- Page 2 1/4" x 1 ⁄ " 1/4" x 1 / " 3/16" x 1 ⁄ " 3/8" hex key hex bolts self-tapping screws self-tapping screws plastic washer 2" x 1" wheels A wheels B legs *you will need a Phillips-head screwdriver (not included) armrest 1 armrest 2 stopper rail...
- Page 3 Take the pre-assembled rollout drawer and sleeper cushion out of the carton. Follow the red string and you’ll nd the hardware pack and the throw pillows inside the drawer. Fold the drawer back into the original position and place the assembly vertically as shown.
- Page 4 Screw in the wheels A (part G) using 2 x D self tapping screws with the Phillips-head screwdriver. Screw in the wheels B (part H) using 2 x E self tapping screws with the Phillips-head screwdriver.
- Page 5 Make sure to fold the drawer into a sleeper cushion and place the assembly horizontally so that the wheels are facing downward. Take out both armrests and place them as pictured. Please position the center of the leg (part I) 1,6" from the edge of the armrest and attach the legs using the E self-tapping screws as shown.
- Page 6 Attach the stopper rail onto the armrests using 2 x C bolts on each armrest with the provided hex key. Please make sure the stopper hooks are positioned as in illustration. Place the armrests and stopper assembly into a regular position, connect the back cushion (6) onto the pins on the inner side of each armrests with the plastic...
- Page 7 Unfold the hook and loop tape on both corners in the back of the backrest and secure the backrest onto both armrests using 4 x C bolts and the hex key. Place the sleeper assembly into the sofa base, gently roll it over the stopper rail until both wheels are on the inside of stoppers, you will hear a distinct «click»...
