- Page 1 AEA 5000 Installation and user manual Document name SIR-AEA5000-EN-REV0 Date of publication 2022-01-11...
-
Page 2: Table Of Contents
AEA 5000 - Self-consumption cabinet with storage Contents 1. Product presentation 1.1 Dimensions 1.2 Description of the front panel controls 1.3 Fault list 1.4 Safety instructions and warnings 1.5 Protective device 1.6 Disposal 1.7 Cleaning 1.8 Identification of the AEA 5000 1.9 Functional principle... -
Page 3: Product Presentation
AEA 5000 - Self-consumption cabinet with storage 1. Product presentation The AEA 5000 cabinet was developed with the aim of delivering a reliable power supply from various sources of conventional and renewable energy. This cabinet promotes self-production and facilitates self-consumption of the electrical energy generated, in order to reduce the consumption of electricity from the electrical network. -
Page 4: Description Of The Front Panel Controls
AEA 5000 - Self-consumption cabinet with storage 1.2 Description of the front panel controls Icon Comment Solar indicator Green fixe: production in progress but production below consumption Slow flashing green: production in progress, production covers the needs of the dwelling, the surplus is charged into the battery... -
Page 5: Fault List
AEA 5000 - Self-consumption cabinet with storage 1.3 List of faults Intitulé Action Lightning fault Check the condition of the PF10 / PF20 arresters Check the connections between the inverter and RS485 communication fault with the inverter the PLC (OND1 / API1) -
Page 6: Safety Instructions And Warnings
AEA 5000 - Self-consumption cabinet with storage 1.4 Safety instructions and warning Attention Any damage resulting from non-compliance with this user manual will void the warranty! We do not accept any liability for damage to property or personal injury caused by incorrect handling or failure to observe the safety instructions. -
Page 7: Identification Of The Aea 5000
AEA 5000 - Self-consumption cabinet with storage 1.8 Identification of the AEA 5000 To identify the AEA 5000, a label with a barcode is attached to the inside of the cabinet door. The serial number (SN) is shown in the third row of the table. -
Page 8: Functional Principle
AEA 5000 - Self-consumption cabinet with storage 1.9 Operating principle Energy from the renewable source is used for consumption as a priority. If there is excess energy production, it is stored in the battery. If the battery reaches a full charge level, the power of the panel will be limited so as not to send power to the grid (in case of sale to the grid, refer to paragraph 2.4) -
Page 9: Commissioning Of The Cabinet
2. Commissioning 2.1 Installation of the batteries The AEA 5000 cabinet is designed to accommodate Phenix Batteries. For further information on the batteries, please refer to the enclosed manual. The batteries are delivered with their power cables. The communication cable to be connected to the battery is already connected in the cabinet. -
Page 10: Connecting The Batteries
AEA 5000 - Self-consumption cabinet with storage 2.2.3 Connecting the batteries Connect the black connectors to black terminals and the orange connectors to orange terminals 2.2.4 Connection of the communication cable Connect the communication sockets (multicolored cable). The plug at the end of the cable should go to the DB9 socket on the back battery and the other socket closest to the front panel. -
Page 11: Connecting To The Mains
AEA 5000 - Self-consumption cabinet with storage 2.2.5 Network connection Connect the cabinet to the mains as follows: connect neutral to terminal 1 of the XP terminal block, phase to terminal 2 and earth to the adjacent earth socket. 2.2.6 Connecting the measuring torus Connect the ORANGE to the XTC terminal block, fil red to... -
Page 12: Switching On The Batteries
AEA 5000 - Self-consumption cabinet with storage Switching on the batteries 2.2.8 Warning To be done at power up: the batteries are switched on by operating the circuit breaker QF30. The LEDs on the batteries flash and then turn fixe green. - Page 13 AEA 5000 - Self-consumption cabinet with storage To do this part: Circuit breaker ID10: - green led on (system connected to the network) - Sur ON Circuit breaker QF10 : - Sur ON Have a computer or smartphone WiFi client connection available Step 1 : Go to the wi fi...
- Page 14 AEA 5000 - Self-consumption cabinet with storage Step 4 : You arrive on this page. Click on "WiFi Settings" Step 5 : Go to the "Internet WiFi" tab Then click on "Add" Step 6 : Select the customer's WiFi network from the list (at the bottom of the page) by clicking on the box to the left of the name.
-
Page 15: Option: Hot Water Tank Management
2.3 Option: Hot water tank management 2.3.1 Control of the domestic hot water tank The AEA 5000 offers the possibility of controlling a resistive DHW tank in order to optimise the use of photovoltaic energy. If the option is activated, the heating of the hot water tank will take priority over the charging of the batteries. -
Page 16: Option: Mains Energy Sales
2.5 Option: Backup output 2.5.1 Management of the backed-up output The AEA 5000 has a back-up output, which provides a temporary source of power in the event of a power failure, voluntary or otherwise. This output is powered when the system is powered up and remains powered if the mains input is cut off. -
Page 17: Putting Into Operation
AEA 5000 - Self-consumption cabinet with storage 3. Putting into operation 3.1 Power on / off The front disconnectors are omnipolar switching devices that can be used for emergency breaking as well as for completely de-energizing the cabinet. The switching devices on the front are preferably open when the cabinet is de-energized See visual section 1.2. -
Page 18: Contacts
AEA 5000 - Self-consumption cabinet with storage Contacts France Sirea 1 rue Jean Perrin 81100 Castres Phone: +33 5 63 72 93 92 Mail: contact@sirea.fr Spain Calle de Arcadio María Larraona, 1, 2º 31008 Pamplona, Navarra Phone: +34 948 067 152 Mail: a.monreal@sireagroup.com...
