- Page 1 Parachute Manual DRS-M600_EN Parachute Manual DRS-M600 Version 1.1-EN-Draft B Drone Rescue Systems GmbH Austria – Stremayrgasse 16/4 8010 Graz www.dronerescue.com office@dronerescue.com ©2021 Drone Rescue Systems GmbH 1/27...
-
Page 2: Table Of Contents
After flight ........................22 Device ........................23 Device states and signals ................... 23 Device Configuration ....................23 System Time ....................... 24 Firmware Update ....................... 25 Specifications ......................26 Storage ........................27 10 Maintenance ......................27 ©2021 Drone Rescue Systems GmbH 2/27... -
Page 3: Disclaimer
Drone Rescue Systems GmbH, its subsidiaries, the directors, employees and agents cannot be held liable for the use of and reliance of the opinions, estimates, forecasts and findings in these documents. -
Page 4: Introduction
Parachute Manual DRS-M600_EN Introduction The DRS-M600 is approved for the DJI M600 series including the professional version (M600 pro) with any additional payload as long as it is operated within the specifications provided by the manufacturer DJI. It provides the following advantages: •... -
Page 5: Components
Hook Brummel hook Hook protection Protection sleeve for the Brummel hook sleeve Cord box Cord box Depending on the actual DRS configuration, the component pictures in Table 1 may slightly differ from your system. ©2021 Drone Rescue Systems GmbH 5/27... - Page 6 3x8mm cylinder head screws PCB-screw (2.5mm hexagon socket) Flat washers (used to mount the motor cut-off Flat washer PCB) Safety washers (used to mount the motor cut- Safety washer PCB) Table 1 System components ©2021 Drone Rescue Systems GmbH 6/27...
-
Page 7: Installation
No drone parts should be ripped off in this case. Each possible spot is right above a battery slot as shown in Figure 1. Figure 1: Feasible positions for the DRS M600 connector, marked in yellow ©2021 Drone Rescue Systems GmbH 7/27... - Page 8 DRS accessory from the A3 flight controller’s port of your choice (e.g. port F3) through the openings in the center to the bottom of the UAV (see Figure 2 and Figure 3). ©2021 Drone Rescue Systems GmbH 8/27...
-
Page 9: Install The Motor Cut-Off Pcb
Unplug the XT30 socket which powers the landing gear’s servo. Remove the bottom cap if not already done yet. ©2021 Drone Rescue Systems GmbH 9/27... - Page 10 Caution: safety washer must be put between the cylinder head of the screw and the flat washer! Ensure a clean surface of the flat washer's bottom and the PCB. ©2021 Drone Rescue Systems GmbH 10/27...
- Page 11 "Landing gear IN". Take the short RC cable included in the DRS accessory and wire it from the PCB's "Landing gear OUT" connector to the landing gear servo. ©2021 Drone Rescue Systems GmbH 11/27...
- Page 12 Take the loose end of the DRS M600 connector's cable and plug it into the corresponding socket (labeled "DRS"). Figure 4 shows the motor cut-off PCB after the installation Figure 4: Overview of the installed M600 motor cut-off PCB ©2021 Drone Rescue Systems GmbH 12/27...
-
Page 13: Mount The Cords
After the cords have been tied correctly to the arms of the M600, thread the ends of all three cords through the central hole in the cord box lid. Then push the lid downwards. ©2021 Drone Rescue Systems GmbH 13/27... - Page 14 Push the cords far enough through the metal hook to wrap the loops of the cords over the hook. Make sure to push the metal hook through all three loops of the cords. ©2021 Drone Rescue Systems GmbH 14/27...
-
Page 15: Configure The Dji M600
A PWM signal is used to deploy the parachute manually. The A3 flight controller has to be configured to generate this signal. The camera trigger on output port F3 is used here as an example, but you may choose another configuration appropriate for your application. ©2021 Drone Rescue Systems GmbH 15/27... -
Page 16: Drs Configuration
50th flight to verify the proper operation of the parachute system. The intention is to test the engine shutdown and the deployment mechanism without a parachute actually being loaded in the container. It is necessary to switch on the motors but keep the UAV on the ground during this test. ©2021 Drone Rescue Systems GmbH 16/27... - Page 17 • Verify that all 12 screws that fix the motor cut-off PCB are pulled tight. • Verify that all 6 screws that fix the red cables on the sockets M1 to M6 are pulled tight. • Reattach the bottom cap. ©2021 Drone Rescue Systems GmbH 17/27...
-
Page 18: Flight
When lifted, place the container on a flat surface and keep the shutter in this position. ©2021 Drone Rescue Systems GmbH 18/27... -
Page 19: Load The Parachute
6.2.2 Load the Parachute Remove the rubber bands from the parachute keep the plastic cover shut or the parachute will unfurl. ©2021 Drone Rescue Systems GmbH 19/27... - Page 20 The cord of the parachute should lead out underneath the container lid at its designated position pointing to the center of the UAV when mounted. ©2021 Drone Rescue Systems GmbH 20/27...
-
Page 21: Takeoff
Takeoff Observe the LED and the buzzer during takeoff and thus verify that the DRS is in the correct system state (see chapter 7.1 Device states and signals). ©2021 Drone Rescue Systems GmbH 21/27... -
Page 22: After Flight
If the DRS does not detect the takeoff, you must land the UAV because the automatic deployment function is inactive. Switch the power off, wait 10 seconds and repeat the start procedure. If the failure persists, inform Drone Rescue Systems GmbH or it’s reseller and provide the logfile for failure analysis. -
Page 23: Device
Parachute Manual DRS-M600_EN Device The DRS-M600 is equipped with a micro SD memory card slot. The SD card is FAT32 formatted and is used to store logfiles, perform firmware updates, and load configuration parameters. Device states and signals An indication light and a buzzer are used to inform the pilot about the DRS-M600 internal system states as described in Table 2. -
Page 24: System Time
System Time The DRS-M600 is capable of naming the log-files based on the current date and timestamp. Therefore, the system’s time has to be set in advance. This is done once after fabrication but ©2021 Drone Rescue Systems GmbH... -
Page 25: Firmware Update
Firmware Update Store a file (.bin extension), provided by Drone Rescue Systems GmbH, in the root directory of the micro SD card to perform a firmware update. When the DRS powers up, the file will be found and the update process will start automatically. -
Page 26: Specifications
ℎ Average impact energy 88.3 J (65.0 ft-lb) Results tested at 15.50 kg take-off weight: �� ���� Average descent rate 4.58 (16.5 , 10.2 mph) �� ℎ Average impact energy 162.5 J (119.8 ft-lb) ©2021 Drone Rescue Systems GmbH 26/27... -
Page 27: Storage
• Replacement of the elastic rubber springs (part of the container) • Replacement of the parachute cords The maintenance needs to be done by Drone Rescue Systems GmbH or a certified partner of Drone Rescue Systems GmbH. ©2021 Drone Rescue Systems GmbH...
