. SAFETY PRECAUTIONS
WARNING:
To reduce the risk of fire or electric shock, do not expose this appliance
to rain or moistrue. Dangerous high voltages are present inside the
enclosure. Do not open the cabinet.
CAUTION:
To prevent electric shock, match wide blade plug to wide slot, fully insert.
CAUTION:
The unit employs a laser system. To ensure the proper use unit, read
this manual carefully and keep it for future reference. If the unit requires
servicing, contact the seller or our service center- see "troubleshooting ". To
prevent direct exposure to the laser radiation, do not open the cabinet. In
visible laser radiation when the cabinet is opened or the interlocks are
defeated. Do not stare into the laser beams.
WARNING:
Use of any controls, adjustments, or procedures other than those specified
herein may result in hazardous radiation exposure.
not for use where video monitor is visible to driver to avoid risk of serious injury
or possible violation of atate laws.
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated "
dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions
in the literature accompanying the product.
· 1 ·
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDM-FD10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Initial IDM-FD10

Summary of Contents for Initial IDM-FD10

  • Page 1 . SAFETY PRECAUTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated " dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions...

  • Page 2: Safety Precautions

    . IMPORTANT SAFETY INSTRUCTIONS (1)Read Instructions - All the safety and operating instructions should be read before the product is operated. (2)Retain Instructions - The safety and operating instructions should be retained for future reference. (3)Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.
  • Page 3 . IMPORTANT SAFETY INSTRUCTIONS (13)Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the anetenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS IMPORTANT SAFETY … … … … … … … … INSTRUCTIONS … … … … … … … … … … … FEATURES ……………………… ABOUT MANUAL ……………………… PLAYABLE DISCS …………………… TERMS FOR DISCS BEFORE OPERATION PRECAUTIONS FOR DISCS PREPARATIONS BEFORE ……………………………...

  • Page 5: Features

    3. LCD SCREEN The IDM-FD10 is capable of displaying Full Screen (4:3) and Wide Screen (16:9) media. This product incorporates copyright protection technology that is protected by method claims of certain U .S.

  • Page 6: About Manual

    D. ABOUT MANUAL PRINCIPLES FOR WRITING This manual mainly introduces how to use the buttons on the remote control. You may operate the unit if the buttons on the unit have the same or similar names as to those on the remote control.

  • Page 7: Terms For Discs

    . TERMS FOR DISCS TITLE The images or music of a DVD are divided into some units, among which title is the biggest one. To an image in video software, title is movie; to a piece of music in audio software, it is music.

  • Page 8: Before Operation

    . BEFORE OPERATION WHEN DRIVING Keep the volume level low enough to be aware of road and traffic conditions. WHEN CAR WASHING Do not expose the product to water or excessive moisture. This could cause electrical shorts, fire or other damage. WHEN PARKED Parking in direct sunlight can produce very high temperatures inside your vehicle.

  • Page 9: Preparations Before Operation

    . PREPARATIONS BEFORE OPERATION This part introduces the work to be done before operating the unit. CHECK ACCESSORIES Check if you have all the accessories after the carton is opened. Power supply cord AV output cables AV input cables Lamps Remote control AAA batteries USE REMOTE CONTROL...

  • Page 10: Main Unit

    . PREPARATIONS BEFORE OPERATION Main Unit 1. POWER 2. REMOTE SENSOR 3. DISC SLOT 4. PREVIOUS SKIP 5. NEXT SKIP 6. STOP 7. PLAY 8. EJECT 9. PAUSE 4 5 6 7 8 9 14 15 16 17 18 10. LAMP L and LAMP L Switch 11.

  • Page 11: Names And Layout Of Remote Controls

    . PREPARATIONS BEFORE OPERATION NAMES AND LAYOUT OF REMOTE CONTROLS ADJUST LAMP RC-2811 * When the slide switch on the remote is set to the "DVD" position (left), the remote control is set to control all DVD player functions. When the slide switch is set to the "LCD" position, it is set to control all Display functions. SOURCE FM TX MUTE...

  • Page 12: Connections

    . PREPARATIONS BEFORE OPERATION CONNECTIONS Wire Color Chart Color Function Black Ground Switched or Ignition/ACC power Yellow Constant Power/Battery direct Blue Dome Lamp Door Trigger - switching (GM Type) White Dome Lamp Door Trigger + switching (Ford Type) · 11 ·...
  • Page 13 . PREPARATIONS BEFORE OPERATION Cautions before connection This product is designed for negative ground 12V DC operation only. Before making connections, turn the car ignition off to avoid short circuits. Connect the yellow power input lead only after all other leads have been connected. Run all ground wires to a common ground point.

  • Page 14: Basic Operations

    . BASIC OPERATIONS Caution: This DVD player and display screen unit are intended for the entertainment and use of rear seat passengers only. It is not recommended that the driver of the vehicle that this device is installed in view the screen while the vehicle is in motion. The owner of the vehicle should familiarize him or herself with all functions of the unit prior to operating the vehicle in anticipation of user questions.

  • Page 15: Play Discs

    . BASIC OPERATIONS PLAY DISCS 1. Load a disc and play the disc. 2. Stop playback. Press 3. Remove the disc and switch off the unit. You have to press this " PAUSE Press WHEN PLAYING PICTURES If the pictures of DVD are played, press The unit enters step play status.

