EE Lighting FL-15W40K-K Installation Instructions

IMPORTANT

READ CAREFULLY BEFORE INSTALLING THE FIXTURE. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
This product MUST be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product.
P . roper grounding is required for safety.
.
Fixtures must be wired in accordance with the National Electrical Code and all applicable local codes.

WARNING

RISK OF ELECTRIC SHOCK.
Make sure power supply is OFF before installing or maintaining fixture. No user serviceable parts inside.
Never perform maintenance or cleaning while fixture is energized. Disconnect power and allow fixture to cool before maintaining.
Must be operated with an ambient temperature range of -40° C (-40°F) and 45° C(113° F).

MOUNTING

This product is available to mount by KNUCKLE (
.

INSTALLATION

Knuckle Mount

1. Use screw to open the junction-box.
Water-proof gasket
Cover of junction-box
Screw
5. Lock the junction-box with screw
key.

Yoke Mount

1. Mark the position of the fixing hole
with flood light bracket, then drill the
fixing holes.
5. Rotate the light to proper angle and
fasten the screws.
INSTALLATION INSTRUCTIONS for LED Flood Light
FL-15W40K-K
½" NPT lock nut included)
2. Put the wires of lamp into the
junction-box.
Lamp
Wires
6. Use hex-key to screw off the
hex- screw in knuckle mount.
Hex-key
Enlarged detail
2. Drive in the bolts to the pre-drilled
holes with thread outside, as
indicated in the below pictures.
6. Fasten the screw on both sides with
allen driver.
Energy Efficient Lighting Ltd. | www.eelighting.ca | Tel: 1-855-415-8878
FL-30W40K-K FL-50W40K-Y
and YOKE.
3. Screw up the knuckle mount into
junction-box.
Knuckle mount
7. Adjust the lamp into suitable angle.
3. Make the bracket face tightly to the
wall through the thread.
7. Connect Wires.
4. Use wire-nuts to connect the wires
of lamp and junction-box.
8. Use hex-key to screw up the hex-screw
Installation is then completed.
4. Fasten the screw nut clockwise with
provided hardware wrench.
L
Black
White
N
Green
Black L
White N
Green
Flat Washer
Spring Washer
Screw Nut
R200107-1200
