- Page 1 S H O W E R S F I T T I N G G U I D E...
- Page 2 GENERAL FITTING GUIDE CONCEALED SINGLE LEVER MANUAL SHOWER VALVE (with and without diverter) PRODUCT SHOWN WILL VARY DEPENDING ON MODEL Important Information (Please leave this installation & user guide with the end user) This installation guide is for all single lever manual shower valve models. It covers the installation and operation of the shower valves.
- Page 3 Components List (Single Outlet) Key Dimensions (Single Outlet) VALVE BODY FIXING LUG CARTRIDGE GUARD FIXING LUG WATER OUTLET SQUARE CARTRIDGE PEG CERAMIC DISC LOCKING RING FLOW CONTROL INLET G1/2" CARTRIDGE INLET G1/2" INLET G1/2" CARTRIDGE COVER CONCEALING PLATE SINGLE LEVER HANDLE GRUB SCREW FINISHING BUTTON...
- Page 4 Technical Data Min operating pressure: 0.5 bar (3 bar if using Bath Filler) Max operating Pressure: 5 bar Operation All Models: Pull the single lever handle towards you to activate the flow of water. Turn the single lever handle clockwise to increase the water temperature, and turn anti-clockwise to reduce the temperature.
