07-DEC-2009
2009-3957
DOMESTIC Chlorine or bromine Generating Device
Installation and Operation Manual
KEEP OUT OF REACH OF CHILDREN
MODEL DIG36 REGISTRATION NUMBER 28026 PEST CONTROL PRODUCTS ACT
Maximum output of hypochlorous of hypobromous acid equivalent to 0.58 kg of free available chlorine per day
One DIG36 Unit Can Treat a Maximum Of 121,000 Litres Of Swimming Pool Water
READ THE LABEL AND THIS MANUAL BEFORE INSTALLING & OPERATING
NOTICE TO USER: This pest control product is to be used only in accordance with
the directions on the label. It is an offence under the Pest Control Product Act to
use this product in a way that is inconsistent with the directions on the label. The
user assumes the risk to persons or property that arises from any such use of
this product.
Mursatt Chemicals Limited, 11 Regalcrest Court, Woodbridge, ON, L4L 8P3
(Mursatt PP DIG3 6 Residential English Final April 2005)
Mursatt
GEN-R-8
Model
Digital 36
by MURSATT CHEMICALS LIMITED
Controls Bacteria And Algae In Swimming Pool Waters
(For Indoor or Outdoor Use)
RETAIN MANUAL FOR FUTURE REFERENCE
C
IMPORTANT
Phone: 1.800.263.9880 or 1.905.850.8444
NSF50
Advertisement
Table of Contents
Related Manuals for MURSATT GEN-R-8 Digital 36
Summary of Contents for MURSATT GEN-R-8 Digital 36
- Page 1 Mursatt Chemicals Limited, 11 Regalcrest Court, Woodbridge, ON, L4L 8P3 Phone: 1.800.263.9880 or 1.905.850.8444 (Mursatt PP DIG3 6 Residential English Final April 2005)
-
Page 2: Section 1 General Information 1A Product Information And Contact Numbers
Section 1a – GENERAL PRODUCT INFORMATION Mursatt Gen-8-R Model Digital 36 by MURSATT CHEMICALS LIMITED Record The Following Information Installer: _____________________________Date of Installation: __________________________ Control Unit Control Unit Model Number: DIG36______________ Serial Number: # ____________________________ Cell Cell Model: # RC-5 Serial Number: # ____________________________ Customer Assistance…... -
Page 3: Important Safety Instructions
115/230VAC, 50/60 Hz Models (fixed wiring) A wire connector is provided on your Mursatt Gen-8-R Model Digital 36 to connect a minimum 8.4 mm² (No. 8 AWG) in the U.S.A. and 6.3mm² (No.6 AWG) in Canada solid copper bonding conductor between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe or conduit within 1.5 m (5 ft.) of the unit. -
Page 4: Table Of Contents
Section 1c – GENERAL PRODUCT INFORMATION Table of Contents Mursatt Gen-8-R Model Digital 36 by MURSATT CHEMICALS LIMITED Section 1 GENERAL INFORMATION Product Information and Contact Numbers ............1 Important Safety Instructions ................... 2 Table of Contents ....................... 3 Section 2 INSTALLATION Main Components ...................... -
Page 5: Section 2 Installation
Section 2a – INSTALLATION Main Components Tri-Sensor Assembly DIG 36 = RC5 Cell union Flow In Flow Out to pool Control Box Flow Bypass Manifold Assembly CONTROL BOX converts incoming ELECTROLYTIC CELL TRI-SENSOR ASSEMBLY AC power to a Low Voltage DC current, receives Low Voltage DC current from ensures that adequate flow, which energizes the Cell(s). -
Page 6: Control Box Connections
DANGER: ensure that the electrical panel or filter pump circuit breaker is turned OFF before wiring this unit. Your Mursatt Gen-8-R Model Digital 36 Control Box comes pre-wired from the factory for 230VAC (1.5 amps max draw) and can also operate on 115 VAC, (3.0 amps max draw) at 50/60Hz. -
Page 7: Cell And Manifold Installation
Cell and Manifold Installation Your Mursatt Gen-R-8 System is adaptable for use with the 5 blade (RC-5) cell. The manifold must be located as the last accessory in the POOL RETURN LINE only. For special plumbing configurations, please contact your representative for assistance in locating the manifold. -
Page 8: Section 3 Operation
Key Features The Mursatt Gen-8-R Model Digital 36 display will show the SANITIZER OUTPUT LEVEL (in percent %) and whether the system is in BOOST or SUPER-BOOST Mode on the first line of the two line alphanumeric display. The second line will display the current TIME in either 12 or 24-hr mode, the TEMPERATURE in either Fahrenheit or Celsius, whether the cell is powered or not, shown as ON or OFF and Polarity Direction, shown as a “.”... - Page 9 The MENU Button allows you to enter the programming and monitoring functions. Use UP/DOWN ARROW and SELECT to scroll through the Main menu and Sub-menu: Main Menu 1.0 Test Mursatt Gen-8-R Model Digital 36 2.0 Owner Options 3.0 Maintenance Menu 4.0 Installer Menu...
