skoopia 21Z10S Technical Manual

Full-hd 10x zoom block camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Full-HD 10x Zoom Block Camera Technical Manual
21Z10S
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21Z10S and is the answer not in the manual?

Questions and answers

Related Manuals for skoopia 21Z10S

Summary of Contents for skoopia 21Z10S

  • Page 1 Full-HD 10x Zoom Block Camera Technical Manual 21Z10S...
  • Page 2 Full-HD 10x Zoom Block Camera Technical Manual Revision History Version Date Description Remarks 1.10 Update Sep 29, 2020 1.00 First Release CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. ACCESSORIES SOLD DEPARATELY .

  • Page 3: Safety Instructions

    Full-HD 10x Zoom Block Camera Technical Manual 1. SAFETY INSTRUCTIONS Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save this instructions for later use. Cleaning Unplug this appliance form wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
  • Page 4 Full-HD 10x Zoom Block Camera Technical Manual 2. PRECAUTIONS  Do not use the camera in extreme temperature conditions.  Do not use or store the camera in humid environment It may cause poor image quality.  Do not use the camera in unstable lighting conditions. Inconsistent lighting or flickering may cause poor image.
  • Page 5 Full-HD 10x Zoom Block Camera Technical Manual INDEX 1. SAFETY INSTRUCTIONS 2. PRECAUTIONS 3. FEATURES 4. SPECIFICATION 5. OPERATING CAMERA 5.1. Camera OSD menu 5.2. WHITE BALANCE 5.3. EXPOSURE 5.4. FOCUS 5.5. BACK LIGHT 5.6. IMAGE CONTROL 5.7. DISPLAY CONTROL 5.8.
  • Page 6 Full-HD 10x Zoom Block Camera Technical Manual APPENDIX A APPENDIX B 3. FEATURES  1/2.8 inch sony STARVIS CMOS image sensor (approx. 2.1 million effective pixels) Progressive scan  WDR (Wide Dynamic Rage) Function  Video signals output HD LVDS : Digital ITU-R BT.1120 - YcbCr4:2:2 16bits Analog : SD CVBS (NTSC/ PAL), 1.0Vp-p 75Ω, Composite HD SDI : SMPTE 292M(1.485Gbps)

  • Page 7: Specification

    Full-HD 10x Zoom Block Camera Technical Manual 4. SPECIFICATION 21Z10S SPECIFICATIONS Image Sensor 1/2.8” Progressive CMOS (Approx. 2.1 mega) Scanning System 16:9 Progressive Sync. System Internal Sensor Effective Pixel 1920(H) x 1080(V) Min. Illumination 0.1Lux (Day), 0.01Lux (Night), 0.001Lux(DSS on)

  • Page 8: Operating Camera

    Full-HD 10x Zoom Block Camera Technical Manual Interface 8bits data, 1 stop bit, no parity, 2400~115200bps Operation -20℃ ~ 60℃ Temperature Power Input 12VDC (7V to 15VDC) General Power consumption Max 5W (3.2W Lens inactive, 3.9W Lens active) Mass Approx. 140g (5.0 oz.) Dimensions 67(D) x 43.6(W) X 45.3(H) mm 5.
  • Page 9 Full-HD 10x Zoom Block Camera Technical Manual LEVEL 0~20 BLACK MASK OFF/ ON WIDTH 0~48 HEIGHT 0~33 MOVE HOR 0~48 MOVE VER 0~33 DISPLAY OFF/ ON SPOT AE WIDTH 0~48 HEIGHT 0~33 MOVE HOR 0~48 MOVE VER 0~33 OFF/ ON DWDR STRENGTH 0 ~ 16...

