miAlert miPos2 Installation And Operation Manual

M odel Nam e: m i Pos2Pendant
FCC I D: 2AZU7- M I POS2PENDNT
miPos2 Pendant Water Resistant
Installation and Operation Manual

1 Overview

The miPositon water-resistant pendant is small, light and easy to wear,
washable and provides advanced functionality including an
accelerometer to establish movement and an algorithm to maximize
battery life.
The pendant is available in the following configurations:
Part # Check-In
miPos2 - W 60 minutes
miPos2 - C 60 minutes
Note: For UL 2560 installations, refer to the miPosition Gateway
Installation Instructions

1.a miAlert Contact Information

www.mialert.com
Toll Free: 855-382-8999
Email: support@mialert.com
27 Armthorpe Rd, Brampton, L6T 5M4
If you have any problems with this procedure, contact miAlert technical
services:
• Email: support@mialert.com
• Toll Free: 855-382-8999
1.b Maximum Number of Repeaters for a UL 2560
Installation
To achieve the 99.99% alarm message reliability required for UL 2560
compliance, system installations must operate within the following limits for
end device and repeater counts.
End Devices Maximum
Repeaters
128 256
256 512
512 1028
1028 1028
miAlert 2021 - www.miAlert.com
Location Wearable
North America Watch/Neck
Watch/Neck
North America

1.c Pendant Components

Figure 1 Pendant components (water resistant pendant with watch
band shown)
A B
Activation button TX/RX alarm LED and Low Battery LED
C
Battery Replace remove back cover 4 screws
2 Installation and Startup

2.a Installation Notes

• These products are designed to be maintained by certified
technicians.
• Products are intended for indoor use.
• Pendant is shipped with the coin cell battery installed. But it will be
in storage mode which will not affect battery life, to take Pendant
out of this mode please hold down the Activation button for 5
seconds.
• All products should be manually tested monthly. "Test the
Transmitter/Receiver section".

2.b Coin Cell Battery Installation / Replacement

Turn the Pendant with the back facing up and unscrew the back cover,
place the battery in the battery compartment, ensuring that the positive
terminal (+) faces up.

2.c Register the Pendant

The Pendant sends a check-in message to the Repeater via the Gateway
every 60 minutes for the purposes of supervision. The Pendant must be
registered and supervised, the Pendant should be tested after registration
to ensure operation. The Repeater will send the Pendant an
aknowledgement signal to confirm check-in supervion has been received.
Caution: The Pendant must have a supervision window of no more
than 12 hours to avoid not discovering a missing device within 24 hours.

2.d Wear the Pendant

The pendant can be worn in three ways:
• Around the neck with the neck lanyard, which is included with the
water resistant pendant with neck lanyard.
• On the arm with the wristband, which comes attached on the
water resistant pendant with wristband.
• On the belt, using the optional belt loop attachment kit.
A
B
C
