Summary of Contents for Crorzar 360
- Page 1 Crorzar 360 WIFI PAN/TILT SMART CAMERA Quick User Manual CZ-PT-CAM1...
-
Page 2: Included In The Box
Included in the Box The following are included in the box with your purchase Main Device: Camera x 1 Accessory 1: USB Cable x 1 Power adapter x 1 Accessory 2: Bracket x1 Screws bag×1... -
Page 3: Product Details
Product Details Please check the interface and buttons of the camera before using. Microphone Photosensitive LED night vision resistance infrared light Million HD lens SD Card slot Front view Speaker 5V1.6A RJ45 Ethernet cable port Power interface Reset factor y reset button Back view... -
Page 4: Memory Card Installation
How to prepare the camera Please note: Voice prompts are automatically available throughout the configuration process. Your memory card comes pre-installed in your camera. Connect your camera to power as shown below. Do not unplug your memory card or insert a new one while the power is turned on. - Page 5 How to Download APP Method 1: Scan the QR Code to download the App. Method 2: Search for "Crorzar Cameras" in the App Store or "Crorzar Pro" in Google Play Store and download directly. Available on the App Store Scan this QR code to download App for iOS devices...
- Page 6 User registration & login If you have a Facebook ID, you can tap the Facebook icon on the APP interface directly to log in. You can also create a new account and log in: Click "Sign Up" to register a new account.
- Page 7 Configure network connection for camera Method 1: through WIFI (recommended) 10:07 10:07 Smart Devices Add Device More Set Up Device Using Wi-fi H o l d “ R E S E T ” b u t t o n o n t h e b o t t o m / b a c k o f t h e d e v i c e t o b e g i n s e t u p Add Guest Device Add Device...
- Page 8 10:07 Push the QR code button in the upper right hand Wifi Network corner to generate a configuration code on your Push the QR code button in the device. Hold this code a few inches from the camera upper right hand corner to display the wifi configuration QR code lens for a few seconds to initiate camera setup.
- Page 9 Method 2: via LAN port Connect the power supply Note: About wired connection, you need to connect the camera to the router using the LAN cable. Lan Cable Connect the camera to LAN Port 1. After logging in successfully, click “+” in the upper right hand corner and then click “...
- Page 10 Method 3: via AP Mode Note: Direct connection is limited to remote viewing within 10 meters when without network 1. Press the “RESET” button 2-5 times Shortly on the device, the device will prompt “Entering AP direct connection mode”. 2. Click the "+" at upper right corner of the APP , then click "More"...
- Page 11 Multiple cameras can be added on the App and all of them will show up on the main screen of the App, long press on an camera can lead to menu that user can share, set or delete the camera. 10:07 10:07 Smart Devices...
- Page 12 View the camera through App User can achieve the real time monitoring through the camera once it is added successfully on App by pressing the “Play” icon like Fig 7, there are also some functions available user can use on the page below. 10:07…...
- Page 13 Setup the Tour and Auto Track functions User can tap the icon in Fig 9 to go to the settings of Tour and Auto Track shown in Fig 10. Tour: it allows user to preset three positions from the camera view to create a route that camera will follow to rotate for monitoring automatically.
-
Page 14: Camera Settings
Camera Settings User can setup the camera when necessar y, press the “setting” icon in the upper right hand corner on Fig 8. 10:07… Settings Basic Settings Manage Password Alert Settings Manage Storage Advanced Settings Network Settings Device Info... -
Page 15: Basic Settings
Basic Settings 10:07… Basic Settings Save Enable or disable voice prompts Tone Change device name Device Name Indoor Enable or disable Flip Upside-Down flip of orientation of image on screen Flip Left-Right Change device Device Language English language Change rotation Rotation Speed Normal speed of pan/tilt... -
Page 16: Manage Password
Manage Password 10:07… Set Password Input current Current Password password Input a new New Password password Input the new Confirm Password password again Press “Save” Save to finish operation... -
Page 17: Alert Settings
Alert Settings 10:07… Motion Settings Enable or disable Motion Activated Alerts motion activated Trigger alarm when there is a motion alerts Set the time of video duration Video Duration(S) 00:30 for recording Change the actions Actions upon alerts Photos and Videos on alerts on Alerts Change the... - Page 18 Alert Settings-Intelligent Vigilance 10:07… Tap Save after a Intelligent Vigilance Save Camera will only setting is done detect human for Smart Detection Enable it to triggering alarm if show traces it's enabled Show Traces of human Enable it to setup detected Perimeter Alert the perimeter that...
-
Page 19: Manage Storage
Manage Storage 10:07… Manage Storage Check entire Storage Capacity capacity of SD card Check the storage Capacity for Video capacity for videos on SD card Check the storage Capacity for Snapshot capacity for snapshots on SD Check the available Available Storage card storage on SD card At Full... - Page 20 Advanced Settings 10:07… Advanced Settings Save Record Settings Turn on/off video Record Switch recording on SD Set the duration card Duration of video clips on 5Mins SD card Enable or disable Record Audio audio recording Auto Track Turn on/off Auto Track Switch Auto Track function Auto Track Sensitivity High level...
-
Page 21: Network Settings
Network Settings 10:07… Network Settings Select the network connection mode AP Mode for camera Routing Mode Select an available ORBI13 WIFI network for camera MySpectrumWIFI Zans_2.4 ORBI13-Guest ORBI13 ORBI13-Guest Save... - Page 22 1 (855) 700-2482 cs@crorzar.com For questions or help, please contact us. Answers to frequently asked questions, as well as video demonstrations of setting up your camera, can be found at https://www.crorzar.com/pages/cameras...
