Avenue 3
Class 1
E27
1
Perçage des trous de fixation
Drill the mounting holes
lg: 150mm
Classe énergétique du luminaire à disposition sur notre site internet. - Type et puissance max. indiqués sur l'étiquette signalétique dans le luminaire. - Energy label for lighting fixture available on our website. - To know the bulb type and max wattage, please, refer to the label inside light fitting.
2
Fixation du support au plafond
Fix the support to the ceiling
Ø64,5mm
3x Ø8mm
x4
x3
x3
x3
3
Installation des verres
Put in place glasses
2
4
3
1
x1
Advertisement
Table of Contents
Related Manuals for Roger Pradier Avenue 3 M1
Summary of Contents for Roger Pradier Avenue 3 M1
- Page 1 Avenue 3 Class 1 Perçage des trous de fixation Fixation du support au plafond Installation des verres Drill the mounting holes Fix the support to the ceiling Put in place glasses Ø64,5mm lg: 150mm 3x Ø8mm Classe énergétique du luminaire à disposition sur notre site internet. - Type et puissance max. indiqués sur l’étiquette signalétique dans le luminaire. - Energy label for lighting fixture available on our website. - To know the bulb type and max wattage, please, refer to the label inside light fitting.
- Page 2 Montage de la lampe & de la cage Raccordement électrique Fixation du luminaire Put in place light-bulb & assemble the cage Connect electrical wires Fix the luminaire LUBRIFIANT Greace roger-pradier.com Conçu & fabriqué en France / Design & manufactured in France...
