DIAMOND PACIFIC 100-PTS-105 Owner's Manual

Pixie trim saw
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Owners Manual
PIXIE TRIM SAW
100-PTS-105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 100-PTS-105 and is the answer not in the manual?

Questions and answers

Related Manuals for DIAMOND PACIFIC 100-PTS-105

Summary of Contents for DIAMOND PACIFIC 100-PTS-105

  • Page 1 Owners Manual PIXIE TRIM SAW 100-PTS-105...
  • Page 2 INSTRUCTIONS PIXIE TRIM SAW ATTACHMENT The Pixie Trim Saw Attachment has three main components: The blade together with its adaptor. The table. The blade guard. The blade is held onto the adaptor between a fixed flange and a removable flange that is held against the blade by a socket head cap-screw.
  • Page 3 Thread the blade and adaptor onto the end of the Pixie shaft. Hand tight is sufficient. Turn the table upside down and wet the sponges thoroughly. Slide the table into place from the front. Lower the blade guard over the blade and into place at the rear of the table.
  • Page 4 Parts and Accessories Description Order Number Water aid (8 ounce) 410-WA-108 Water aid (16 ounce) 410-WA-116 Replacement Blade 6 x .020 300-0602050-83 Blade Dressing Stick (cut through 109-SS-05 2 to 3 times to sharpen blade) Orders/Technical Support: Toll Free: (800)253-2954 Outside US: (760)255-1030 Fax: (760)255-1077 E-mail: diamondpacific@aol.com...
