- Page 1 Twin Fold Ground Mounted Clothesline Assembly instructions...
- Page 2 Thank you for purchase of our Twin Fold Ground Mounted clothesline. We hope this clothesline fulfils your laundry needs and continues to remain of benefit to you and your family. This manual includes a set of assembly instructions along with a user guide. Please thoroughly read through these to acquaint yourself before starting the assembly and use of the clothesline.
- Page 3 www.airdryclotheslines.com.au Tools required: • Post hole digger • 13mm spanner or socket and ratchet • Measuring tape • 1-2 bags concrete mix • Ground marker • Spirit level • Cord cutters Step 1: Formula to find the post hole centres Using the overall width of the clothesline ordered, subtract 140mm and this will give you...
- Page 4 www.airdryclotheslines.com.au Repeat with the opposite post. Step 4: Assembling the rear bar Parts required: • 2 x Spreaders • 1 x Joiner Take 2 spreader bars and insert them into each end of the joiner to make one long bar. Make sure to leave the ends with the holes outside and facing the same direction.
- Page 5 www.airdryclotheslines.com.au Step 6: Attaching the twin fold unit • 2 x 110mm bolts • 2 x 90mm bolts • 4 x nuts • 4 x washers • New long spreader bar (Step 4) Make sure that the wall side sticker is facing away from you and place it up to the first post.
- Page 6 www.airdryclotheslines.com.au Step 8: Lifting and lowering the inner frame: Lift the front bar and insert the inner stay into the hole of each arm. Lifting and lowering the outer frame: Lift the front bar evenly from the centre slightly past horizontal until you heard both struts click and engage.
- Page 7 www.airdryclotheslines.com.au Step 9: Wiring Parts Required: • 2 x bundles of cord • Scissors or wire cutters (not supplied) Unravel the bundle of cord. Take one end of the cord and thread the cord up through the first hole at the front of the arm. You may start from either side.
- Page 8 www.airdryclotheslines.com.au Cut off the remaining cord using wire cutter/ scissors, leaving 100mm to be tucked into the inner arm hole. Step 10: Final adjustments Lower the frame to the fold down position Horizontal checks: Sit the spirit level on the rear spreader bar. Make sure this is level. Post adjustment may be needed. Raising and lowering the post height can be done by lifting and packing concrete as needed.
