  • Page 1 ZERONE Electrosurgical Unit ZEUS-200S / 150 OPERATION MANUAL ZERONE CO., LTD.
  • Page 2 ZEUS-200S/150 ZO-OM-007 ZEUS-200S/150 Operating manual ZERONE CO., LTD...

  • Page 3: Table Of Contents

    ZEUS-200S/150 ZO-OM-007 - Contents - 1. INTRODUCTION ......................2 1.1 P ........................2 RIOR OTICE 2. INSTALLATION NOTICE ....................7 2.1 B ......................7 EFORE PPLICATION 3. APPLICATION NOTICE ....................9 4. FOLLOW-UP WAYS FOR STORAGE AND MAINTENANCE ........12 5.

  • Page 4: Introduction

    How to Contact Us ● - Contact us on the following telephone numbers and address in order to receive our service and products. For Supplying ZERONE Co., Ltd. Products and (Shinil IT UTO Bldg., Dangjeong-dong) Ordering Supplies #810, LS-Ro 13, Gunpo-si, Gyeonggi-do, Korea...
  • Page 5 ZEUS-200S/150 ZO-OM-007 Warranty Period ● - This product was made under the strict quality control system and inspections. - The warranty period is one year. - Compensation standard for repairs and replacement complies for “Guidelines for Consumer Protection” quoted by the Korean Economic Planning Board.
  • Page 6 ZEUS-200S/150 ZO-OM-007 Warning, Caution, Notice ● This manual adopts several terms to draw your attention to what must be informed of or aware of. Please read carefully and be fully aware of them before you start operating the equipment. Warning Serious physical injury.
  • Page 7 ZEUS-200S/150 ZO-OM-007 Signs ● Symbol Description Type CF Applied Part RF Isolated : Count electrode isolated to an earth for high frequency Refer to the manual Non-ionizing Radiation This equipment intentionally supplies non-ionizing RF energy for physiological effect. High Voltage Warning...
  • Page 8 ZEUS-200S/150 ZO-OM-007 Cautions ● - Do not use/store this equipment under the following environments. Wet hands or humid Direct rays. areas. Out of these temperature and humidity ranges: Near to electronic T:10℃ ~ 40℃, heaters. H: 20%~ 95%. Areas with high humidity Excessive shock or or ill ventilation.

  • Page 9: Installation Notice

    Unused accessories (active electrode) must not be placed on the patient body. ⑥ ZERONE Co., Ltd. Supplied accessories have appropriate for rating for ZEUS-200S/ 150. CE marked or UL approved components with more than Monopolar: 1800Vpp, Bipolar: 500Vpp rated voltage rating can be used as accessories.
  • Page 10 It is recommended that Patient Return Plate be applied to REM system of ZERONE Co., Ltd. Monitors the size of contact area between a patient and the pad. If the size is inappropriate, it automatically blocks the high-frequency current to minimize the danger of burning incidents ①...

  • Page 11: Application Notice

    ZEUS-200S/150 ZO-OM-007 ① Warning : To avoid the risk of electric shock, this equipment must only be connected to a supply mains with protective earth ② Use the power code provided by the equipment supplier or a other test-completed product that has equal quality.
  • Page 12 ZEUS-200S/150 ZO-OM-007 About Patients ● Warning Check the followings before using this product. ① Eliminate or isolate all the patient’s metal materials and handle them with special interests. ② A patient must be isolated from grounded metal materials. Be careful to see if they are contacted to the patient.
  • Page 13 ZEUS-200S/150 ZO-OM-007 ⑨ Extreme caution must be taken for patients with pacemaker or implantable electrode. Performance of devices may be temporarily affected which may cause ventricular fibrillation. In case of any doubts concerning safety of patient contact qualified and concerned pacemaker manufacturer or Cardiology department.

  • Page 14: Follow-Up Ways For Storage And Maintenance

    ZEUS-200S/150 ZO-OM-007 ③ If Dispersive Electrode is not closely adherent to the patient body, he/she can get a burn sine high frequency current flows between Dispersive Electrode and the skin. When using Patient Plate, you should bind it by something like band, after putting gel all over the patient skin on which Patient Plate will be adhered in order it to be adhered to the patient skin completely.

  • Page 15: Configuration

    ZEUS-200S/150 ZO-OM-007 Warning Check the followings before using this product. ① During sterilization, don’t increase temperature and pressure more than the standard, which can cause damage to the accessories. ② Don’t sterilize disposable accessories. 5. Configuration 5.1 Feature ① A DISPLAY window allows you to easily check output values, indicated as digits.

