16-NOV-2007 [2007-6225]
GEN-R-8
™
Pool Pilot
Digital
by MURSATT CHEMICALS LIMITED
COMMERCIAL
Chlorine Generating Device
Installation and Operation Manual
MODEL DIG840C REGISTRATION NUMBER 28080 PEST CONTROL PRODUCTS ACT
Maximum Output Equivalent To 0.91 Kg. Of Free Available Chlorine Per Day
One DIG840C Unit Can Treat a Maximum Of 190,000 Litres Of Swimming Pool Water
Controls Bacteria And Algae In Swimming Pool Waters
(For Indoor or Outdoor Use)
RETAIN MANUAL FOR FUTURE REFERENCES
NSF50
IMPORTANT
READ THE LABEL AND THIS MANUAL BEFORE INSTALLING & OPERATING
C
Notice to User: This pest control product is to be used only in accordance with the directions on the label. It
is an offence under the Pest Control Products Act to use this product in a way that is inconsistent with the
directions on the label. The user assumes the risk to persons or property that arises from any such use
of this product.
Mursatt Chemicals Limited, 71 Carlauren Rd., Woodbridge, ON, L4L 8A8
(MURSATT PP DIG840 Commercial English Final May 2 0 0 5)
Advertisement
Table of Contents
Related Manuals for MURSATT Digital Pool Pilot GEN-R-8
Summary of Contents for MURSATT Digital Pool Pilot GEN-R-8
- Page 1 The user assumes the risk to persons or property that arises from any such use of this product. Mursatt Chemicals Limited, 71 Carlauren Rd., Woodbridge, ON, L4L 8A8 (MURSATT PP DIG840 Commercial English Final May 2 0 0 5)
-
Page 2: Section 1 General Information 1A Product Information And Contact Numbers
Section 1a – GENERAL PRODUCT INFORMATION Pool Pilot ™ Digital by MURSATT CHEMICALS LIMITED Record The Following Information Installer: _____________________________Date of Installation: __________________________ Control Unit Control Unit Model Number: DIG840C______________ Serial Number: # ____________________________ Cell Cell Model: # CC-15 Serial Number: # ____________________________ Customer Assistance…... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS INSTALLATION AND EQUIPMENT RELATED Installation of all Mursatt GEN-R-8 Pool Pilot Digital models: When installing and using your Pool Pilot Digital Control Box, basic safety precautions must always be followed, including the following: Follow all aspects of the local and National Electrical Code(s) when installing your Control Box. -
Page 4: Table Of Contents
Section 1c – GENERAL PRODUCT INFORMATION Table of Contents Pool Pilot Digital by MURSATT CHEMICALS LIMITED SYSTEMS INC. Section 1 GENERAL INFORMATION Product Information and Contact Numbers ............1 Important Safety Instructions ................... 2 Table of Contents ....................... 3 Section 2 INSTALLATION Main Components ...................... -
Page 5: Section 2 Installation
Section 2a – INSTALLATION Main Components Tri-Sensor Assembly Cell CC-15 13.8 kpa Ball Valve #1 Ball Valve #2 2 lb Spring Check Valve To Pool Control Box Flow Bypass Manifold Assembly CONTROL BOX converts incoming ELECTROLYTIC CELL TRI-SENSOR ASSEMBLY AC power to a Low Voltage DC current, receives Low Voltage DC current from ensures that adequate flow, which energizes the Cell(s). -
Page 6: Control Box Connections
Section 2b – INSTALLATION Control Box Connections Electrical Connections Autopilot recommends that a licensed electrician or certified electrical contractor perform the electrical connections. DANGER: ensure that the electrical panel or filter pump circuit breaker is turned OFF before wiring this unit. Your Pool Pilot™... -
Page 7: Cell And Manifold Installation
Cell and Manifold Installation Your MURSATT GEN-R-8 System is adaptable for use with the 15 blade (CC15) cell. The manifold must be located as the last accessory in the POOL RETURN LINE only. For special plumbing configurations, please contact your representative for assistance in locating the manifold. -
Page 8: Section 3 Operation
Section 3a – OPERATION Key Features The Pool Pilot Digital display will show the SANITIZER OUTPUT LEVEL (in percent %) and whether the system is in BOOST or SUPER-BOOST Mode on the first line of the two line alphanumeric display. The second line will display the current TIME in either 12 or 24-hr mode, the TEMPERATURE in either Fahrenheit or Celsius, whether the cell is powered or not, shown as ON or OFF and Polarity Direction, shown as a “.”... - Page 9 Section 3a – OPERATION Key Features – continued POOL PILOT Digital S a n i t i z e r 100% 12:00P Check System Boost Menu Select Pump The MENU Button allows you to enter the programming and monitoring functions. Use UP/DOWN ARROW and SELECT to scroll through the Main menu and Sub-menu: Main Menu 1.0 Test Pool Pilot...
