Page 1
INSTALLATION INSTRUCTIONS SERIES 8000 | SLIDING DOOR SYSTEM w w w . a l l w e a t h e r a a . c o m 7 7 7 A l d r i d g e R o a d | V a c a v i l l e , C A 9 5 6 8 8 8 0 0 .
Product was checked and free of damage Any damage or incorrectness was reported immediately to All Weather or the dealer where the product was purchased Product was stored in a dry safe place where it could avoid damage ...
Other IMPORTANT All Weather recommends that installers return to site and perform a final check of installation. Namely that the header has not sagged under structure settlement and/or weight and necessary adjustments have been made prior to installation of exterior siding/stucco and interior finishes.
Page 4
All visible defects must be reported before installation and finishing. These instructions are the property of All Weather Architectural Aluminum and may not be duplicated, altered or distributed for any purpose whatsoever without the express written permission of All Weather.
Page 5
The frame should be checked for square and twist. Assembly screws are provided by All Weather. Be sure to clean any metal shavings from the head track to avoid damage to the rollers.
Page 6
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS PROVIDED ASSEMBLY FASTENERS & PARTS PART PICTURE DESCRIPTION PURPOSE #10-12 x 3" Square Drive To secure the keeper onto the Pan Head Grade 18-8 Type door jamb and building frame A Point Stainless Steel Sheet through 4 slotted holes.
Page 7
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS PROVIDED ASSEMBLY FASTENERS & PARTS PART PICTURE DESCRIPTION PURPOSE To provide the panel hooks on panels channels to lock into Keeper to keep the panel secured into the frame. To cover and protect the track 1.8"...
Each installation job has its unique set of challenges and circumstances. Because of that, the provided set of installation instructions for All Weather Architectural Aluminum products is meant only to serve as a set of standardized guidelines and NOT necessarily a strict manual to follow regardless of the situation.
Page 9
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 5. Prepare rough opening by checking diagonal dimension of opening to verify square and apply water resistant barrier as shown in figure 2a. Use steps A through C for applying water resistant barrier. Use step D for installation of sill pan. A.
Page 10
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 7. Make sure that each corner joint of the frame has sufficient sealant. Apply additional sealant to the corner joints as necessary to ensure a watertight seal as shown in figure 3. Head Part #5 Head Part #5 Head Part #5...
Page 11
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 10. Apply a continuous bead of sealant across the entire sill of the opening where the door frame will sit as shown in figure 6a and insert door frame into the opening as shown in figure 6b.(Sealant should conform to AAMA 802.3-16 and 803.3-16). After frame is installed, seal all 4 corners per detail 6b and 6c.
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 12. Apply backer rod and compatible sealant to the interior joint between the frame and the rough opening. Backer Rod w/ Sealant Backer Rod w/ Sealant Backer Rod w/ Sealant FIGURE 8A FIGURE 8B PANEL INSTALLATION Before installing panels, make sure the fixed panel holder is where the fixed panel will be installed.
Page 13
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 14. Temporarily adjust the panel upward by lifting the panel and turning the adjustment screw shown in figure 11a clockwise as shown in figure 11b until the rollers regain contact with the track. It is important to physically lift the panel while adusting upward so that the adjustment screw does not strip due to the weight of the panel.
Page 14
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 16. After the final roller adjustments, install the keeper (Part #8) into the lock side jamb (Part #6) by aligning with the lockset hooks on the panel and marking the location of the keeper’s four screw holes onto the jamb. Next, pre-drill holes in the jamb at the marked locations using a size ¹⁄...
Page 15
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 18. Install the threshold (Part #10) into the exterior sill track (Part #7) and install the smallest trim cap (Part #9) into the head exterior track (Part #5) shown in figures 14b and 14c. Trim Cap Part #9 Threshold Part #10 Trim Cap Part #9...
Page 16
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS FOR AN OXXO DOOR 20. Install the threshold (Part #10) into the exterior sill track (Part #7) shown in figure 15a. Threshold Part #10 Threshold Part #10 Threshold Part #10 FIGURE 15A 21.
Page 17
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS FOR AN OXX OR XXO DOOR 23. Install the longest trim cap piece (Part #9) into the exterior and center jamb track (Part #6) shown in figure 16a. Trim Cap Part #9 Trim Cap Part #9 Trim Cap Part #9 FIGURE 16A...
Page 18
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS 25. Install the 2 remaining trim caps (Part #9) into the interior jamb tracks (Part #6) shown in figure 16d. Trim Cap Part #9 Trim Cap Part #9 Trim Cap Part #9 Trim Cap Part #9 FIGURE 16D PULL HANDLE INSTALLATION...
Page 19
SERIES 8000 I SLIDING DOOR SYSTEM INSTALLATION INSTRUCTIONS APPENDIX A: FALSE JAMB INSTALLATION 1. After the operable panel is installed, install the left fixed panel (for OXO Left) or right fixed panel (for OXO right) per Step 15 above. Screws Part #3 Use 2 screws (Part #3 Pg.