  • Page 16: Osd

    . BASIC OPERATIONS The On-Screen Display (OSD) contains many playback features. To see the Display, press the OSD button on the remote while a disc is playing. The picture being played will be zoomed out to the top of the screen. The Display appears under the zoomed picture.
  • Page 17 . BASIC OPERATIONS Changing the Audio Language If the disc was created with different language tracks (recorded in different languages), you can use the Display to temporarily change the DVD player's Audio Language setting. 1. While the disc is playing, press OSD on the remote to bring up the Display.
  • Page 18 . BASIC OPERATIONS 1. While the disc is playing, press OSD on the remote to bring up the Display. 2. Press the buttons to highlight "TT (Title) Time". 3. Press the (PLAY) button, the text box by the right side is now highlighted. 4.

  • Page 19: Dvd Menu Play

    . BASIC OPERATIONS Setting Disc Time You can skip to a specific disc time by using the Disc Time feature in the Display. 1. While the disc is playing,press OSD on the remote to bring up the Display. 2. Press the buttons to highlight "Disc Time".

  • Page 20: Select With Number Buttons

    BASIC OPERATIONS You can also do as follows: 1. Press to select track 13. Root Menu 2. Press (PLAY)to start playing track 13. Press TITLE once to return to the title menu. Press MENU once to return to the root menu.
  • Page 21 . MENU SETUP The screen shows: -- Audio Setup Page -- Speaker Setup Dolby Digital Setup Channel Equalizer 3D Processing Main Page Go To Speaker Setup Page Press direction buttons ( highlight "Dolby Digital Setup", and press (PLAY) to enter "Dolby Digital Setup" Page.
  • Page 22 . MENU SETUP GENERAL SETUP The setting structure is as follows: - - General Setup Page - - TV Display TV Type NTSC Captions Screen Saver Last Memory Main Page TV DISPLAY 1. NORMAL/PS This is selected when the unit is connected to a normal TV.
  • Page 23 . MENU SETUP CAPTIONS The hidden subtitle is shown. The hidden subtitle is turned off. SCREEN SAVER Start the screen saver, the screen saver image appears when the unit stops or the image is frozen for a few minutes. This saver can keep the screen from being damaged.
  • Page 24 . MENU SETUP EQUALIZER This will help you to select graphic equalizer patterns according to the genre of the music being played, and adjust the equalizer. The setting structure is: - - Channel Equalizer - - EQ Type None None Rock Live dance...
  • Page 25 Example: Select "PG" , you cannot play DVD video disc rated higher than the PG grade. DEFAULT >> RESET Each function setting returns to the initial status in the factory if you select this option. Note: "PREFERENCES" only can be selected after the unit goes into stop mode.

  • Page 26: Play Discs In Various Ways

    L. PLAY DISCS IN VARIOUS WAYS AUDIO MODE You may select a needed language from a multi-language DVD. You may select the right channel or left channel or stereo from a multi-channel CD. WHEN PLAYING DVD Press LANGUAGE , the screen shows orderly: Audio 1/2:AC 3 5.1CH Audio 2/2:AC 3 5.1CH...

  • Page 27: Fast Play

    L. PLAY DISCS IN VARIOUS WAYS FAST PLAY When playing a disc, you may play it forward fast or reverse it fast to find what you want. WHEN PLAYING DVD OR CD 1. Press to play forward fast. Each time you press the button, the screen shows orderly: 2.

  • Page 28: Select Subtitles

    . PLAY DISCS IN VARIOUS WAYS SELECT SUBTITLES This operation works only with discs on which multiple subtitle language are recorded. PLAY DVD 1. Press repeatedly until the desired language is selected. The screen shows: SUBTITLE01/03:ENGLISH 2. Remove the subtitle. Press until the screen shows "TURN OFF SUBTITLES".

  • Page 29: Play Mp3 Discs

    . MP3 OPERATION SELECT TRACKS WITH MENU 1. Insert a disc, the unit will search disc information. The TV screen displays main menu. 00:00 00:00 001/012 FOLDER CD01 CD02 CD03 CD04 CD05 CD06 2.Press direction key folder. Press (PLAY) to confirm selection.

  • Page 30: Others

    . OTHERS TROUBLE SHOOTING If you experience the following problems while using the unit, this troubleshooting guide can help you. PROBLEM The power does not turn Nothing happens when the buttons are pressed. No video image. The screen is dark. No sound from the wireless headphone.

  • Page 31: Technical Specifications

    . OTHERS TECHNICAL SPECIFICATIONS Laser Video system Frequency response Signal/noise ratio Audio distortion + noise Channel separation Dynamic range Audio out (analog audio) Output Video out Power supply Environment temperature Power consumption Weight This manual is only for your reference, any change to the design and specifications will not be advised.

  • Page 32: Installation

    O. INSTALLATION Warning! The product must be installed by a certified dealer for the warranty coverage to be valid. The user waives warranty coverage if the product is moved to another vehicle. Where to install Before installing the monitor, please check your local traffic rules and regulations. Follow the following diagram to install the monitor in a suitable position in your car.