  • Page 10: White Balance

    Full-HD 10x Zoom Block Camera Technical Manual TYPE SQUARE/ POLYGON MASK NO. MASK1 ~ MASK8 DISPLAY OFF/ ON COLOR BLK/WHT/GRN/BLE/RED/CYAN/MAG/YEL/G RAY1~6,MOSAIC POLY SELECT L-TOP/ R-TOP/ L-BOT/ R-BOT POSITION 0~255 POSITION 0~216 WIDTH 0~120 HEIGHT 0~68 1 ~ 4 MOTION AREA OFF/ ON AREA ACTIVE OFF/ ON...
  • Page 11 Full-HD 10x Zoom Block Camera Technical Manual PUSH WB : Color Temperature is manually adjustable to adjusting value. The One Push White Balance mode is a fixed white balance mode that may be automatically readjusted only at One Push Trigger, while the camera is directed at a piece of white paper to obtain the optimum state under current illumination.
  • Page 12 Full-HD 10x Zoom Block Camera Technical Manual 5.4. FOCUS The camera employs a 30x optical zoom lens combined with a 12x digital zoom function. This camera allows you to zoom up to 360×. Optical 10x, f = 4.7 mm to 47 mm (F 1.6 to F 3.0) Digital Zoom 12x : enlarges of the subject 7 levels of zoom speed FOCUS MODE :...

  • Page 13: Image Control

    Full-HD 10x Zoom Block Camera Technical Manual removing fog, clouds, smoke, and dust. 5.6. IMAGE CONTROL COLOR LEVEL Color level is the colorfulness of a color relative to its own brightness. SHARPNESS As you increase this value, the picture outline becomes stronger and clearer. Adjust this value appropriately depending on the sharpness of the picture.

  • Page 14: System Setup

    Full-HD 10x Zoom Block Camera Technical Manual OSD character camera name settings.. ZOOM MAGNIFICATION Display the Zoom scale. PRIVACY It is possible to set the size of the area and a video Mask. MOTION Video zone settings and sensitivity can be set. IMAGE STABILIZER This function reduces image blurring associated with the motion of a camera.

  • Page 15: Video Output

    Full-HD 10x Zoom Block Camera Technical Manual 6. Video Output 6.1. Video Mode Video output : 1080p - 2200x1125@30/60 fps, 2640x1125@25/50 fps 2200x1125@29.97/59.94 fps (optional) 1080i - 2200x562(563)@60 fps, 2640x562(563)@50 fps 2200x562(563)@59.94 fps (optional) 720p - 1650x750@60 fps, 1980x750@50 fps, 3300x750@30 fps, 3960x750@25 fps 1650x750@59.94 fps (optional), 3300x750@29.97 fps (optional) Pixel clock : 74.25MHz, 148.5MHz 74.25/1.001 MHz (optional), 148.5/1.001 MHz (optional)
  • Page 16 Full-HD 10x Zoom Block Camera Technical Manual 6.2. Output Timing Chart(1920x1080p@30/60/29.97/59.94)
  • Page 17 Full-HD 10x Zoom Block Camera Technical Manual 6.3. Output Timing Chart(1920x1080p@25/50)
  • Page 18 Full-HD 10x Zoom Block Camera Technical Manual 6.4. Output Timing Chart(1920x1080i@60/59.94)
  • Page 19 Full-HD 10x Zoom Block Camera Technical Manual 6.5. Output Timing Chart(1920x1080i@50)
  • Page 20 Full-HD 10x Zoom Block Camera Technical Manual 6.6. Output Timing Chart(1280x720p@60/59.94)
  • Page 21 Full-HD 10x Zoom Block Camera Technical Manual 6.7. Output Timing Chart(1280x720p@50)
  • Page 22 Full-HD 10x Zoom Block Camera Technical Manual 6.8. Output Timing Chart(1280x720p@30/29.97)
  • Page 23 Full-HD 10x Zoom Block Camera Technical Manual 6.9. Output Timing Chart(1280x720p@25)
  • Page 24 Full-HD 10x Zoom Block Camera Technical Manual 6.10. Video Data Start/Stop Format EAV and SAV CODE (MSB (LSB) Preamble Status word EAV and SAV Sequence The EAV and SAV sequences are shown in Table A. The status word is defined as: F = “0”...

