- Page 1 PSPS40 / PSPT40 PSPS40 / PSPT40 PSPS40 / PSPT40 PSPS40 / PSPT40 User/Technical Manual Contents subject to change without notice Version 1.0 04/2021...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS 1. 1. 1. 1. Introduction Introduction ........................1 Introduction Introduction 1.1. General and Safety Information ........................1 1.2. Specifications ............................... 1 2. 2. 2. 2. Unpacking and setup ......................2 Unpacking and setup Unpacking and setup Unpacking and setup... -
Page 3: Introduction Introduction
96.45lb 240.9oz 481.8oz 644.5oz 964.5oz calibration calibration calibration zero calibration calibration Power-on zero zero point zero point point zero point zero point -10%~+10% -1.5%~+10%F range -10%~+10%FS -5%~+10%FS -3%~+10%FS power-on zero ±1.5%FS Zero Key rang RS232, USB Interface PSPS40 / PSPT40... -
Page 4: Unpacking And Setup Unpacking And Setup
If the scale will be stored or transported in the future, save the packaging material to ensure the best possible protection for the scale. 2.1 Packing List Scale Tower assembly (PSPT40 only) Manual 12Vdc/500mA adapter Weighing platforms (one plastic platform +one stainless steel platform) PSPS40 / PSPT40... -
Page 5: Assembling
2.2 Assembling PSPS40: Install the weighing platforms onto the base, with the pan properly aligned. PSPT40: Follow below procedure to install the tower display. Pass the socket on bottom of scale base through the pole bracket, and plug it to the connector. -
Page 6: Keypad Functions Keypad Functions Keypad Functions
PRINT PRINT AC AC AC AC - - - - AC Adapter in-use indicator Charge Charge - - - - Battery being charged indicator Charge Charge 3.2 Keypad functions Keypad functions Keypad functions Keypad functions PSPS40 keypad PSPS40 / PSPT40... - Page 7 ON/OFF+7 7 7 7 : Used to enter OS-2030D Back Feed setup mode (If “232.out” is set to “HOST”, this setting is invalid) ON/OFF ON/OFF ON/OFF ON/OFF ON/OFF ON/OFF+8 8 8 8 : Used to enter OS-2030D Origin setup mode (If “232.out” is set to “HOST”, this setting is invalid) PSPS40 / PSPT40...
-
Page 8: The Meaning Of The Special Displayed Character
Symbol Symbol Symbol Symbol 7 7 7 7 - - - - segments digit segments digit segments digit segments digit À Â Æ Ç È É Ê Ë Î Ï Ô Ù Û Ü PSPS40 / PSPT40... -
Page 9: Operations Operations
To clear the manually entered tare weight, (enter “0” and) press the Tare key to confirm. d. If unit price is in un-saved mode, the tare weight and unit price will be auto cleared after transaction and objects being moved. PSPS40 / PSPT40... -
Page 10: Save Function Save Function
(example): (example): (example): (example): Label dimension is 58mm × 40mm Label dimension is 58mm × 60mm 3. Content of printed out: 3. Content of printed out: 3. Content of printed out: 3. Content of printed out: PSPS40 / PSPT40... -
Page 11: Input The Unit Price Directly Input The Unit Price Directly
16. Use the numerical keys 0-9, CLEAR key to input the tare weight, use ENTER key to store and confirm. then go to the next store unit setting, namely, plus one to the last Address, then repeat the steps from 1-15. Or press ON/OFF key to give up input and back to the normal weighing mode; PSPS40 / PSPT40... -
Page 12: Recall Direct Plu
Now WEIGHT window will show “UoL.x.x” (Voltage x.x V), this means the inner working voltage is x.x V. If the scale uses AC power adaptor, the voltage is the power adaptor voltage after regulating. If AC adaptor is not used, this around voltage is battery’s voltage. A/D internal code will be displayed in TOTAL PRICE. PSPS40 / PSPT40... -
Page 13: The Details About Rs232 Communication The Details About Rs232 Communication
HOST 2.2 P P P P rtd rtd rtd rtd40 40 40 40 (PSPS40/PSPT40-xxxx is connected with the OS-2130D, label dimension is 58mm × 40mm, date will be printed on label) 2.3 P P P P rtd rtd60 60 60 60 (PSPS40/PSPT40-xxxx is connected with the OS-2130D, label dimension is 58mm × 60mm, date will be... - Page 14 Use the numerical keys 0, 1, 2, 3 to select which format will be used. TYPE EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 EAN13 I2of5 Department Code; Item Code; Check-sum for price (4 digits); Check-sum for price (5 digits); Check-sum for weight (4 digits); PSPS40 / PSPT40...
