- Page 1 EDGE BLIND ASSEMBLY INSTRUCTIONS Part Number: 04619V www.terrainoutdoor.com (989) 575-3122 READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.
- Page 2 SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. EDGE BLIND USAGE INSTRUCTIONS AND WARNINGS Thank you for your purchase of this Terrain Outdoor® Hunting Blind experience the need to contact emergency assistance. Failure to product. To ensure your personal safety, please take a moment to...
-
Page 3: Parts List
INS-COMMON TAB PLEXIGLASS Windows INS-COMMON LIVING HINGE Window Hinge STORAGE AND CARE SPECS All Terrain Outdoor ® hunting blinds are made with an Size: 48”x48”x78” (LxWxH) industrial grade UV Protected High Density Polyethylene material. All components and hardware is resistant to sun, Weight: 91 lbs moisture, and normal temperature fluctuation. - Page 4 Nut (10-32 Lock Nut) 3014 Washer (¼ ID ⅝ OD) 03863V-A Edge Roof 6013 Wing Nut (¼-20) INS-TERRAIN-HANDLE Door Handle INS-COMMON TAB PLEXIGLASS Windows INS-COMMON LIVING HINGE Window Hinge INS-TERRAIN-TURN-BUTTON Window Latch READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.
- Page 5 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: EDGE 04619V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. FIG 1 STEP 1: Attach (2) common sidewall [03864V-A] panels together using (5) Bolt ¼-20 x ⅞"...
- Page 6 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: EDGE 04619V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. FIG 3 STEP 3: Attach (1) Door/Frame Assembly [004627V-A] 03864V-A panels to the assembly using (5) Bolt ¼-20 x ⅞"...
- Page 7 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: EDGE 04619V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. STEP 5: Fasten the Edge Roof [03863V-A] to the FIG 5 assembly using (4) Bolt ¼-20 x ⅞"...
- Page 8 NOTE: When assembling, be sure the handle is in the correct orientation as shown. The TERRAIN text faces up, the LATCH faces towards the frame, and the WEATHER COVER is on the exterior.
- Page 9 PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: EDGE 04619V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. FIG 8 STEP 8a: Install the Door Handle [ INS-TERRAIN-HANDLE] into the Door/Frame Assembly [04627V-A]from the exterior of the panel. Insert the tabs near the latch on STEP 8a the Door Handle into the slot as shown.
- Page 10 DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: EDGE 04619V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. STEP 9: Install (8) Window Latches [ INS-TERRAIN-TURN- FIG 9 BUTTON] into the Door/Frame Assembly [04627V-A] and (3) Common Sidewall Panels [03864V-A].
- Page 11 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: EDGE 04619V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. STEP 10: Attach (4) Windows [INS-COMMON TAB PLEXIGLASS] FIG 10 to (4) Window Hinges [INS-COMMON LIVING HINGE].