  • Page 25: Camera Interface

    Full-HD 10x Zoom Block Camera Technical Manual 7. Camera Interface 7.1. Camera Interface B connector: Connector – KYOCERA 00-6200-509-130-000+ ( 1.0mm pitch 9pin, Bottom Contact 1.0mm pitch FFC/FPC Cable (9pin) Name Level RXD (UART in- CMOS 5V (High Min. put) 2.5V) TXD (UART out- CMOS 5V (High Min.
  • Page 26 Full-HD 10x Zoom Block Camera Technical Manual C connector: HD-SDI video output 21Z10S Connector –MMCX(micro-miniature coaxial) Female Jack special internal wiring Note: to connect the MMCX, one needs to remove the top of the casing, as the connector is facing the optics to allow for internal cabling within housing...

  • Page 27: Lvds Interface

    Full-HD 10x Zoom Block Camera Technical Manual 7.2. LVDS Interface LVDS Single Output only LVDS Single/Dual Output...
  • Page 28 Full-HD 10x Zoom Block Camera Technical Manual LVDS Data Mapping Single Mode (16bits) Dual Mode (16bits)
  • Page 29 Full-HD 10x Zoom Block Camera Technical Manual 7.3. Application of recommended circuit Camera Reception (Only for Digital Output Model) LVDS Rx(THC63LVD104C) circuit (Single Output Only)
  • Page 30 Full-HD 10x Zoom Block Camera Technical Manual LVDS Rx(THC63LVD1024) circuit (Single output)
  • Page 31 Full-HD 10x Zoom Block Camera Technical Manual LVDS Rx(THC63LVD1024) circuit (Dual output) 7.4. Key Application recommended circuit...
  • Page 32 Full-HD 10x Zoom Block Camera Technical Manual 8. Dimensions Front Back Bottom Left Right...

