Summary of Contents for DAE Pumps Sonora S330
- Page 1 Instruction Manual Sonora S330...
- Page 2 Original instructions Printed matter N° 2954 8980 01 04/2019...
- Page 3 Neglecting maintenance or making changes to the setup of the machine can result in major hazards. While every effort has been made to ensure that the information in this manual is correct, DAE Pumps does not assume responsibility for possible errors.
-
Page 4: Table Of Contents
Table of Contents Warranty ......... . . 27 Operating instructions . -
Page 5: Safety Precautions
INTRODUCTION neering practices and to observe all relevant local The policy of DAE Pumps is to provide the users of ing danger. safety requirements and ordinances. their equipment with safe, reliable and efficient prod- ucts. -
Page 6: Authorised Personnel
Not observing the safety instructions may lead to per- Do not abuse the power cable. Never use the power pair on DAE Pumps equipment. sonal injury, damage to the equipment and environ- cable to carry the pumps or pull the plug from an out- mental hazards. -
Page 7: General Description
General description Sonora dewatering pumps are electrical submersible IMPELLER The Sonora S330 pumps are equipped with a high pumps for dewatering applications in construction sites, industry, mining, tanks, pools etc. The range chrome steel impeller. consists of several dewatering pumps, all designed for though pumping in demanding applications. -
Page 8: Main Parts
Main parts Reference Name Cable Plug Coupling Discharge Oil plug Strainer Handle Holder for float switch (option) Data plate Float switch (option) Volute Bottom plate... -
Page 9: Options
Options FLOAT SWITCH MOTOR PROTECTION PLUG After a fault the pump must be restarted manually pressing the switch on the external motor protector. SUPPLY CONTROL RELAY The Sonora pumps can be equipped with a built-in supply control relay. Features Pump protection, the pump will stop in case of: •... -
Page 10: Low Suction Collar
Supply control relay LOW SUCTION COLLAR Reference Name Zinc anode 3081690475 Zinc anode kit Sonora S330 When pumping salt water (which is highly aggressive towards aluminum), the pump should be protected with zinc anodes. EPOXY COATING For optimum protection when pumping salty water,... -
Page 11: Operating Instructions
Operating instructions TRANSPORT The minimum start water level is approx.: Run the electric cable so that sharp bends are avoided and there is no danger of the cable being pinched or 150 mm otherwise being damaged. Always use the handle to lift the pump. -
Page 12: Stopping
STOPPING Take the plug out of the socket and take the pump out of the pump site. If the pump has been operating in dirty water, allow it to run in clean water for a short period or flush clean water through the discharge port. If clay, cement or other sticky dirt remain in the pump this may clog the impeller and seal area. -
Page 13: Maintenance
Maintenance PREVENTIVE MAINTENANCE SCHEDULE Service task Every month Every 3 months Every 6 months Every 12 months in use When worn Check cable / replace cable when jacket is damaged Check cable seal Check pipes, hoses, valves Check float switch / Level sensor function Check for external damage, loose parts Oil check * Oil change after 6 months or when contaminated with water... -
Page 14: Thermal Switches In Windings, 3-Phase
THERMAL SWITCHES IN WINDINGS, 3- PHASE If either of the three thermal contacts in the winding is found defect the circuit can be repaired if the defect thermal contact is bypassed according to the below scheme. If more than one thermal contact is found de- fect the stator must be replaced. -
Page 15: Oil
Take an oil sample using a pipette. Check for impuri- ties and emulsification. (Oil must be clear.) If water intrusion has occurred the seal must be replaced and the seal chamber refilled with fresh oil. Refer to sec- tion Spare parts [33] for type and quantity of oil. Reference Name Plug... -
Page 16: Troubleshooting
Troubleshooting Problem Cause Action Pump's ca- 1. Wrong pump rotation (if no built in supply control relay) 1. Correct the phase sequence by shifting two out of three phases and start the pump again pacity is too 2. Pump not enough submersed 2. - Page 17 Problem Cause Action Pump starts 1. Pump motor overheat 1. Raise water level and stops For Sonora Sludge pumps, water level can be too low for sufficient cooling. Lay the pump down. 2. Back running water 3. Wrong adjusted level control Water temperature too high, decrease temperature 4.
-
Page 18: Technical Details Impeller Material
Technical details Impeller material Sonora S330 Unit The pump is not to be used in explosive or inflammable environ- ments or for pumping flammable liquids Discharge, Hose Dis- inch charge, threaded (ISO- inch G&NPT) DIMENSIONS Weight kg/lb 25/55 Max solids handling Ø50/2... -
Page 19: 1-Phase, 50 Hz
MOTOR DATA Sonora S330 1-phase, 50 Hz Max power input 2.2 kW Voltage (V) Rated current (A) 3-phase, 50 Hz Max power input 3.3 kW Voltage (V) Rated current (A) 3-phase, 60 Hz Max power input 3.6 kW Voltage (V) Rated current (A) 10.4... -
Page 20: Wiring Diagram
WIRING DIAGRAM 1-phase stator... -
Page 21: Motor Data Weda S30
6-lead stator & contactor... - Page 22 9-lead stator & contactor...
- Page 23 12-lead stator & contactor...
- Page 24 6-lead stator terminal board 9-lead stator terminal board...
- Page 25 12-lead stator terminal board...
-
Page 26: Flow Characteristics
FLOW CHARACTERISTICS Sonora S330 50Hz Sonora S330 60Hz 16,0 14,0 Power Power 3-Ph 3-Ph 12,0 10,0 Power 1-Ph Power 1-Ph Head Head Head 3-Ph Head 3-Ph 1-Ph 1-Ph 1 000 Flow [l/min] Flow [USGPM]... -
Page 27: Spare Parts
2. Pump serial number In the event of a warranty claim please contact your 3. Quantity required local dealer or the nearest authorized DAE Pumps 4. Part number Customer Service Center. 5. Part description... -
Page 28: Disposal
Recycling and disposal policies are part of the devel- cable disposal regulations. opment of all DAE Pumps products. DAE Pumps Remove spilled fluid mechanically; pick up the rest company standards determine strict requirements. using an absorbing agent (for example sand, sawdust) -
Page 29: Declaration Of Conformity
