Summary of Contents for Atlantic Products EMW1500R
- Page 1 EMW1500R EMW3000R Electric Marine Winch Installation instructions and operating manual for Atlantic Electric Marine Winches series. PLEASE READ CAREFULLY BEFORE OPERATING THE WINCH...
- Page 2 76.2 adequate motor cooling. A pulley block (not supplied) is required for Double Line operation. EMW1500R SPECIFICATIONS LINE SPEED AND MOTOR CURRENT (FIRST LAYER) LINE PULL AND CABLE CAPACITY Line pull Line speed...
- Page 3 WIRING HARNESS INSTALLATION Figure 4 - Base Hole Pattern-Model EMW1500R & EMW3000R (in mm) The wiring harness is designed to be permanently installed on a vehicle and 4. Attach negative wire to vehicle frame stored in the trunk or truck bed, etc.
-
Page 4: Operating The Winch
Operating the Winch Unloading and loading under power Operating the clutch Auxiliary Handle 1. Attach the power supply plug into the 1. The clutch lever provides a means for 1. An emergency crank handle is provided. connector located at the back of the releasing a load without power while For use in the event of a power failure, winch. -
Page 5: Maintenance Of The Winch
Figure 8). the clamp is tightened securely. NOTE: Cable is wound under the drum on Model EMW1500R and EMW3000R. Figure 8 - O-Ring Illustration Figure 7 - Cable Attachment Methods d. Rotate the spring keeper clockwise 10 degrees and install on the next 3. - Page 6 Electric Marine Winch Repair Parts List Part description Part description Part description Motor assembly Clutch handle nut Front plate Brake disc Clutch spring keeper Hexagon screw with flange One-way bearing 16×Ф9.5×13 Snap joint Cover 1 Nylon-ring Clutch handle Cover 2 Bushing 1 Cross recess pan head screw cross recess pan head screw...
- Page 7 Troubleshooting and General Safety Guide Symptom Possible Cause(s) Corrective Action Safety hook spreads 1. Point loading of hook 1.Replace hook 2. Load exceeds rated capacity of unit 2. Lighten load, reduce % of incline or reduce load friction Cable snaps 1.
- Page 8 A N O T H E R Q U A L I T Y A T L A N T I C P R O D U C T www.atlanticproducts.com.au...
