  • Page 1 AT RETRO RADIO ATA22AA012A...

  • Page 2: Important Safety Instructions. Read Carefully And Keep For Future Reference

    CONGRATULATIONS TIONS Thank you for your purchase the product. Please read this manual carefully and keep it for future reference. IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. Danger! Excessive sound pressure from earphones and headphones can cause hearing loss.
  • Page 3 9. Do not use attachments or accessories other than recommended by the manufacturer or sold with this product. Install in accordance with this user manual. install in bookcases, built-in cabinets or the like. 11. Do not impede ventilation by covering the ventilation openings with items, such as newspapers, table-cloths, curtains, etc.
  • Page 4 20. Before connecting the product to a socket outlet, make sure the voltage indicated on the product corresponds to your local mains. 21. Only use the provided adaptor. 22. The adaptor power plug is used as the disconnect device; the disconnect device shall remain readily operable.
  • Page 5 30. Make sure the batteries are correctly inserted. Observe the polarity (+) plus / (-) negative on the battery and This product is intended for audio pla the housing. Improperly inserted batteries can lead to Radio, FM-Radio or Bluetooth®. An leakage or, in extreme cases, a fire or an explosion.
  • Page 6 Out View...

  • Page 7: Controls And Components

    CONTROLS AND COMPONENTS A. Telescope antenna B. Standby/Mode button C. Preset 1 Menu / Info button E. Preset 2 Alarm button G. Preset 3 Scan button Prev button J. Preset button K. Next button L. Vol +/- knob M. Display Tune / Select knob (rotation scroll up or down for menu option) DC input socket DC 5V Ear phone jack...

  • Page 8: Before First Use

    BEFORE FIRST USE Remove the product and accessories carefully from the original packaging. Inspect the delivery contents for completeness and damages. Should the delivery contents be incomplete or damaged, contact your sales outlet immediately. LANGUAGE The default language of your radio is English. You change the language under SYSTEM SETTING.

  • Page 9: Dab Radio

    DAB RADIO Press Standby/Mode to select DAB mode. Fig. When the radio is switched on for the first time, it will automatically do a full scan of DAB/ DAB+ stations. The list of stations is then stored, eliminating the need for another full scan when the radio is turned on next time.

  • Page 10: Displaying Station Information

    DISPLAYING STATION INFORMATION Select a DAB station. 2. During DAB/DAB+ radio playback, press Menu repeatedly to display the following information (if available): • Ensemble • Frequency • Signal frequency error • Audio state and bit rate • Time • Date •...
  • Page 11 USING THE DAB/DAB+ MENU In DAB mode press and hold Menu for approx. 1 second and the display shows the menu. Use the buttons Prev or Next to browse the menu options. To confirm your selection press Select each time. •...
  • Page 12 Storing FM stations You can store up to 30 preset FM stations. Select the desired FM station. 2. Press and hold the Preset button for one second and then confirm by pushing Select so that <Preset 1 Saved> appears on the display. 3.
  • Page 13 • <All stations> Scans all available stations • <Audio setting> Forced mono & Forced stereo station SYSTEM SETTING Long press Menu in any mode and select Fig. <System Setting> with the buttons Prev or Next. Confirm selection with Select. Following menu options are available: •...
  • Page 14 Display lighting (backlight) Setting> with the keys Prev Select the menu option <System or Next and confirm with the key Select. Select the following options with the keys Prev or Next and press the Select key to confirm the entry and return to the display illumination menu.

  • Page 15: Set Alarm

    SET ALARM Note: Make sure the time is set correctly. Press the Alarm button to access the following options: • [Alarm 1] • [Alarm 2] 2. Press Select to enter the Alarm Wizard. 3. With the [alarm] menu item selected, press the Select 4.

  • Page 16: Alarm Repeat

    8. Use the Prev or Next button to select the [Source] item to set the alarm source and confirm with Select. Use the Prev or Next buttons to select [Digital Radio] (DAB radio), [FM] or [Buzzer] and confirm with Select. If DAB radio or FM radio is selected, the currently selected station is adopted.
  • Page 17 Compatibility This product is compatible with Bluetooth® enabled mobile It also works with devices featuring other Bluetooth® versions that support e.g. Wireless stereo listening • A2DP (Advanced Audio Distribution Profile) Wireless music control • AVRCP (Audio/Video Remote Control Profile) Note •...

  • Page 18: General Setting

    GENERAL SETTING Sender information Briefly press the Menu/Info button each time to display various information such as radio text, station name, time, etc. CLEANING AND CARE • Unplug the adaptor from the socket before cleaning the unit. • Attention! Do not let water penetrate into the unit. •...
  • Page 19 Technical specification Power supply : External power adaptor: Input: 100-240V~, 50/60Hz 0.3AMAX Output: 5V 1.5A Power consumption: 7.5W Battery Powered: 6V 4x1.5V“C”size/LR14 batteries(Not supply) Radio bands: DAB Frequency range: 174.9-239.2 MHz, FM Frequency range: 87.5-108MHz. Bluetooth Frequency range: 2402-2480 MHz Antenna Type: Telescopic Antenna.(For DAB FM) BT Antenna Type: Rectangular wave shape antenna on PCB (Antenna gain: 0dB)

  • Page 20: Declaration Of Conformity

    DECLARATION OF CONFORMITY Hereby,declares that the radio equipment type RETRO RADIO is in compliance with Directive 2014/53/EU. DISPOSAL The crossed-out wheeled bin logo requires the separate collection of waste electric and electronic equipment (WEEE).Electric and electronic equipment may contain dangerous and hazardous substances.Do not dispose of this appliance as unsorted municipal waste.