- Page 10 3.7 Calibrate Salt: allows you to calibrate the salt display. Contact the factory for calibration solution 3.8 Replace Cell: Only used when replacing cells. May be used to zero the amp -hour counter. Consult Mursatt Chemicals Limited for details 3.9 Back –...
-
Page 11: Pool Water Preparation
120-ppm. Start Up Procedures Keep the Output Setting on your Mursatt Gen-8-R Model Digital 36 on 0% (OFF) until you get your water clear, blue and properly balanced. After balancing your water chemistry according to the Water Chemistry Parameters shown on page 10, add the proper amount of salt (see Salt Requirement Chart above) and circulate 24-hours prior to starting your Mursatt Gen-8-R Model Digital 36. -
Page 12: Monitoring And Maintenance
NOTE: For Bromine or indoor pools, it is not necessary to add stabilizer. SALT RESIDUAL: Your Mursatt Gen-8-R Model Digital 36 works most efficiently with salt levels between 2.8 – 3.2 gm/l (2800- 3200 ppm). If it falls below 2.8 gm/l (2800 ppm), determine the salt level and adjust according to the SALT REQUIREMENT. Low salt will cause premature deterioration of the Cell blades. -
Page 13: Section 4 Service And Maintenance
Section 4a –SERVICE and MAINTENANCE CONTROL BOX There are very few serviceable parts on the Mursatt Gen-8-R Model Digital 36 Control Box except the fuses. For any other problems with the Control Box, please contact your representative or Authorized Dealer/Service Center. -
Page 14: Cell
VISUAL CELL INSPECTION: The titanium Cell blades, seen inside the Cell body, should be straight and clear of any debris between the blades. Your Mursatt Gen-8-R Model Digital 36 is designed to automatically self-clean scale build -up within the Cell. However, imbalanced water chemistry and certain conditions can cause a heavier scale build up that exceeds the self-cleaning capability and would need to be cleaned manually by the method described below. -
Page 15: Parts Explosion
Section 4c –SERVICE and MAINTENANCE Parts Explosion Manifold Assembly: Manifold Union w/Strainer: (#941) (#19065) TRI-SENSOR Union Nut Union O-Ring (#19014) Strainer (#19064) CELL w/ UNIONS MANIFOLD UNION w/Strainer MANIFOLD BASE w/Check Valve Electrolytic Cell: (Cell Unions and Cord ordered separately) Red Cap Plug for RC-5 cell cord (#19050) 12 ft. -
Page 16: Section 5 Troubleshooting
Section 5a – TROUBLESHOOTING TROUBLESHOOTING PROBLEM CAUSE SOLUTION Insufficient Sanitizer Production. A) The test kit reagents or test strips are old or expired. A) Retest with new Reagents or Strips. B) The unit is set too low in relation to sanitizer demand. B) Increase the Sanitizer % output. - Page 17 FIRE OR EXPLOSION DOMESTIC READ THE LABEL AND THE INSTALLATION AND OPERATION MANUAL BEFORE USING KEEP OUT OF REACH OF CHILDREN (MURSATT PP PCP Sticker Lect DIG36 Final April 2 0 05 )
- Page 18 Cell Model RC-5 This is a replacement cell for the chlorine or bromine generating device MURSATT GEN -R-8 Model DIG 36 REGISTRATION NUMBER 28026, PEST CONTROL PRODUCTS ACT. This cell must only be used on this model of chlorine or bromine generating device.
- Page 19 ****************************** This label transcript service is offered by the Pest Management Regulatory Agency to provide efficient searching for label information. This service and this information do not replace the official hard-copy label. The PMRA does not provide any guarantee or assurance that the information obtained through this service is accurate, current or correct, and is therefore not liable for any loss resulting, directly or indirectly, from reliance upon this service.