  • Page 33: Visca Protocol

    Full-HD 10x Zoom Block Camera Technical Manual APPENDIX A VISCA Protocol 9600, 19200, 38400, 115200bps 8bit data 1stop bit none parity 　 　 Command Packet (3~ 16bytes) Comments 8X: 0x80+Sender addr(H nibble)+Recv addr(L nib- ble) addr(1~7) Inquiry 　 8X QQ RR ... FF QQ: 01-Command/ 00-Inquiry RR: Category 00(Interface) 04(cam1) 06(Pan/Tilt) 07(cam2)
  • Page 34 Full-HD 10x Zoom Block Camera Technical Manual IF_Clear 8X 01 00 01FF X0 50 FF 　 IF_Clear (broad- 88 01 00 01 FF 88 01 00 01 FF 　 cast) 　 　 Inquiry Packet Reply Packet CAM_VersionInq 8X 09 00 02 FF Y0 50 GG GG HH HH JJ JJ KK FF GGGG = Vender ID 002B:...
  • Page 35 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Set Command Packet Comments AddressSet Broadcast 88 30 01 FF Address setting IF_Clear Broadcast 88 01 00 01 FF I/F Clear 　 CommandCancel 8x 2p FF p: Socket No. (=1 or 2) CAM_Power 8x 01 04 00 02 FF Power ON/OFF...
  • Page 36 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Set Command Packet Comments CAM_Focus Stop 8x 01 04 08 00 FF 　 　 Far (Standard) 8x 01 04 08 02 FF 　 　 Near (Standard) 8x 01 04 08 03 FF 　...
  • Page 37 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Set Command Packet Comments CAM_WB Auto 8x 01 04 35 00 FF Normal Auto 　 Indoor 8x 01 04 35 01 FF Indoor mode 　 Outdoor 8x 01 04 35 02 FF Outdoor mode 　...
  • Page 38 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Set Command Packet Comments CAM_Gain Reset 8x 01 04 0C 00 FF Gain Setting 　 8x 01 04 0C 02 FF 　 　 Down 8x 01 04 0C 03 FF 　...
  • Page 39 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Packet Comments CAM_Aperture Reset 8x 01 04 02 00 FF Aperture Control 　 　 8x 01 04 02 02 FF 　 Down 8x 01 04 02 03 FF 　 　 Direct 8x 01 04 42 00 00 0p 0q FF pq: Aperture Gain (0 to 0x14) (refer Table)
  • Page 40 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Packet Comments CAM_Stabilizer 8x 01 04 34 02 FF Stabilizer ON/OFF/HOLD 　 　 8x 01 04 34 03 FF 　 Hold 8x 01 04 34 00 FF 　 CAM_Memory Reset 8x 01 04 3F 00 0p FF p: Memory Number (=0 to 6) (Preset pos)
  • Page 41 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Packet Comments 8x 01 04 75 02 FF Muting ON/OFF CAM_Mute 8x 01 04 75 03 FF 　 　 On/Off 8x 01 04 75 10 FF mm: Mask Settings 8x 01 04 76 mm nn 0r 0r 0s 0s nn: 00-Modify, 01-New SetMask rr: W...
  • Page 42 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Set Command Packet Comments CAM_MD 8x 01 04 1B 02 FF Motion Detection On/Off 　 8x 01 04 1B 03 FF 　 　 Function Set 8x 01 04 1C 0m 0n 0p 0q 0r 0s m: Display mode 0-Off 1-On 　...
  • Page 43 Full-HD 10x Zoom Block Camera Technical Manual Command Set Command Set Command Packet Comments mm: First byte from the top threshold value nn: Second byte from the top threshold value pp: Third byte from the top threshold value qq: Color specification for high-intensity CAM_ rr: Color specification for low-intensity Parameter Set...
  • Page 44 Full-HD 10x Zoom Block Camera Technical Manual Register Set Command Set Command Packet Comments 　 8x 01 04 24 00 00 0p FF p: 0-9600 　 　 1-19200 BaudRate 　 　 2-38400 　 　 3-115200 pp: 1-1080i@59.94 (optional) 2-1080i@60 4-1080i@50 6-1080p@29.97 (optional) 7-1080p@30 8-1080p@25...
  • Page 45 Full-HD 10x Zoom Block Camera Technical Manual Register Set Command Set Command Packet Comments Key Input enable 　 8x 01 04 24 70 00 0p FF p: 0-Key input disable 1-enable Wide limit 　 8x 01 04 24 50 0p 0p FF pp: 0~FF refer Table Tele limit 　...
  • Page 46 Full-HD 10x Zoom Block Camera Technical Manual Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments CAM_PowerInq 8x 09 04 00 FF y0 50 02 FF 　 　 y0 50 03 FF Off(Standby) CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqrs: Zoom Position (refer Table) CAM_DZoomModeInq 8x 09 04 06 FF...