- Page 15 PIN4 DSR------------------4--------------------4---------------------------PIN4 DTR PIN6 DTR------------------6--------------------6---------------------------PIN6 DSR PIN7 CTS------------------7--------------------7---------------------------PIN7 RTS PIN8 RTS------------------8--------------------8---------------------------PIN8 CTS PIN1 NC--------------------1--------------------1---------------------------PIN1 NC PIN9 NC--------------------9--------------------9---------------------------PIN9 NC Note: PIN4 and PIN6, PIN7 and PIN8 are shorted in the scale! 11. RS-232 cable connects between scale and OS-2130D： PSPS40 / PSPT40...
-
Page 16: Date And Time Setting Date And Time Setting
2. The weight window disPSPT40ays "SETUP”, the UNIT PRICE window disPSPT40ays “Id” and the TOTAL PRICE window disPSPT40ays Id code xxxxxx(the default Id code is 000000). 3. Use the numerical keys to input ID code, then press Enter key to confirm the input and exit this mode. PSPS40 / PSPT40... -
Page 17: Setting
1. Connect the scale to PC through RS232 interface, run PSPS40.exe, this software can only process *.xls files. (The following is ExamPSPT40e for PSPS40-1530) 2. Software searches all serial ports on PC, and tries to connect with the scale. In the Status bar, it will separately disPSPT40ay present serial port, baud rate, data format. - Page 18 “Serial Set” in “Serial” menu. 4. Press “Open” or “open file” button in “File” menu, it will first remind you whether to save the current file, and then open the file and dialogue box to choose and open the right file. PSPS40 / PSPT40...
- Page 19 If it \ disPSPT40ays “Downloading Mxx”, it means it’s downloading the information of M1~M9 (direct unit price). If it disPSPT40ays “Downloading No. xxx”, it means it’s downloading the information of PSPT40U1~265. “Download successful” will be disPSPT40ayed after downloading finished. In downloading, to use "Serial\Download\Stop" or F9 can stop down load PSPT40U. PSPS40 / PSPT40...
- Page 20 Choose ”Pair” in “Serial” menu to open the date and time setting dialogue box, it will disPSPT40ay the system clock of PC, press “Confirm” or exit the dialogue box directly. After the software send date and time setting data to the scale, it will disPSPT40ay “Pair successful.”. PSPS40 / PSPT40...
-
Page 21: Calibration
7. When the WEIGHT window disPSPT40ays "unLoAd" again, the scale is ready to re-confirm the zero point, remove any weight on the scale, after the scale is ready and unit indicator stops flashing, press Enter key to confirm. 8. After the calibration comPSPT40etes, the UNIT PRICE window disPSPT40ays "CAL.END" and TOTAL PRICE window PSPS40 / PSPT40... -
Page 22: The Meaning Of Some Dispspt40Ayed Symbols 17. The Meaning Of Some Dispspt40Ayed Symbols The Meaning Of Some Dispspt40Ayed Symbols
----- ----- ----- -----To unload the weight -------- --------To load the weight -------- -------- -------- --------To input load weight -------- -------- ------Calibration enable switch is ON ------ ------ ------ ----- ----- ----- -----Calibration enable switch is OFF PSPS40 / PSPT40... -
Page 23: Troubleshooting And Battery Charging Troubleshooting And Battery Charging
Calibrate scale again Remove the SS PSPT40atter when scale is on Put back the SS PSPT40atter RePSPT40ace the load cell; or The load cell signal is too big. RePSPT40ace PCB PSPS40 / PSPT40... -
Page 24: Battery And Charging Battery And Charging
Battery life and recharge time will vary with use. Over time, the operating time per each full charge will degrade. If the operating time is no longer acceptable, the battery must be rePSPT40aced. When storing the scale for extended periods, the battery must be charged every 90 days to avoid premature performance degradation. PSPS40 / PSPT40...
