GLMX Series
1
Introduction
Thank you for purchasing the GLMX720 . The GLMX720 is a 720W horticultural LED light. It drives
six LED bars each of which is 120W. The GLMX720 is intended to be used in indoor grow rooms.
Other types of plug are also available, please check with our sales engineers directly.
This manual describes the installation and connection of the product and also describes how to
use the product. Mounting and installing of the GLMX720
service personnel. Please read and understand this manual completely before using the product.
Only use the product as specified in this manual.
2
Product Information & Specifications
General Information
2.1
Product Name
Manufacturer
Version
Plug Type
Input Voltage
US 5-15P
!
Note:
Other types of plug are also available, please check with our sales engineers directly.
GLMX720 720W LED Grow Light
C
GLMX720 720W LED Grow Light
C
Shenzhen VANQ Technology Co., Ltd.
US
US plug 120-277V
120-277VAC
US 6-15P
US L7-15P
C
C
C
C
may only be executed by certified
EU
UK
EU plug 230V
UK plug 240V
100-230VAC
100-240VAC
EU plug 230V
AUS
AUS/NZS plug 240V
100-240VAC
UK plug 240V
AUS/NZS
plug 240V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLMX Series and is the answer not in the manual?

Questions and answers

Related Manuals for VANQ GLMX Series

Summary of Contents for VANQ GLMX Series

  • Page 1 Only use the product as specified in this manual. Product Information & Specifications General Information Product Name GLMX720 720W LED Grow Light Manufacturer Shenzhen VANQ Technology Co., Ltd. Version Plug Type US plug 120-277V EU plug 230V UK plug 240V...
  • Page 2 Specifications GLMX 720C GLMX720C-S GLMX720 Power InputPower 720W ±5% 720W ±5% 720W ±5% InputVoltage(Standard) 100-277VAC 100-277VAC 100-277VAC HighInputVoltage(Optional) 277-480VAC 277-480VAC 277-480VAC Light Source Details Model SMD2835 SMD2835 SMD3030 Supplier SAMSUNG OSRAM SAMSUNG LED Diodes - White Rated Max Power per 0.82W ±5% 0.82W ±5% 0.58W ±5%...
  • Page 3 Technical specifications Light Source AC Input Power 720W @ 240VAC AC Input Voltage 120-277V AC, 347-480V AC, 50/60Hz Spectrum Full Spectrum Light Output PPF 1940 µmol/s （ - VQ GLMX720C E - ） Effic 2.7 µmol/J ( - VQ GLMX720C E Product weight 1 kg Dimensions...

  • Page 4: Packing List

    Environment The product is intended to be used in indoor growing environments. The product can be used in wet environments. The product may not be used outdoors. The GLMX720 light functions optimal when the max ambient temperature is between 20~40°C. Packing List Please follow the content of the list and carefully check whether the purchased equipment and accessories are complete.

  • Page 5: Safety Precautions And Warnings

    Product Name Model Quantity Driver Box 720W LED Bar 120W Steel Wire Rope Hanger 30cm/1ft 1/8" Adjustable Ratchet Hangers 1. m 8 Screws SUS304 M4-8 Dimming Cable(optional) T-Shape VD-100 Controller(optional, buy separately) 0-10V Dimming Hex key Safety Precautions & Warnings Warning! Carefully read the warnings below before using or working with the product! Always adhere to the local rules and regulations when installing or using the LED light.

  • Page 6: Installation

    Installation Warning! Mounting and installing of the LED light may only be executed by certified service personnel, in accordance with the applicable local laws and regulations. The installer is responsible for correct and safe installation. Ensure the local cabling can support the voltage and current requirements of the LED light. Avoid coiled cords and keep mains leads separated.
  • Page 7 VQ-GLMX720C-S-BO15CM VQ-GLMX720C-S-SO15CM VQ-GLMX720C-S-OO15CM 1041 1094 1128 1294 1382 1469 1488 1360 1282 1188 1381 1453 1495 1343 1282 1357 1498 1641 1690 1513 1413 1025 1032 1154 1277 1238 1125 1004 1173 1225 1235 1184 1029 1061 1263 1344 1370 1245 1109 1040...
  • Page 8 Warning! Make sure mains power is switched off. Ensure the cord is not coiled and does not touch any hot surfaces. Connect the cables according to local rules, safety regulations and electrical code. Ensure external switching gear can cope with the inrush current of the LED fixture. Always use a double pole contactor suitable for switching a capacitive load.
  • Page 9 38.38"(975mm) 70.8 "(1 Packaging: 1pcs carton 0m m ) 15 7 . " Gross Weight: 16kg 35.3Ibs " 13 0 m m ) Size: 45.6in L x 15.7in W x 5.1in H 1160mm L x 400mm W x 130mm H N e t W e i g h t : 3 5 .

  • Page 10: Inspection, Maintenance And Repair

    (5) years from the original date of purchase. If the product shows any defects within this period and that defect is not due to user error or improper use, VANQ technology shall, at its discretion, either replace or repair the product using suitable new or reconditioned products or parts. In case VANQ technology decides to replace the entire product, this limited warranty shall apply to the replacement product for the remaining initial warranty period, i.e.

This manual is also suitable for:

Glmx720c-eGlmx720c-sGlmx720c-p