  • Page 47 Full-HD 10x Zoom Block Camera Technical Manual Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments CAM_AEModeInq 8x 09 04 39 FF y0 50 00 FF Full Auto 　 　 y0 50 03 FF Manual 　 　 y0 50 0A FF Shutter Priority 　...
  • Page 48 Full-HD 10x Zoom Block Camera Technical Manual Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments CAM_ApertureInq 8x 09 04 42 FF y0 50 00 00 0p 0q FF pq: Aperture Gain CAM_HRModeInq 8x 09 04 52 FF y0 50 02 FF On (Hi-Resolution) 　...
  • Page 49 Full-HD 10x Zoom Block Camera Technical Manual Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments StabilizerModeInq 8x 09 04 34 FF y0 50 02 FF 　 　 y0 50 03 FF 　 　 y0 50 00 FF Hold TitleDisplayModeInq 8x 09 04 74 FF y0 50 02 FF 　...
  • Page 50 Full-HD 10x Zoom Block Camera Technical Manual Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments MDFunctionInq 8x 09 04 1C FF y0 50 0m 0n 0p 0q 0r 0s FF m: Display mode 0-Off 1-On n: Detection Frame Set bit0-Frame0 bit1-Frame1 　...
  • Page 51 Full-HD 10x Zoom Block Camera Technical Manual Inquiry Command 　: Register 　 Inquiry Command Command Packet Inquiry Packet Comments 8x 09 04 24 00 FF y0 50 00 0p FF p: 0-9600 　 　 1-19200 BaudRate 　 　 2-38400 　 　...
  • Page 52 Full-HD 10x Zoom Block Camera Technical Manual Inquiry Command 　: Register 　 Inquiry Command Command Packet Inquiry Packet Comments Key Input enable 8x 09 04 24 70 FF y0 50 00 0p FF p: 0-Key input disable 1-enable Wide limit 8x 09 04 24 50 FF y0 50 0p 0p FF pp: 0~FF refer Table...
  • Page 53 Full-HD 10x Zoom Block Camera Technical Manual Block Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments pppp: Zoom position qq: Near limit 0-30Cm, 1-1M, 2-1.5M, 3-2M, 4-3M, 5-5M, 6-10M rrrr: Focus position hh: [5]DzoomMode 0-combine 1-seperate [4:3] 0-Nor 1-Interval 2-ztrg Lens Control y0 50 0p 0p 0p 0p 0q 0q 0r 0r 0r 8x 09 7E 7E 00 FF...
  • Page 54 Full-HD 10x Zoom Block Camera Technical Manual Block Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments p: [3]Auto ICR alarm 0-off 1-on [2]Auto ICR 0-off 1-on [1]0 [0]power 0-off 1-on qq: [6]Stabilizer 0-off 1-on [5]Stabilizer Hold 0-off 1-Hold [4]ICR 0-off 1-on [3]Freeze 0-off 1-on [2]LR Reverse 0-off 1-on rr: [5]Privacy zone 0-off 1-on...
  • Page 55 Full-HD 10x Zoom Block Camera Technical Manual Block Inquiry Command Inquiry Command Command Packet Inquiry Packet Comments pp: Dzoom position qq: AF activation time rr: AF Interval time s: SpotAE position X t: SpotAE position Y u: [2]MD 0-off 1-on [1]Alarm 0-off 1-on [0]flip 0-off 1-on y0 50 0p 0p 0q 0q 0r 0r 0s 0t 0u vv hh...
  • Page 56 Full-HD 10x Zoom Block Camera Technical Manual TABLE. Shutter Speed IRIS Value NTSC Value F no. 1/10000 (1/20000) 1/10000 (1/20000) F1.6 1/6000 (1/12000) 1/6000 (1/12000) 1/4000 (1/8000) 1/3500 (1/7000) F2.4 1/3000 (1/6000) 1/2500 (1/5000) F2.8 1/2000 (1/4000) 1/1750 (1/3500) F3.4 1/1500 (1/3000) 1/1250 (1/2500) 1/1000 (1/2000)
  • Page 57 Full-HD 10x Zoom Block Camera Technical Manual Gain Brightness Value 　 Value IRIS GAIN +60 dB 　 F1.6 +60 dB +55.7 dB 　 F1.6 +55.7 dB +51.4 dB 　 F1.6 +51.4 dB 　 +47.1 dB F1.6 +47.1 dB +42.9 dB 　...
  • Page 58 Full-HD 10x Zoom Block Camera Technical Manual Position Limit Setting Zoom Ratio Zoom Ratio Wide Limit Tele Limit Data Value Optical Zoom ×1 0000 x1.0 　 ×2 17C5 　 x1.03 　 ×3 22AD 　 x1.05 x9.6 　 　 ×4 2990 x1.08 　...
  • Page 59 Full-HD 10x Zoom Block Camera Technical Manual Focus Near Limit Position Near Limit 2000 Over Inf 3000 4000 6000 8000 C000 D000 30cm...
  • Page 60 Full-HD 10x Zoom Block Camera Technical Manual APPENDIX B PELCO Protocol PELCO “D” Byte Format Command Message Command Data BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6 BYTE 7 Zoom Tele 0xFF CamID 0x00 0x20 0x00 0x00 Checksu Zoom Wide...
