Page 2: Electrical Safety Instructions
RoomTec LED mirror adopts three-pin plug, power leads must be connected to ground wire. DO NOT put hard and sharp materials directly against the mirror surface during operation, otherwise it may result in current leakage and even personal injury accident. - Page 3 LED Wall-mounted Mirror Wiring Roomtec supply 1m cord and U.S 3-pin plug for easy connection with wall socket. This product all can connect the cord in the wall and be controlled by wall switch. Cleaning When the mirror has to be cleaned, please switch off the power first.
-
Page 4: Installa�On
2 x screws and white nylon screw type plug 4 x spacer Step 1 S�ck spacers on mirror backside to keep the mirror be flat, and measure the distance of A(two hooks center distance). Size Measurement A(mm) Model MA04R32TD-OL 388±5mm Measurement A MA04R36TD-OL 388±5mm MA05R24TD-OL 82±5mm... - Page 5 LED Wall-mounted Mirror Step 3 Step 2 Put the white nylon screw type plug in the holes and Marked 2 dots on wall with length of A, and drill holes. screws in to the plug. Wall Wall Wall Step 4 Hang the mirror to wall.
- Page 6 LED Wall-mounted Mirror Connec�on way ②: Connect the mirror wire with wall switch wire via connector. Live/ Black Live/ Black Neutral/ white Neutral/ white Field Wire Earth/ Green Earth/ Green Input Wire of Mirror www.room-tec.com...
