ALS Tire Pro
Install Guide
(20.06.2022)
V1.0 – Initial version
1
© Alsense Motorsport SRL

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALS Tire Pro and is the answer not in the manual?

Questions and answers

Related Manuals for ALSENSE ALS Tire Pro

Summary of Contents for ALSENSE ALS Tire Pro

  • Page 1 ALS Tire Pro Install Guide (20.06.2022) V1.0 – Initial version © Alsense Motorsport SRL...
  • Page 2 The recommended way would be to remove the PCB and silicone seal, but, if you can drill the holes to be 2-3mm, you can jump straight to step #3 in the guide © Alsense Motorsport SRL...
  • Page 3 2. Taking the sensor apart Unscrew the 3 x M2 screws of the case and gently lift the lid. © Alsense Motorsport SRL...
  • Page 4 Remove the two screws that fix the PCB to the case and gently push the camera and silicone seal out © Alsense Motorsport SRL...

  • Page 5: Drilling The Holes

    Drill the 2 holes using the supplied template. They need to be tapped for M2 screws, so use a 1.6 drill bit. Fit the lens into the mount and put everything in place using the M2 screws provided. © Alsense Motorsport SRL...
