Operation Manual
CD-200
®
Electric Conductivity Detector
READ
CAREFULLY
this operation manual
before using
Shodex
C D - 2 0 0 Electric Conductivity Detector.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Shodex CD-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for SHOKO SCIENTIFIC Shodex CD-200

  • Page 1 121056 Operation Manual CD-200 ® Electric Conductivity Detector READ CAREFULLY this operation manual before using Shodex C D - 2 0 0 Electric Conductivity Detector. ®...
  • Page 2 Copyright 2011-2012, SHOKO SCIENTIFIC CO.,LTD. Printed in Japan. All rights reserved. Contents of this publication may not be reproduced in any form or by any means (including electronic storage and retrieval or translation into a foreign language) without prior agreement and written consent from the copyright owner.
  • Page 3 This operation manual does not expect Shodex CD-200 to be used for clinical or medical purposes. Shodex CD-200 must not be used for such purposes.
  • Page 4 Precautions Thank you for your continued patronage. Observe the following precautions in order to make safe and stable use of the detector. [ Important ! ] Precautions are divided into three groups in this operation manual, depending on the degree of danger. The three groups are This sign is used where failure to follow strictly the instructions !...
  • Page 5 ! Warning immediately and disconnect the power cord. Please consult our local representative in your area or SHOKO SCIENTIFIC. As this detector is readily affected by the ambient temperature, use Caution it in places where there is little wind or change in the ambient temperature.
  • Page 6 Use a thoroughly degassed eluent. It is recommended that a degassing Note device be used to degas the eluent, as it is easy to use and permits continuous degassing. If an eluent is replaced with another eluent, replace all channels of the ion Note chromatograph with new eluent.
  • Page 7: Table Of Contents

    Contents 1 . Accessories 1 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2 . Features 2 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3 . Specifications 3 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4 . Measuring mechanism 4 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-1 Detecting System 4 ・・・・・・・・・・・・・・・・・・・・・・ 4-2 Electric System 5 ・・・・・・・・・・・・・・・・・・・・・・ 5 . Nomenclature and Functions ・・・・・・・・・・・・・・・・・・・・・・ 5-1 Front Panel ・・・・・・・・・・・・・・・・・・・・・・・・・・...
  • Page 8 1. Standard accessories When unpacking, please verify that all the following accessories are included: Details of Accessories 【 】 Name Specification Quantity 3-core cord with a grounding electrode (100V) (1) For voltage of 100 or 120 VAC Power cable Power supply cable set (125 V) (2) For voltage of 220 or 240 VAC Power supply cable set (250 V) Signal cable...
  • Page 9 2. Features Shodex CD-200 is an Electric Conductivity Detector for HPLC and has the following features: 1) Stability The double temperature control system provides for a very fast start up time and excellent stable baseline performance. 2) Safety Solvent leak sensor generates an output signal that stops pump flow in case of an eluent leak within the detector.
  • Page 10 3. Specifications 1) Measuring method : Two-electrode system 2) Measuring limits : 0-600 mS/m 3) Measuring range : 0.0025-5.12/0.025-51.2/0.25-512 mS/m (12 steps) 4) Linearity range : 0-600 mS/m 5) Noise : < 0.0005 mS/m (response; 1 sec) or less (2.5 mM phthalic acid ; pH 4.0 ; 1.5 ml/min.) 6) Response : 0.1, 0.25, 0.5, 1.0, 1.5, 2, 3, 6 seconds 7) Zero adjustment...
  • Page 11: 4 . Measuring Mechanism

    4. Measuring mechanism 4-1 Detecting system This detector has adopted a two-electrode system, and the detection cell and flow line are as shown in Fig. 4-1. In Fig. 4-1, a current proportional to the electrical conductivity of eluent is output from electrode I when an ac voltage is applied to electrode II.
  • Page 12: 4-2 Electric System

    4-2 Electric system The electric system of Shodex CD-200 consists of an oscillator (generating AC voltage), a signal processing circuit, a display/keyboard circuit, and two temperature control circuits. Fig 4-2 shows a block diagram of the electric system. The oscillator applies AC voltage to the cell, generating an electric AC current proportional to the electrical conductivity of the eluent, in the cell electrode.
  • Page 13: 5 . Nomenclature And Functions

    Display □ CD-200 Conductivity Detector □ □ Fig. 5-1 Front Panel of Shodex CD-200 Name of part Function □ Power Switch Press this key once to turn the unit on or off. A 24-digit 2-row character display panel. This is used for □...
  • Page 14: 5-2 Side Panel

