Summary of Contents for TERRAIN VANROVE 04620V
- Page 1 RANGE BLIND ASSEMBLY INSTRUCTIONS Part Number: 04620V www.terrainoutdoor.com (989) 575-3122 READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.
- Page 2 SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. RANGE BLIND USAGE INSTRUCTIONS AND WARNINGS Thank you for your purchase of this Terrain Outdoor® Hunting Blind experience the need to contact emergency assistance. Failure to product. To ensure your personal safety, please take a moment to...
-
Page 3: Parts List
INS-COMMON TAB PLEXIGLASS Windows INS-COMMON LIVING HINGE Window Hinge STORAGE AND CARE SPECS All Terrain Outdoor ® hunting blinds are made with an industrial grade UV Protected High Density Polyethylene Size: 76”x76”x85” (LxWxH) material. All components and hardware is resistant to sun, Weight: 114 lbs moisture, and normal temperature fluctuation. - Page 4 Roof Panel 3014 Washer (¼ ID ⅝ OD) 04630V Roof Cap 6013 Wing Nut (¼-20) INS-TERRAIN-HANDLE Door Handle INS-COMMON TAB PLEXIGLASS Windows INS-TERRAIN-TURN-BUTTON Window Latch INS-COMMON LIVING HINGE Window Hinge READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.
- Page 5 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: RANGE 04620V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. FIG 1 STEP 1: Attach (2) common sidewall [03864V-A] panels together using (5) Bolt ¼-20 x 1-¼"...
- Page 6 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: RANGE 04620V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. FIG 3 STEP 3: Attach (1) Door/Frame Assembly [004627V-A] panels to the assembly using (5) Bolt ¼-20 x 1-¼"...
- Page 7 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: RANGE 04620V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. STEP 5: Lay each section of the (5) Range Roof FIG 5 Panel [03866V-C] so they overlap each other with the holes lined up, small ribs inside the...
- Page 8 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: RANGE 04620V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. STEP 7: Align the Range Roof Assembly above the wall FIG 7 and door panels so that the holes overlap each other.
- Page 9 NOTE: When assembling, be sure the handle is in the correct orientation as shown. The TERRAIN text faces up, the LATCH faces towards the frame, and the WEATHER COVER is on the exterior.
- Page 10 PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: RANGE 04620V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. FIG 9 STEP 10a: Install the Door Handle [ INS-TERRAIN- HANDLE] into the Door/Frame Assembly [04627V-A] from the exterior of the panel. Insert the tabs near the STEP 10a latch on the Door Handle into the slot as shown.
- Page 11 DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: RANGE 04620V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. STEP 11: Install (10) Window Latches [ INS-TERRAIN- FIG 10 TURN-BUTTON] into the Door/Frame Assembly [04627V- A] and (4) Common Sidewall Panels [03864V-A].
- Page 12 ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: RANGE 04620V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST. STEP 12: Attach (5) Windows [INS-COMMON TAB PLEXIGLASS] FIG 11 to (5) Window Hinges [INS-COMMON LIVING HINGE].
