OPERATORS MANUAL – PARTS LIST
EVERY PERSON OPERATING THIS MACHINE MUST READ THIS MANUAL INCLUDING
ALL SAFETY INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
PROPER GUARDS AND SAFETY DEVICES ARE INSTALLED FOR YOUR SAFETY.
DO NOT OPERATE THE MACHINE UNLESS ALL GUARDS ARE IN PLACE.
COPYRIGHT © 2020 BY
HOLLYMATIC CORPORATION
SEPTEMBER, 2020
l
2
8
,
5
l
2
8
,
5
5
,
8
8
S
5
,
8
8
S
HOLLYMATIC CORPORATION
600 E. PLAINFIELD ROAD
COUNTRYSIDE, ILLINOIS 60525
PHONE: 708-579-3700
FAX: 708-579-1057
t
u
f
f
e
r
s
t
u
f
f
e
r
s
Advertisement
Table of Contents
Related Manuals for Hollymatic 28
Summary of Contents for Hollymatic 28
- Page 1 ALL SAFETY INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS MACHINE. PROPER GUARDS AND SAFETY DEVICES ARE INSTALLED FOR YOUR SAFETY. DO NOT OPERATE THE MACHINE UNLESS ALL GUARDS ARE IN PLACE. COPYRIGHT © 2020 BY HOLLYMATIC CORPORATION HOLLYMATIC CORPORATION 600 E. PLAINFIELD ROAD COUNTRYSIDE, ILLINOIS 60525...
- Page 2 NEW EQUIPMENT COVERED BY THE DIRECTIVE 1. CEM 2004 / 108 / CE 2. BT 2006 / 95 / CE 3. MACHINE 2006 / 42 / CE CERTIFICATE OF COMPLIANCE rules of the European Community.
-
Page 3: Table Of Contents
Table of contents 1 Introduction and standards ................. 1 2 Installation and Electrical connection ............2 3 Features and specifications ................ 3 4 Getting started ....................4 5 Good using ....................4 6 Cleaning ......................6 7 Maintenance ....................7 8 Accessories .................... -
Page 4: Introduction And Standards
1 Introduction and standards Fillers VILLA 13, 25 and 40L allow the filling of any kind of flesh mix mainly for production of sausages. STANDARDS These devices meet the requirements of the decrees and safety standards. General hygiene and safety laid down in Articles R233-84 R233-106, introduced in the Labour Decree No. -
Page 5: Installation And Electrical Connection
2 Installation and Electrical connection Position the machine on a stable and solid work surface. ELECTRICAL CONNECTION The electrical connection must be performed by qualified personnel and be conducted in compliance with safety standards in force. The line of the power supply must be carried out using a cable section adapted to the power of the machine and must include three phase conductors and a grounding conductor (voltage machine 400v, 50 Hz) or two phase... -
Page 6: Features And Specifications
3 Features and specifications SIZES VILLA 13 VILLA 25 VILLA 40 1103 1210 1014 1148 1270... -
Page 7: Getting Started
TECHNICAL DETAILS VILLA 13 VILLA 25 VILLA 40 Cylinder capacity Litres Cylinder capacity ± Kg 10kg 20kg 35kg for meat weight 1HP- 1,5HP - MONO 0,75KW 1,1KW Engin Power 0,75HP- 1HP - 0,75 1,5HP - 0,55KW 1,1KW Oil tank capacity Litres Lids / piston Matière... -
Page 8: Good Using
5 Good using Do not lay down the machine Work the paste to a minimum temperature of 10°C. BEFORE each using, remove the piston to lubricate the joint. BEFORE each use, the piston in the down position, oil the cylidner pfor a proper funcitoning of the joint. -
Page 9: Cleaning
6 Cleaning AFTER EACH USE: 1- Put the piston in upper position. 2- Using the key screwdriver, loosen the set screw of the piston 3- Turn the key to extract the piston 4 - Clean the cylinder by hand with warm water. -
Page 10: Maintenance
Inner diameter 12 mm Outer diameter 14 mm Length 230 mm Cornet No.2 stainless steel Inner diameter 20 mm Outer diameter 22 mm Length 236 mm Cornet No.3 stainless steel Inner diameter 28 mm Outer diameter 30 mm Length 236 mm... -
Page 11: Warranty
9 Warranty As a manufacturer, we guarantee our equipment for 6 months against any manufacturing defect. IMPORTANT : Electrical parts are excluded from the warranty. WARRANTY LIMITS : The warranty applies only to the purchaser and not to third parties to which the material could be sold. Our warranty is limited to replacement or repair at no cost recognized by us defective parts. -
Page 12: Electrical Schemes Tri Phases
10 Electrical schemes Tri phases... -
Page 13: Electrical Schemes Single Phase
11 Electrical schemes single phase... -
Page 14: Exploded Scheme
12 Exploded scheme Exploded view :... -
Page 15: Detail (A)
Detail (A) :... -
Page 16: Detail (B)
Detail (B) :... -
Page 17: Nomenclature
13 Nomenclature NOMENCLATURE FILLERS MODEL 28 MODEL 55 MODEL 88 DESIGNATION REPERE VILLA 13 VILLA 25 VILLA 40 ACCOUPELEMENT PUMP 1505 1505 1505 COUPLING MOTOR 1505 1505 1505 PEDAL STEEL SHAFT 1547 (1242-0014) 1547 (1242-0014) 1547 (1242-0014) LID RING DELRIN... - Page 18 MODEL 28 MODEL 55 MODEL 88 DESIGNATION REPERE VILLA 13 VILLA 25 VILLA 40 RANGE DISTRIBUTOR STUD STAINLESS STEEL COVER 1544 1545 1546 LIP SEAL CYLINDER BOTTOM 1517 (1242-0017) 343 (1245-0012) 369 (1248-0013) SEAL PASSAGE OF PARTITION SEAL COVER 1523 (1242-0010)
- Page 19 HOLLYMATIC CORPORATION 600 E. PLAINFIELD ROAD COUNTRYSIDE, IL 60525 Telephone: (708) 579‐3700 ...
