Summary of Contents for shockrite SRM402
-
Page 2: Table Of Contents
Contents 1. Introduction.................1 2. Safety Requirements and Regulations........1 3. Specification................3 4. Installation Guide................4 5. Troubleshooting................5 6. Guarantee...................6 7. Contact Information..............6... -
Page 3: Introduction
1. INTRODUCTION Thank you for buying a ShockRite electric fence energiser. This energiser has built-in lightning protection devices to reduce the risk of lightning damage, and has built-in RFI (Radio Frequency Interference) suppressed circuitry. If for any reason you are not happy with your purchase, please return the energiser to your supplier within 30 days of purchase and we will give you a full refund. - Page 4 If connecting leads and electric fence wires are installed near an overhead power line, the clearances should be not less than those shown below: Power Line Voltage Clearance (Voltage) (Metres) Under 1,000 Between 1,000 and 33,000 Over 33,000 If connecting leads and electric fence wires are installed near an overhead power line, their ...
-
Page 5: Specification
3. SPECIFICATION 1. Pulse Indicator 3. Fence Terminal 2. Earth Terminal 4. Mains Plug Contents: 1 x Mains Electric Fence Energiser 1 x Fence Wire 1 x Earth Wire 1 x Earth Stake Features: 1. Heavy duty case 2. Pulse indicator will flash with each pulse 3. -
Page 6: Installation Guide
Power Open 500 Ohm Power Number Energy Energy Source Consumption Volts Load Length (Joules) (Joules) Volts (km) SRM402 0.25 230V 0.6W 8,500 4,200 SRM406 230V 1.0W 9,500 4,500 SRM412 230V 1.5W 9,500 5,100 **Distance is based on single strand high tensile galvanized wire (no vegetation) 4. -
Page 7: Troubleshooting
Step 3. Connecting to Power Supply After all installation checks have been carried out, connect to mains using the plug provided. The pulse indicator will flash green every 1.5 seconds to show that the energiser is operating. If the connection cables provided are not long enough to reach the earth stake or fence from where your energiser is mounted, please use electric fence double-insulated lead out cable to extend your connections. -
Page 8: Guarantee
If these requirements are not fulfilled, we reserve the right to void warranty. 7. CONTACT INFORMATION If you have any further technical questions about our products, please contact us: McGrath Supplies Ltd - ShockRite 72 Derrybrick Road Carrickoughter...