  • Page 16: Safety Function

    ZEUS-200S/150 ZO-OM-007 ⑬ If the area between a patient and the pad is not appropriate, REM(Return Electrode Monitoring) gives the alarm with a warning sound and stop an operation of the product to prevent a burning incident. ⑭ The level of alarm sound can be adjusted during an operation of application mode.

  • Page 17: Configuration And Accessories

    ZEUS-200S/150 ZO-OM-007 Intended Patient Population ● Considerations Requirement description No limitation Check a marking in kg indicating the maximum a Weight patient weight on end use packaging for Disposable Patient Return Plate Except patients implantable Healthy pacemakers or implantable defibrillators transplant.

  • Page 18: Name And Function Of Each Part

    ZEUS-200S/150 ZO-OM-007 5.5 Name and Function of Each Part Front Side ● ③ Coagulation Mode ① Power Switch ② Cutting Mode ④ Connection to Patient Plate ⑤ Connection for Bipolar Forceps ⑥ Connection 1 for Cutting, Coagulating Electrode ⑦ Connection 2 for Cutting, Coagulating Electrode Back Side ●...
  • Page 19 ZEUS-200S/150 ZO-OM-007 ① Power ON / OFF Switch ② Cutting Mode ⓓ Cutting Output Confirmation Lamp ⓔ Cutting Output Set-Up Indicator ⓐ Pure Cutting ⓑ Coagulation Blend Cutting 1 ⓒ Coagulation Blend Cutting 2 ⓕ Cutting Output Decrease ⓖ Cutting Output Increase ⓐ...
  • Page 20 ZEUS-200S/150 ZO-OM-007 ③ Coagulation Mode ⓓ Coagulation Output Set-Up Indicator ⓔ Coagulation Output Confirmation Lamp ⓐ Contact Coagulation ⓑ Spray Coagulation ⓒ Bipolar Coagulation ⓕ Coagulation Output Increase ⓖ Coagulation Output Decrease ⓐ Contact Coagulation Select this button for the coagulation with the minimized level of arrest of bleeding.
  • Page 21 ZEUS-200S/150 ZO-OM-007 ④ Connection for Patient Plate - Applied part Use Patient Return Electrode when using Monopolar. If Patient Return Cable is not proper to use, the alarm sound rings and the lamp above is blinked. ⑤ Connection for Bipolar Forceps - Applied part Connection Terminal for Bipolar Forceps ⑥...
  • Page 22 ZEUS-200S/150 ZO-OM-007 ③ Reusable Monopolar Handle Connect it to the terminal of Connection2 for Cutting and Coagulation Electrode. The yellow pedal is for Cutting and the blue is for Coagulation. Cable 3m, Rated Voltage: 3000Vpp ④ Reusable Patient Return Plate Cable Connect it to the connection part of Patient Plate.
  • Page 23 ZEUS-200S/150 ZO-OM-007 ⑨ Electrodes Use it during Cutting and Coagulation Knife Electrode 2.4 * 70mm Needle Electrode 2.4 * 70mm Needle Electrode(Angled) 2.4 * 70mm Ball Electrode 5mm Loop Electrode 6mm Accessories (Optional Products) ● ① Reusable Patient Plate Connect it to the connection part of Patient Plate.

  • Page 24: Using Method And Procedure

    ZEUS-200S/150 ZO-OM-007 5.6 Using Method and Procedure Monopolar ● ① After confirming power and voltage (AC120V/AC230V), connect a ground power cable to the power connection part on the back side of Electrosurgical Unit. If there is no ground at Main Power, link an earth ground to the ground connection on the back side of the product.
  • Page 25 It is possible to switch between Auto Mode and Manual Mode, by pressing the Bipolar mode button and Power ON. Notice The factory default mode of ZEUS-200S/150 is Auto Mode. In changing Mode(Auto Mode, Manual Mode), power OFF first, press Bipolar mode button, and power ON again.

  • Page 26: Accessory Diagram

    ZEUS-200S/150 ZO-OM-007 5.7 Accessory Diagram Diagram of Twin Button Handle and Patient Return Plate Cable ● (Twin Button Handle) (Silicone Patient Plate) (Patient Return Plate Cable) Diagram of Monopolar Handle and Patient Return Plate Cable ● (MonoPolar Handle) (Silicone Patient Plate)
  • Page 27 ZEUS-200S/150 ZO-OM-007 Diagram of Double Foot Switches ● (Double Foot Switch) Diagram of Bipolar Forceps and Cable ● (Bipolar Forceps) REV : 08 ZERONE...

