- Page 1 LED Wall-mounted Mirror Manual...
- Page 2 RoomTec LED mirror adopts three-pin plug, power leads must be connected to ground wire. DO NOT put hard and sharp materials directly against the mirror surface during operation, otherwise it may result in current leakage and even personal injury accident.
- Page 3 LED Wall-mounted Mirror Wiring RoomTec supplies an about 3.6-4.3� long power cable and U.S 3-pin plug for easy connec�on with a wall socket. This product can connect the cord to the wall and be controlled by a wall switch. Cleaning When the mirror has to be cleaned, please switch off the power first.
- Page 4 2 x screws and white nylon screw type plug 4 x spacer Step 1 S�ck spacers on mirror backside to keep the mirror flat, and measure the distance of A(two hooks center distance). Size Measurement A(mm) Model F1A300494E MA04R24TD-OL 82±5mm 96FB004795 MA04R32TD-OL 388±5mm Measurement A 621A004796 MA04R36TD-OL 388±5mm...
- Page 5 LED Wall-mounted Mirror Step 2 Step 3 Place the white nylon plugs into the holes in the wall then Mark two dots on the wall with the length of screw the screws into the plug. A/B then drill holes into those marks. Wall Wall Wall...
- Page 6 Neutral/ white Field Wire Earth/ Green Earth/ Green Input Wire of Mirror Thanks for choosing RoomTec. Web: www.room-tec.com Any query please feel free to email our service team : Service@room-tec.com. Scan the QR code to watch the video of installa�on. www.room-tec.com...
- Page 7 CARE AND MAINTENANCE • Please wipe the mirror with a so� dry cloth or co�on to avoid scratching the mirror. • Please avoid harsh, corrosive, and abrasive cleaners. • Keep dry and avoid damp environments. • We provide a 1-year warranty (Excludes ar�ficial damage and normal wear and tear).