- Page 10 3.7 Calibrate Salt: allows you to calibrate the salt display. Contact the factory for calibration solution 3.8 Replace Cell: Only used when replacing cells. May be used to zero the amp -hour counter. Consult Mursatt Chemicals Limited. for details 3.9 Back –...
-
Page 11: Pool Water Preparation
Section 3b – OPERATION Pool Water Preparation Salt Requirements It is important that with typical pools, a salt residual of 2.8 – 3.2 gm/l (2800 to 3200 ppm) be maintained at all times for peak efficiency. NOTE: Maintaining high salt levels above recommended range can contribute to corrosion of pool/spa equipment. Salt levels exceeding the recommended concentration can be reduced by diluting the pool/spa with fresh water. -
Page 12: Monitoring And Maintenance
Section 3c – OPERATION Monitoring and Maintenance Water Chemistry Parameters - Your Pool Pilot Digital is designed to provide Sanitizer on a daily VERY IMPORTANT NOTE! basis. We recommend the following water chemistry ranges and periodic checks to monitor your systems efficiency. A lways follow local health requirements. -
Page 13: Section 4 Service And Maintenance
Section 3c OPERATION (cont’d) Additional notes: For proper sanitation, spa must be completely drained periodically. The number of days between COMPLETE SPA DRAINAGE is equal to the volume of spa water in liters, divided by 10 times the maximum number of daily spa users. -
Page 14: Cell
SUPPLY. WARNING: ALWAYS ADD ACID TO WATER, never water to acid. When replacing the cell, only use replacement cells having a label that clearly states that it is a replacement cell for the chlorine generating device Mursatt GEN-R-8 Digital Model DIG840C, REGISTRATION NUMBER 28080, PEST CONTROL PRODUCTS ACT. -
Page 15: Parts Explosion
Section 4c –SERVICE and MAINTENANCE Parts Explosion Manifold Assembly: Tri-Sensor Assembly Cell # CC-15 13.8 kpa (2 lb) Ball Valves Spring Check Valve Electrolytic Cell: (Cell Unions and Cord ordered separately) 3.6m (12’) Cell Cord (# 952-1) Union O-Ring (#19013) Cell # CC-15 Nut Half only (2 pcs) for 50 mm (2”) S x S Union Thread Half Only for 50 mm (2”) S x S Union... -
Page 16: Section 5 Troubleshooting
Section 5a – TROUBLESHOOTING TROUBLESHOOTING PROBLEM CAUSE SOLUTION Insufficient Sanitizer Production. A) The test kit reagents or test strips are old or expired. A) Retest with new Reagents or Strips. B) The unit is set too low in relation to sanitizer demand. B) Increase the Sanitizer % output. - Page 17 FIRE OR EXPLOSION COMMERCIAL READ THE LABEL AND THE INSTALLATION AND OPERATION MANUAL BEFORE USING (MURSATT PP PCP Sticker Lect DIG840C Final April 2 0 0 5 )
- Page 18 16-NOV-2007 [2007-6225] Cell Model CC-15 This is a replacement cell for the chlorine generating device MURSATT GEN -R-8 Digital Model DIG840C REGISTRATION NUMBER 28080, PEST CONTROL PRODUCTS ACT. This cell must only be used on this model of chlorine generating device.
- Page 19 ****************************** This label transcript service is offered by the Pest Management Regulatory Agency to provide efficient searching for label information. This service and this information do not replace the official hard-copy label. The PMRA does not provide any guarantee or assurance that the information obtained through this service is accurate, current or correct, and is therefore not liable for any loss resulting, directly or indirectly, from reliance upon this service.
