Owner's Manual
VERSION: IM02Z-EN-03
2-in-1
20V Brushless Impact Driver Wrench
Model
IM02Z
WARNING: To reduce the risk of injury, the user must read and understand the
Owner's Manual before using this product. Save these instructions for future reference.
support@mokeneye.com
For Customer Service
