Doc.-no.:
AC20/AC30 V1/01/05
Revision:
–
Date:
January 2006
Prior to starting up the Ratiomed AC 20/AC 30, read these
operating instructions carefully and store them near the unit for later reference!
Operating Instructions
Ratiomed AC 20/AC 30
Mains-operated
Suction Units
0482
GmbH & Co. KG
Am Schornacker 30
D-46485 Wesel
Tel.: +49 (0) 281 - 98990
Fax: +49 (0) 281 - 989950
www.megro.de
E-Mail: info@megro.de
Advertisement
Table of Contents
Related Manuals for Megro Ratiomed AC 20
Summary of Contents for Megro Ratiomed AC 20
- Page 1 Revision: – Ratiomed AC 20/AC 30 Date: January 2006 Prior to starting up the Ratiomed AC 20/AC 30, read these operating instructions carefully and store them near the unit for later reference! Mains-operated Suction Units 0482 GmbH & Co. KG...
-
Page 2: Table Of Contents
© Reproduction of this document, even in part, is not permitted. Contents shall not be reproduced, duplicated or given to third party, either in full or in part, without the written authorisation of megro GmbH. In case of ambiguity with regard to textual contents or translations, only the German original editions are valid. -
Page 3: General
– see chapter 1.8. Delivery Explanation of symbols „Caution: pay attention to operating The Ratiomed AC 20/AC 30 was subjected to a thorough instructions“ acc. to DIN EN 980:2003. quality control and carefully packed before shipment. This symbol accentuates important Nevertheless, please immediately compare the contents information in the operating instructions. -
Page 4: For Your Safety - Caution
Opening the unit may only be performed by qualified The Ratiomed AC 20/AC 30 may only be applied by personnel authorized by megro. Only use original persons who have been trained in its operation acc. to accessories and spare parts. -
Page 5: Application Range
Portable and mobile HF communication facilities can influence medical electrical equipment. T201 The Ratiomed AC 20/AC 30 is intended for use in the electromagnetic environment specified below. The customer or user of the Ratiomed AC 20/AC 30 should ensure that it is used in such an environment. - Page 6 T202 The Ratiomed AC 20/AC 30 is intended for use in the electromagnetic environment specified below. The customer or user of the Ratiomed AC 20/AC 30 should ensure that it is used in such an environment. Immunity Test IEC 60601-Test Level...
- Page 7 To determine the electromagnetic environment in regard to stationary transmitters, a study of the location is to be considered. If the measured field strength at the location where the Ratiomed AC 20/AC 30 is used exceeds the above compliance level, the Ratiomed AC 20/AC 30 is to be observed to verify the intended use.
-
Page 8: Warranty
Ratimed AC 20/AC 30 The Ratiomed AC 20/AC 30 is intended for use in electromagnetic environment in which radiated disturbances are controlled. The customer or user of the Ratiomed AC 20/AC 30 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF Communications Equipment and the Ratiomed AC 20/AC 30 as recommended below, according to the maximum output power of the communications equipment. -
Page 9: Technical Data
61dB (A) Transport/storage - 10°C up to + 60°C Operation + 5°C up to + 35°C Ambient conditions 5 up to 80% humidity, non-condensing 860 hPa…1060 hPa air pressure Ratiomed AC 20: REF 8710401 Item numbers Ratiomed AC 30: REF 8710501... -
Page 10: Connection, Start-Up And Operation
Functions Start-up The Rationed AC 20/AC 30 is a particularly compact The Ratiomed AC 20/AC 30 is delivered ready for suction unit for use in hospital, medical practice and at operation. Prior to connecting the power plug, make sure home. -
Page 11: Operation
Operation When the Ratiomed AC 20/AC 30 is used for removing CAUTION! body fluids of all kinds you should follow this procedure: Make sure that the collection jar is evacuated in time. Generally, it must be evacuated after each finished depending on the intended application, select a suction procedure. -
Page 12: Cleaning And Servicing
Collection jar and housing: Collection jar: how to evacuate it how to clean them Switch off the Ratiomed AC 20/AC 30. Remove CAUTION! connecting hoses from the collection jar and withdraw the Prior to cleaning the surfaces, remove power plug collection jar incl. -
Page 13: Filter
A moist filter reduces the performance of your features. Together with the mechanical overflow Ratiomed AC 20/AC 30. safety this filter prevents sucking in of secretions into In this case, immediately replace the filter. -
Page 14: Trouble-Shooting
TROUBLE-SHOOTING The Ratiomed AC 20/AC 30 was subjected to a thorough quality control before shipment. If there is, nevertheless, some malfunction, you possibly might solve this problem yourselves if you observe the following instructions. Problem Possible causes Remedy Unit does not start –... -
Page 15: Consumables, Spare Parts And Accessories
CONSUMABLES, SPARE PARTS AND ACCESSORIES CAUTION! CAUTION! Regularly check your stock for completeness of these Operational safety of the unit can be guaranteed by parts. the manufacturer only if original accessories and original spare parts are used. Consumables Bacterial filter (packaging unit = 5 pcs.)................REF 8711100 Float ball for overflow safety (packaging unit = 3 pcs.)...........REF 8711104 Silicone suction hose, internal diameter 6mm, length 1.5 m ..........REF 8712201 Hose set S6... -
Page 16: Accessories
Accessories 5.3.1 Accessories: Receptal Holder with Receptal ® canister 1500 ml ................REF 8713100 50 Receptal ® disposable liners 1500 ml, with integrated overflow shutoff valve ...REF 8713101 Unit with ® Receptal -System 5.3.2 Accessories: MediVac Holder with MediVac ® canister 1000 ml.................REF 8713200 50 MediVac ®... -
Page 17: Maintenance And Repair
MAINTENANCE AND REPAIR DISPOSAL The suction unit Ratiomed AC 20/AC 30 may only be At the end of durability, the components of the Ratiomed opened and repaired by persons explicitly authorized AC 20/AC 30 must be disposed of properly, observing the by megro. -
Page 18: Index
12.0 INDEX (referenced to pages) electromagnetic compatibility ........4 electromagnetic environment ......5, 6, 17 EMC................17 evacuate ..............11 accessories ............3, 4, 15 explanation of symbols ..........3 address of manufacturer ..........20 air pressure ..............8 air-flow rate ............10, 11 air-flow rate of pump ............8 ambient conditions .............4, 8 fill level............. - Page 19 maintenance-free ............10 malfunction..............14 MediVac ...............15 safety advices..............5 moist filter..............13 secretion ............ 10, 11, 12, 13 service technician ............11 servicing ..............12 shipment ................ 3 nominal voltage..............8 short-time operation........... 3, 8 non-original manufacturer parts ........16 silicone..............8, 13 notes on EMC ..............17 silicone hose..............
-
Page 20: Further Information
10.0 FURTHER INFORMATION Address of manufacturer: Address of supplier: GmbH & Co. KG Am Schornacker 30 D-46485 Wesel Tel.: +49 (0) 281 - 98990 Fax: +49 (0) 281 - 989950 Internet: www.megro.de E-Mail: info@megro.de 11.0 DECLARATION OF CONFORMITY...
