Summary of Contents for TransDeco TD600B

  • Page 2 - Repeat Step 1 to install the bottom panel(Part T); - Instqall the bolt(Part A)into the side panel(Part U); - Insert the camlock into the top panel(Part S); - Check the “LEFT”mark is on the left side as shown; - Attach the top panel to the side panel; - Turn the camlock(Part B)210 degree with a flathead screw driver(not included).
  • Page 3 - Attach the wood frame to the main structure; - Install the pivoting device(Part X) to the mounting bracket(Part AA). - Do not tighten the screws until all screws are in place; - Align the wood frame and the main structure; - Fasten all the screws including those on the back panel and the top connectiong bar;...
  • Page 4 - Install the top glass shelf; - Insert the bottom glass shelf as shown; - Align the glass with wood frame,loosen the screws on the back panel - Insert the middle glass shelf as shown. for adjustment if necessary; - Attach the TV mounting bracket to the TV; - Install the safety bolts to the top anchors.
