- Page 1 S H O W E R S F I T T I N G G U I D E...
- Page 2 GENERAL FITTING GUIDE CONCEALED 2/3/4 WAY DIVERTER VALVE PRODUCT SHOWN WILL VARY DEPENDING ON MODEL Important Information (Please leave this installation & user guide with the end user) This installation guide is for a concealed 2/3/4 way diverter valve. It covers the installation and operation of the fitting.
- Page 3 Components List Key Dimensions OUTLET BLANKING CAP (Fit where applicable) OUTLET OUTLET DIVERTER G.1/2 G.1/2 CARTRIDGE OUTLET G.1/2 OUTLET G.1/2 DIVERTER CARTRIDGE COVER COLLAR FIXING LUG DIVERTER GUIDE CONCEALING BODY PLATE SLEEVE DIVERTER SPINDLE DIVERTER LOCKING BUSH INLET RING G.1/2 BUSH OPERATING SCREW...
- Page 4 Operation Turning the operating handle will switch the water flow between the various outlet options (up to four) Two blanking caps are supplied to allow the installer to cap off any ports that are not required. This diverter valve is designed to operate only one shower accessory at a time, and they are not designed for a “split”...
- Page 5 A S Q U I T H S B A T H R O O M S . C O M...
