MAGNUM C® / MAGNUM C® DR
SERIES
X-RAY GENERATOR
SERVICE MANUAL
PREPARED BY:
APELEM-DMS Group
Parc Scientifique Georges Besse
175, Allée Von Neumann
30035 NIMES CEDEX 1 – France
Tel : 00 33 (0)4 66 29 09 07
Fax : 00 33 (0)4 66 29 71 23
Email : export@apelem.com
Web site : www.apelem.com
DOCUMENT REFERENCE NUMBER: 3Z-40-001 Rev. H
