RaPTr (Rapid Pallet Tracker) Gen 3c
QUICK START GUIDE
This guide is intended to help you get up and running quickly, but we strongly recommend that you familiarize yourself with
and refer to all documentation provided in its entirety.
QUICK START ASSEMBLY
1
Open camera canister
and insert camera sled
into slots. There will be an
audible click.
4
Attach a monitor to
desired location.
(image is example)
2
Plug camera USB into
back of camera and
thread cable through
hole at bottom of
camera canister.
5
(If applicable)
Attach additional cameras
where needed.
3
Attach main unit to
desired location.
(image is example)
6
Plug in all other cables. Connect your own
keyboard, monitor, and mouse as needed.
1
CONTINUED
Advertisement
Related Manuals for Artemis Vision RaPTr Gen 3c
Summary of Contents for Artemis Vision RaPTr Gen 3c
- Page 1 RaPTr (Rapid Pallet Tracker) Gen 3c QUICK START GUIDE This guide is intended to help you get up and running quickly, but we strongly recommend that you familiarize yourself with and refer to all documentation provided in its entirety. QUICK START ASSEMBLY Open camera canister Plug camera USB into Attach main unit to...
- Page 2 Artemis Vision RaPTr (Rapid Pallet Tracker) | Quick Start Guide QUICK START SET - UP PROCEDURE Place pallet in area where you Launch RaPTr Position camera canister so that image of want to capture barcodes. software pallet is visible on screen, with barcode in (desktop icon).
- Page 3 Artemis Vision RaPTr (Rapid Pallet Tracker) | Quick Start Guide QUICK START SET - UP PROCEDURE, CONTINUED Green bars confirm readability. Adjust as Adjust additional system parameters by each tab at top needed. If necessary, you can also adjust of screen.
- Page 4 Artemis Vision RaPTr (Rapid Pallet Tracker) | Quick Start Guide info@artemisvision.com (303) 832-1111 www.artemisvision.com...
