- Page 1 OPERATOR'S MANUAL VIBRATORY PLATE COMPACTOR SP3410 / SP5013 / SP4518 R e v i s i o n 0 2 1 7 2 2 w w w . t h i r d c o a s t e q u i p m e n t . c o m...
- Page 2 To reduce the risk of injury, all operators and maintenance personnel must read and understand these instructions before operating, changing accessories, or performing maintenance on Third Coast Equipment machines. All possible situations cannot be covered in these instructions. Care must be exercised by everyone using, maintaining, or working near this equipment.
-
Page 3: Table Of Contents
CONTENTS APPLICATIONS Introduction ……………………………………………….…1 • Asphalt Compaction • Earthwork Compaction Applications ……………………………..……….………….1 • Paverstones • Granular & Mixed Soil Functions and Controls……………………..………………1 • Utility & Trench Work • Gravel & Aggregate Accessories………………………………………………….1 Hazards and Risks .……………………………………...1-3 Safety Labels..………………………………………..4 FUNCTIONS AND CONTROLS Operation ………………………………………………..5 Extended Storage ..........……..5 The motor is controlled by an ON/OFF switch or... - Page 4 ! MECHANICAL HAZARDS DO NOT operate the machine unless all protective guards are in place. KEEP handles and feet clear of rotating and moving parts as they will cause injury if contacted. ENSURE that the motor operation switch is in the OFF position and the spark plug ignition lead is disconnected before removing the guards or making adjustments.
- Page 5 WEAR an approved hearing protection device to limit noise exposure. As required by Occupational Safety and Health Administration regulations. PROTECTIVE CLOTHING ALWAYS wear proper protective clothing when operating this equipment. Hearing protection, respiratory protection, shatterproof eye protection, steel-toe boots, and other PPE as required by job or city regulations. Eye ! ADDITIONAL HAZARDS Slip/Trip/Fall is a major cause of serious injury or death.
-
Page 6: Safety Labels
SAFETY LABELS Third Coast Equipment machines use international pictorial labels where required. These labels are described below: Label Meaning This model-in label contains important safety and operating information. If it becomes illegible, the cover must be replaced. Reger to the Parts Manual for ordering information. -
Page 7: Operation
OPERATION Pre-start-up inspection The following pre-start-up inspection must be performed before the start of each work session or after every four hours of use. If any fault is discovered, the machine should be deemed not operational until the fault is rectified. 1. -
Page 8: Care And Preventive Maintenance
CARE AND PREVENTIVE MAINTENANCE Check the oil level in the motor crankcase daily. Inspect the rubber anti vibration mounts for wear or deterioration. If the optional water tank is equipped, inspect the water hose and its connections to ensure that they do not leak. Clean the underside of the plate regularly to prevent a build up of material. - Page 9 Changing Vibrator Oil / Vibrator Grease When changing the vibrator oil, remove the drain plug located at the bottom-right of the vibrator, and simply tip the compactor to drain the oil. Note that the oil will drain more easily while it is hot. For SP series compactors, replace the oil with 200ML of 10W-30 motor oil;...
-
Page 10: Specifications
SPECIFICATIONS Weight SP3410 SP5013 SP4518 Operating Weight 143 lb 183 lb 212 lb Performance Data Base Plate Material Cast Iron Cast Iron Cast Iron Centrifugal Force 2248 lbf 2923 lbf 4046 lbf Vibration Frequency 5400 vpm 5500 vpm 5400 vpm... -
Page 11: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSES SOLUTION Engine speed too low? Set engine speed to correct RPM. Clutch slips? Check or replace clutch. Travel speed too low, and vibration is V-belt slips? Adjust or replace V-belt. reduced. Excessive oil in vibration? Drain excess oil and fill to proper level. Malfunction in vibrator housing? Check eccentric, gears and counter weights. -
Page 12: Warranty
Preventative maintenance and routine service are essential to the long life of your plate compactor. Please refer to your local Third Coast Equipment dealer for all OEM spare parts and service needs. For your convenience we have provided this space to record relevant data about your plate compactor.