    Eluent passing through the flow path is discharged from this port. [OUT] 5-2 Side Panel □ Fig. 5.2 Side panel of Shodex CD-200 Name of part Function In case of internal eluent leak, the eluent will be discharged from □...
  • Page 15: 5-3 Back Panel

    □ T2.0A □ □ □ □ □ □ □ Fig. 5.3 Back panel of Shodex CD-200 Name of part Function Communication port □ USB communication port [COM] Error out terminals A contact signal is sent out through these terminals when □...
  • Page 16 N o . N a m e o f p ar t F u n c t i o n Integrator terminals Signals to the data processing unit are sent out through these □ terminals. The sensitivity of the output signal is 200, 20, or 2 [INTEG.
  • Page 17: 5-4 Display

    5-4 Display The display shows a “Monitor screen” when the detector is started and can be switched to a “Parameter setting screen” when the key or the key is pressed. <Monitor screen> <Parameter setting screen> S 123.4 mS/m 45℃ * PARAMETERS * SETTING <Monitor screen>...
  • Page 18 <Parameter setting screen> To show the currently set parameters in order, press the ▼ key or the ▲ key while the parameter setting screen is displayed. ▼ ▲ * PARAMETERS * SETTING ▼ ▲ PARAMETERS INTEG.RANGE XXX mS/m ▼ ▲ PARAMETERS...
  • Page 19 To change parameters, perform the following procedures: (1) Display the relevant parameter. (2) Press the Enter key. The underlined digits will flash and the parameter can be changed. (3) Press the key or the key to change the parameter with reference to Table 5-1. (4) Press the ENTER key to finalize the parameter.
  • Page 20: 6 . Installation And Connections

    6. Installation and connections 6-1 Power Connection and Grounding Connect the detector to the power source according to the following procedure: 1) Confirm that the power socket into which the detector power cable is plugged is of a 3P type with a grounding terminal. 2) Confirm that the voltage of the power socket into which the detector power cable is plugged is the same as the voltage indicated on the rear panel of the detector.
  • Page 21: 6-2 Signal Cable Connections

    6-2 Signal cable Connections Make correct connections using the provided signal cables in accordance with the figures below. Connect the red wire to the “+” terminal, the white wire to the “-” terminal, and the clear wire to “FG.” (-) driver (-) driver Inserts the end of the lead wire while pressing Then, remove the flat-tip screwdriver to the...
  • Page 22: 6-3 Tube Connections

    6-3 Tube Connections When connecting this detector to a high performance liquid chromatograph through tubes, wash the chromatograph and columns thoroughly with the eluent in use and make sure that the eluent is clean before connecting the tube. Connect the tubes in accordance with the following procedures: □...
  • Page 23: 6-4 Operation Procedures

    6-4 Operation Procedures Use the detector in accordance with the following procedures: 1) Set the parameter on operating parameter-setting screen (Refer to 5-4). 2) Start pumping eluent at the flow rate of analytical condition. 3) Confirm that the detector status is “RD.” 4) Wait until the baseline is stabilized.
  • Page 24 《 alarm 》 When an error occurs, while an alarm is displayed on lower figures of monitors, a beep sounds. The beeping stops by pressing the "CANCEL" key. In addition, when two or more errors occur, only the alarm of highest priority is displayed.
  • Page 25: 7 . Maintenance

    Please consult our local representative in your area or SHOKO SCIENTIFIC CO.,LTD. 7-3 Cleaning of detector exterior When the exterior such as the top cover of the front panel is stained or gets wet for whatever reason, please keep the detector clean and dry by wiping it off with a soft cloth or tissue paper.
  • Page 26: 8 . Troubleshooting

    - 18 - 8. Troubleshooting Problem Possible cause Solution No power 1. Power cable is not 1. Connect power cable to power socket. (Lamps and displays connected. do not go on when 2. Fuse is blown. 2. Replace fuse. (If new fuse blows soon the power button is after replacement, contact agent for turned on.)
  • Page 27: 9 . Weee Instructions

    9. WEEE Instructions WEEE Mark An instrument marked with this mark indicates that it was sold on or after August 13th 2005, and it is covered by Waste Electrical and Electronic Equipment (WEEE) Directive. This WEEE mark means that the instrument must be collected separately from general household waste, according to the regulatory guideline in your area.
  • Page 28 SHOKO SCIENTIFIC CO., LTD. Scientific Instruments Division Factory Department 1-3-3, Azamino-Minami, Aoba-ku, Yokohama City, Kanagawa 225-0012, Japan TEL : +81-(0)45-913-5544 FAX : +81-(0)45-913-5802 Email : tu.tokieda@shoko-sc.co.jp http : www.shoko-sc.co.jp [A SIA & PA CI FI C] [KOREA] Shodex / Shoko Co., Ltd.
