- Page 1 User Manual KMW3000C Water Chiller Unit October 2001 Version 1.1 Oxford Diffraction Limited 20 Nuffield Way, Abingdon Oxon OX14 1RL UK Tel: +44 (0)1235 532132 Fax: +44 (0)1235 528005 http://www.oxford-diffraction.com...
- Page 2 Important Information This user manual is intended to help the user operate the KMW3000C water chiller unit manufactured in Poland by Oxford Diffraction. Product: KMW3000C Model Type: X-ray tube / generator Electrical Ratings: 1/N AC 230 V 50/60 Hz 300 Watts Before attempting to operate the system, PLEASE READ THE INSTRUCTIONS.
-
Page 3: Table Of Contents
5.2.1.3 Electrical Services....................11 5.2.1.4 Water Supply ...................... 11 5.2.2 Setting to Work......................11 5.2.2.1 Equipment Required ................... 12 5.2.2.2 Setting up Procedures ..................12 5.3 Storage..........................13 6. Operating Instructions ..............14 KMW3000C Version 1 USER MANUAL Page iii KMW3000CChiller v1.1.doc... - Page 4 8.1 Filling The Reservoir With Water ..................16 8.2 Cleaning The Water Filters ..................... 17 9. Trouble Shooting ................18 10. Spares ...................19 11. Additional Information..............20 11.1 Drawings ..........................20 12. CE Conformity Notice..............21 KMW3000C Version 1 USER MANUAL Page iv KMW3000CChiller v1.1.doc...
-
Page 5: Health And Safety Information
1. Health and Safety Information 1.1 General In normal operation the system is designed to operate safely. All users of the KMW3000C water chiller unit should be aware of potential hazards which exist in and around equipment of this type and the ways of avoiding possible injury and equipment damage which may result from inappropriate ways of working. -
Page 6: Recommended Precautions
Check that lifting points are used only for the job intended. The system itself and some components are heavy and require careful handling. Use safe lifting procedures for heavy items to prevent possible strain injury. KMW3000C Version 1 USER MANUAL Page 2... -
Page 7: Safe Mechanical Practice
It should be stressed that those parts of the equipment which are interchangeable, and which are subject to deterioration during operation, may significantly affect the safety of the equipment. KMW3000C Version 1 USER MANUAL Page 3 KMW3000CChiller v1.1.doc... -
Page 8: Introduction
2.3 System Description The KMW3000C is a stand-alone chiller unit intended for indoor use. It is designed to be used to cool X-ray generators and X-ray tubes within a laboratory environment. The purpose of the KMW3000C is to stabilise the temperature of the cooling water supplied to X-ray generators and X-ray tubes. -
Page 9: Specifications
Quick-release type designed for pipes of size 10 x 3 mm External water supply flow rate 0.6 l/min/kW (at 12 ºC tap water inlet temperature) External water supply pressure 0.5 - 5 bar KMW3000C Version 1 USER MANUAL Page 5 KMW3000CChiller v1.1.doc... -
Page 10: Technical Description
4.2 Operating Principles 4.2.1 Tap water circuit Tap water from the mains supply passes through a filter on the front of the KMW3000C. The water then enters the unit through a manual cut-off valve, before passing to the temperature-modulated valve. The temperature-modulated valve controls the temperature stabilisation in the closed water circuit, and the consumption of tap water. -
Page 11: Closed Circuit
Water then passes through the front panel of the KMW3000C to the devices to be cooled. Water returning from the devices passes through the front panel of the KMW3000C via a manual valve. -
Page 12: Control Unit
4.3 Interfaces 4.3.1 Water Supply Four water connections are located on the front panel of the KMW3000C. The closed circuit connectors are combined with manual valves. The connectors are of the Jubilee Clip type and are designed for pipes of size 10 x 3 mm. -
Page 13: Electrical Connections