  • Page 28: Periodic Inspection

    ZEUS-200S/150 ZO-OM-007 6. Periodic Inspection Every six months, visually inspect the ZEUS-200S/150 Electrosurgical Generator for signs of wear or damage. In particular, look for any of the following problems: ✓ Damage to the power cord ✓ Damage to the power cable receptacle ✓...

  • Page 29: Output

    ZEUS-200S/150 ZO-OM-007 7.2 Output ZEUS-200S ● Tolerance : ±20% Mode output power Carrier Crest Duty Repeat Freq. Factors Rate Freq. Pure Cut 200W at 200ohm 400 ㎑ 100% Continuous Blend1 150W at 200ohm 400 ㎑ 33 ㎑ Blend2 120W at 200ohm 400 ㎑...

  • Page 30: Standard Output Table By Surgery Part

    ZEUS-200S/150 ZO-OM-007 8. Standard Output Table by Surgery Part Coagulation Coagulation Part Cut Mode Bi-coag. POWER(W) Mode POWER(W) Pure or 10~120 Skin Incision Blend1 8~100 Muscle Pure or Above 15 Dessection Blend1 Above 15 Tumor Blend2 15~70 Spray 10~15 Excision...

  • Page 31: Troubles And What To Do With Them

    ZEUS-200S/150 ZO-OM-007 9. Troubles and What to do with them There are no lights on the Display Number window. ● 1. Check if the power cord is connected to the power cord input plug on the back side of the surgery unit.

  • Page 32: Load Regulation

    ZEUS-200S/150 ZO-OM-007 10. Load Regulation 10.1 Pure Cutting 10.2 Blend1 1… 10.3 Blend2 REV : 08 ZERONE...

  • Page 33: Contact Coagulation

    ZEUS-200S/150 ZO-OM-007 10.4 Contact Coagulation 8… 4… 10.5 Spray Coagulation 8… 10.6 Bipolar Coagulation REV : 08 ZERONE...

  • Page 34: Voltage Output Graphic

    ZEUS-200S/150 ZO-OM-007 11. Voltage Output Graphic 11.1 Pure Cutting (Load 200Ω) Max Peak Output Voltage : 315Vp Watt 11.2 Blend1 (Load 200Ω) Max Peak Output Voltage : 325Vp Watt 11.3 Blend2 (Load 200Ω) Max Peak Output Voltage : 340Vp Watt...

  • Page 35: Contact Coagulation

    ZEUS-200S/150 ZO-OM-007 11.4 Contact Coagulation (Load 200Ω) Max Peak Output Voltage : 350Vp Watt 11.5 Spray Coagulation (Load 500Ω) Max Peak Output Voltage : 700Vp Watt 11.6 Bipolar Coagulation (Load 100Ω) Max Peak Output Voltage : 130Vp Watt REV : 08...

  • Page 36: Appendix

    Table 201 Guidance and manufacturer’s declaration – electromagnetic emissions ZEUS-200S/150 model is intended for use in the electromagnetic environment specified below. The customer or user of the ZEUS-200S/150 model should ensure that it is used in such an environment. Emissions test...
  • Page 37 Guidance and manufacturer’s declaration – electromagnetic immunity ZEUS-200S/150 model is intended for use in the electromagnetic environment specified below. The customer or user of the ZEUS-200S/150 model should ensure that it is used in such an environment. Emissions test EN/IEC 60601 test...
  • Page 38 ZEUS-200S/150 model is intended for use in the electromagnetic environment specified below. The customer or user of the ZEUS-200S/150 model should ensure that it is used in such an environment. Emissions test...
  • Page 39 ZEUS-200S/150 ZO-OM-007 Table Test specifications for Enclosure port immunty to RF wireless communications equipment Maximu Test Immunity Band Distance frequency Service Modulation Test level (MHz) Power (MHz) (V/m) 380-390 TETRA 400 Pulse modulation 18Hz 430-470 GMRS 460, FM ±5 kHz deviation...
  • Page 40 (zip 435-831) Phone : +82 31 427 2772 : +82 31 427 2332 ※ Thanks for purchasing of ZEUS-200S/150 from ZERONE Co., Ltd. ※ This product is made under thorough quality control and passed strict inspections. REV : 08 ZERONE...
  • Page 41 ZEUS-200S/150 ZO-OM-007 Document History REV.No Edited Date Corrections 2006.06.08 Initial issued 2009.06.12 Add 200S MODEL 2012.04.25 Change address 2013.09.10 Applied to 60601-1 3rd Edition. 2016.06.16 Add Caution 2016.10.12 Change of address (European agent) 2016.11.10 Add Caution 2017.06.08 Change CE number 2019.03.02...
