Summary of Contents for IDOO ID-IG301S
- Page 1 User Manual Smart Indoor LED Hydroponic System Model: ID-IG301S...
-
Page 2: Important Safety Instructions
Important Safety Instructions 1. Do not use this product outdoors. It is intended for indoor household use only. 2. Please use the power adapter with a 12V output voltage and a 3A current. To reduce the risk of electric shock, do not alter or replace the power adapter in any way. 3. -
Page 3: Using The Product
2. Specification Model: ID-IG301S Water Tank Capacity: 4L Power Adapter: 100V-240V~ 50/60Hz Light Panel: NOT Waterproof Input: 12V Working Temperature: 15℃ - 30℃/59℉ - 86℉ Operating Voltage: 12V Product Weight: 2.7kg/5.95lb Fan Speed: 2500r/m Product Size: 35*26*24.5cm/13.8*10.23*9.64inch Fan Noise: ≤40dB... - Page 4 2. Adjust the Height of the LED Light Panel Rotate the knob on the back of the rod and pull the upper rod section to adjust the height. Do not pull the lower rod section. It is designed to be firmly attached to the water tank.
- Page 5 4. Plant Seedlings The Gardening Kit does not include seeds. It is recommended to purchase seeds from a known local brand. Step 1 • Put 3-4 seeds into the wet sponge. (Some seeds germinate in less than 24 hours, some may take 1-4 weeks.) •...
- Page 6 5. Plug-In Do not plug the power adapter if there is no water in the tank. 6. Control Panel Settings Power: After plugging in, the power indicator will turn solid red and blinking green, indicating that the machine is on standby mode. Then, short press the button to turn it on. The power indicator will flash green (It will turn solid green if the device is connected to the App).
-
Page 7: App Instructions
APP Instructions Note: Due to continuous updates and improvements, the app may appear slightly different. Please follow the in-app instructions in case of any differences. 1. Search Search for "Gennec" on App Store/Google Play or scan the QR code below to download the app. Gennec Gennec 2. - Page 8 3. Add Device Note: Please make sure your phone is connected to a secure 2.4 GHZ Wi-Fi network. The device can only be connected on a secure 2.4 GHZ network. Plug in the device and enable your Bluetooth, the power indicator will flash green to wait for connecting.
- Page 9 Method 1 Click “Add Device” or “+” on the upper right corner, then click “IG301S Smart Garden” in the Smart Home category. Input the Wi-Fi password and click “Next” to add the device through Default Configuration Mode (EZ Mode) following the in-app instructions. Method 2 Click “Add Device”...
- Page 10 Method 3 If the Default Configuration Mode (EZ Mode) fails to connect, you can use AP (Access Point) Mode. This mode enables you to connect your mobile phone to the device’s hotspot first and then add the device. 1. Follow the following steps. 2.
- Page 11 4. Operation After pairing successfully, you will be directed to the Home Page. Click “Power On/Off” to turn on/off the device. Click corresponding keys to control the settings of Flowers & Fruits/Vegetables modes, Light, Pump and Fan. Click the “Settings” icon to adjust the following functions.
-
Page 12: Product Maintenance
5. Remove the Device To disconnect the device, click the pen icon on the upper-right corner in the Home Page to enter the interface, slide down and tap “Remove Device”. For more detailed instructions for App, please scan the QR code below to access and read. - Page 13 Cleaning Pump Clean the water pump at least once a month. Step 1: Turn the power off and remove the top cover of the water tank. Step 2: Unplug the pump and remove the filter cover from the water pump. Step 3: Take out the cotton.
- Page 14 5. Why does it not germinate? It can vary depending on the temperature. You can try to grow it in the soil to test whether it is the seed problem. 6. Why does it not bloom or bear fruit? Make sure the nutrition is enough. Keep in mind to add water while adding a proportionate amount of nutrients.
-
Page 16: Customer Service
Customer Service We have an award-winning warranty, exchange, and customer service team that guarantees hassle-free solutions to any issue you might have within the 24 business hours. Tel: +1(951)751-2590 (US ONLY) Monday-F iday: 9:00AM-4:30PM Email: suppo t@idooworld.com *For defective products or the return of items, please contact us with your order number within the specified warranty period.