Soldered on to PCB Soldered on to PCB Neutral Soldered on to PCB J4-Motor and pump unit Logic unit PCB Line Soldered on to PCB Soldered on to PCB Neutral Soldered on to PCB KMW3000C Version 1 USER MANUAL Page 9 KMW3000CChiller v1.1.doc... -
Page 14: Handling, Installation, Storage And Transit Information
4. Always lift the packing case from the bottom using suitable lifting equipment (refer to list of component weights in the following section. 5. Move the packing case into the designated installation site. 6. Contact Oxford Diffraction to notify them that the equipment is awaiting installation by a factory trained service representative. 5.1.2 Unpacking 1. -
Page 15: Installation And Setting To Work
The mains plug should be readily reachable by the operator when the equipment has been installed. 5.2.1.4 Water Supply Prepare 30 litres of clean, filtered tap water to fill the reservoir. 5.2.2 Setting to Work The location of connectors on the KMW3000C is shown in figure 5.2.1. KMW3000C Version 1 USER MANUAL Page 11... -
Page 16: Equipment Required
Ensure that the water connections are made such that the water flows through the X-ray generator and tube in the correct direction. Failure to do this could cause the X-ray generator/tube to overheat. 1. Connect the water pipes between the KMW3000C and the equipment to be cooled. Refer to figure 5.2.2. X-ray generator... -
Page 17: Storage
4. Refit the top covers on the KMW3000C. 5. Open all three red manual valves on the front of the KMW3000C. The red tap should be in line with the water pipe when the valve is open. 6. Plug the KMW3000C mains power cable into the mains supply. -
Page 18: Operating Instructions
3. Switch on the KMW3000C by turning the key switch to the right. NOTE: The KMW3000C performs a flow control procedure, which lasts 2 to 4 seconds. 4. After a few seconds, check that the green light on the front panel is illuminated. -
Page 19: Maintenance Schedule
MAINTENANCE SCHEDULE 7. Maintenance Schedule 7.1 Introduction Maintenance must be performed to ensure that the KMW3000C system continues to operate safely and reliably. This maintenance is detailed in the maintenance schedule given below. WARNING Failure to perform scheduled maintenance tasks properly and at the correct intervals can affect the safety and performance of this system. -
Page 20: Maintenance Instructions
Ensure that the power is switched off at the mains and that the plug has been disconnected from the mains power supply before removing the top of the KMW3000C. Dangerous voltages are present on the KMW3000C’s terminals when the power is on. -
Page 21: Cleaning The Water Filters
When: As required Tools: None Procedure 1. Switch off the KMW3000C. 2. Remove the plug from the electricity socket. 3. Close the manual valve on the tap water inlet. 4. Remove the filter cover. 5. Remove the filter 6. Clean the filter under clean running water. -
Page 22: Trouble Shooting
Remove the air from the closed water illuminated. circuit by restarting the KMW3000C several times (usually 3 to 5 times) until the pump operates continuously. Yellow light is illuminated, The closed water circuit is... -
Page 23: Spares
SPARES 10. Spares Part Number Description CZ-02-00-001-A KMW3000C water filter 25 micron cartridge (5 pieces) CZ_02-00-002-A KMW3000C water filter 50 micron cartridge (5 pieces) KMW3000C Version 1 USER MANUAL Page 19 KMW3000CChiller v1.1.doc... -
Page 24: Additional Information
ADDITIONAL INFORMATION 11. Additional Information 11.1 Drawings Drawing no Title KMW3000C Circuit Diagram KMW3000C Version 1 USER MANUAL Page 20 KMW3000CChiller v1.1.doc... -
Page 25: Ce Conformity Notice
The basis for the criteria has been found in international documentation, particularly in: ISO/IEC Guide 22, 1982, “Information on manufacturer’s declaration of conformity with standards or other technical specifications." Oxford Diffraction's liability under this declaration is limited to that set forth in the current Oxford DiffractionTerms and Conditions of Sale. __________________________________________________________________________________...
