KeyOuest MI5 Quick Start Manual page 2

TRUE WIRELESS EARPHONES MI5
Ref: KO025918 / KO025925
CHARACTERISTICS
• Input : 5V
• Sensitive : 98 ± 3dB
• Impedance : 16Ω
• Frequency response : 20-20KHz
• Sound pressure level : 95dB
• Charging case battery : 500 mAh
• Earphones battery : 50 mAh
• Calling time / Listening time : 3 hours
• Charging time : 2 hours
• Bluetooth specification : Bluetooth 5.0
PACKAGING CONTENTS
• 1 pair of true wireless earphones
• 2 silicone wingtips
• 1 charging case
• 1 micro USB charging cable
• 1 user manual
DESCRIPTION OF PARTS
3
1
2
4
5
WARNING & SAFETY INSTRUCTIONS
Be careful to listen your music at reasonable volumes for reasonable periods of time.
Excessive sound pressure from earphones can cause hearing loss. Do not turn up the
volume so high that you can't hear what's around you. You should use caution or temporarily
discontinue use in potentially hazardous situations. For your safety, avoid distractions from
music or phone calls while in traffic or other potentially dangerous environments. Do not
expose any piece to rain or moisture and to heat sources.
Keep all small parts, bags and packaging out of the reach of children.
Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives. If
cleaning is required use a soft cloth.
Directive 2012 / 19 / EU
Correct disposal of this produt
Electronic waste should not be thrown away with household waste. Please recycle them to your authorized
agency and check the recycling advice with the relevant local authorities.
Make an eco-citizen gesture, recycle this product at the end of its life and think about sorting your waste.
1 : Dust-proof Mesh
2 : Built-in Microphone
3 : LED Light indicator / Phone button
4 : Charging LED Indicator
5 : Charging case Power ON/OFF Switch
6
6 : Charging Port
PRODUCT USE
CHARGING INSTRUCTIONS
Charging case
Connect the USB cable to any USB charging
source, and the micro USB plug to the
charging port of the charging case.
The charging LED indicator flashes blue
to indicate that its built-in battery is being
charged.
When the battery is fully charges, the LED
light will stay on.
PAIRING THE EARPHONES WITH BLUETOOTH
1. Ensure the earphones are fully charged.
2. Press and hold the MF button for 3-4 seconds to turn on, an indication tone will be heard
and the LED flashes red and blue.
3. Place the earphones and Bluetooth
other.
4. Activate the Bluetooth function on your device.
®
5. Select «KEYOUEST».
6. Once paired successfully, another indication tone will be heard and the LED will flash
blue slowly.
7. You can now start to use the earphones.
Note : Your earphones and your mobile device will be paired automatically for next use.
USE OF YOUR EARPHONES
Power ON/OFF
Turn On your earphones Press and hold the Phone button for 3-4 seconds
Turn Off your earphones Press and hold the Phone button for 3-4 seconds
Music control
Play/Pause Short press the MF button
Call control
Pick up/Hang up a call Short press the MF button
Reject incoming call Press the Phone button 2 seconds and release
Redial last number Short press the Phone button twice
Warranty
Products are guarranteed against any failure from manufacturing defects.
This warranty does not cover normal wear or tear, or damage caused by improper use,
keep your invoice stapled to the user manual.
Earphones
To start charging, put the earphones into
the charging case.
Short press the power ON/OFF Button on
the charging case to turn on.
The LED light indicator turn red to indicate
that the battery is being charge.
When the battery is fully charged, the LED
light will turn blue and it will turns off in 1
minute.
DEVICES
®
device no further than 1 meter apart from each
®
2020/06V2/MKG
