Delgard DT3336-60 Installation Manual

T
HE
AERO GRADE GATE INSTALLATION MANUAL
GIVE THIS MANUAL TO THE HOMEOWNER UPON COMPLETION
CAUTION: This manual is for aero gates
only. All fence and gates must be installed to
conform with B.O.C.A. Specifications and/or
local building code regulations.
2" between property
line and string
(See note above)
2"
S
TRENGTH OF
DT3336-60

1. Layout and Planning

PROPERTY
LINE
FIGURE 1
STRING LINE
1/8" between
post and string
B
Note: Local municipalities may require a
setback from property line to fence line,
otherwise, it is recommended to be 2"
inside the property line. It is important to
find out all the requirements before
installing your fence.
1.1. First stake out the area and run strings around
as shown in Figure 1. Gates need to be located
on level ground.
1.2. Proceed to dig post holes approximately 3" to
4" wider than the gate on centers
2 (on next page) for post hole depth.
1.3. Be sure to separate the gate posts from other
fence posts. Gate posts have a thicker wall
than other fence posts. To prevent your fence
from running short of the next gate post DO
NOT install more than one gate for each line
of fence to be installed. Additional gates will
be installed when the fence reaches the desired
gate location.
CAUTION: In areas where ground frost
occurs extend the concrete footing below
the frost line.
NOTE: Local municipalities may require
different hole depths than those shown
below. You must verify that these depths
meet all local building codes.
EAUTY
See Figure
1
