- Page 1 ■ Version：A2 ■ No.：WI-Vision-0024 ■ Release Date: 2021/05/12 Suzhou Melodicare Medical Technology Co., Ltd...
- Page 2 Vital Signs Monitor User Manual Model: Vision...
-
Page 3: Table Of Contents
Contents WARNING··················································01 I COMPANY PROFILE········································03 II PRODUCT DESCRIPTION···································03 Ⅲ PRODUCT SPECIFICATION·································06 Ⅳ SETUP AND OPERATING···································07 V MAINTENANCE···········································17 VI OBSOLETE EQUIPMENT MANAGEMENT·······················18 VII QUALITY ASSURANCE·····································19 VIII ELECTROMAGNETIC COMPATIBILITY INFORMATION············19... -
Page 4: Warning
Warning 1.Do not replace the battery without training, to avoid a series of dangerous situations such as battery over-heating, fire or explosion. 2.Do not calibrate it yourselves. The calibration is done before delivery. Please contact the manufacturer when calibration is needed. 3.The patient is the intended operator. - Page 5 【Contraindications】 1.People who have an implanted pacemaker should use the device with caution. 2.Patients should be cautious to use the device when suffering serious heart disease. 3.Do not use the blood pressure function with an injured arm. 4.Children or the people who cannot express their thoughts shall use the device under supervision.
-
Page 6: I Company Profile
Ⅰ COMPANY PROFILE 1.Company Name: Suzhou Melodicare Medical Technology Co., Ltd Address: Room 301, Building F2, No.32 Hongxi road, Suzhou high-tech zone, Jiangsu province,China. 2.Contact: Email: info@minttihealth.com Tel: +86（0）791-85230171 3.Website: www.minttihealth.com PRODUCT DESCRIPTION 1.Product Features The unit has multi functions of measuring heart rate, body temperature, blood pressure and blood oxygen. - Page 7 3.Product Classification According to the protection of the risk of electric shock, this product is classified as class Ⅱ type equipment. Type BF: Cuff；Type CF: ECG electrode, temperature probe, blood oxygen probe. 4.Operating Environment Vital Signs Monitor operating environment as follows: a) Environment temperature: +5℃...
- Page 8 Note: 1. ECG electrodes part should not be placed near conductive materials such as magnets. 2.If the electrode and sensor of the device are loose or damaged, the corresponding function will not work properly, please contact our staff for return to the factory for repair. 6.Explanation of Symbols on Unit BF type application Scrap electrical...
-
Page 9: Ⅲ Product Specification
Ⅲ PRODUCT SPECIFICATION Model: Vision Power voltage: DC3.7V Size: 70mm*70mm*18.4mm Weight: approximately 70g Wireless communication: Bluetooth 4.0 operating frequency: 2.4000GHz-2.4835GHz Blood pressure/heart rate Measuring method: oscillometric method Cuff perimeter: 22-35cm Measuring range: Blood pressure 0-300mmHg Systolic pressure: 60-260mmHg Diastolic pressure: 40-199mmHg Heart rate: 40-180bpm Measuring error: blood pressure ±3 mmHg Heart rate ±5%... -
Page 10: Ⅳ Setup And Operating
Safety classification: this product should not be used under mixed gases of flammable anaesthetics and air mixture of oxygen or nitrous oxide environment. Ⅳ SETUP AND OPERATING PROCEDURES Set up Requirements The Vital Signs Monitor is designed to be used with the following required device: a)Bluetooth 4.0 b)Android 5.0 system or newer, iOS 9.0 or newer system. - Page 11 Turn on/off the Unit a)Turn on: long press the power button for 2s, the unit will gently vibrate. The power LED indicator is flashing blue light. b)Turn off: long press the power button for 2s, the unit will gently vibrate. The power indicator is dark. c)Connected and measuring: the power LED indicator is steady blue.
- Page 12 Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Please check whether The smart the smart phone's Can not phone does not Bluetooth and operation download the APP conform with the system conforms with the requirements requirements. Can not Turn on the unit first then be automatically Incorrect operation login in the app, or connect...
- Page 13 please make sure the middle of the cuff should be placed at the same level as your heart. 1） Stay calm and rest for at least 5 minutes before blood pressure measurement. Remove clothes from your arm or wear thin clothes to test. 2）Put the multifunctional Vital Signs Monitor to the cuff in a correct position, making sure that the bottom edge of the cuff is approximately 1 to 2 cm above the elbow, loosen or tighten it as long...
- Page 14 CAUTION Avoid eating, drinking, coffee, smoking, exercising and showering for at least 30 minutes before taking a measurement, please rest at least 5 minutes. Please ensure testing under a resting state, maintain emotional balance and make sure you do not need to urinate, and then take the measurement in a correct gesture.
- Page 15 Troubleshooting for blood pressure/heart rate PROBLEM POSSIBLE CAUSE SOLUTION Review the body posture, apply the cuff The cuff position was correctly, and please not correct; speaking Abnormal result (too stay calm during or body movement low value) the process. For during testing;...
- Page 16 The interval between monitor probe and forehead should be 1 to 2cm Sensor of temperature aim to forehead CAUTION Clean your forehead before measuring. Do not use temperature probe to directly touch your forehead skin. Please try to take measurement under a stable environment; do not measure in the direction of the Spacing or air-condition wind flow or places under direct sunlight.
- Page 17 Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Clean the forehead before Sweat/oil/ dirt on measurement, stay dry and forehead clean for the measuring part The interval between Measured error monitor probe and Measured distance forehead should be 1 to was too far 2 cm according to the requirement Blood Oxygen Measuring Guidance...
- Page 18 CAUTION The Vital Signs Monitor should be horizontally placed during the measurement. It's recommended to measure using the middle finger, with nails facing upwards. DO NOT move the finger during the measurement. There are some differences on the blood pressure, blood circulation, physiological features on different fingers, hence try to use the same finger to take measurements.
- Page 19 ECG Measuring Guidance Basic Knowledge of ECG Heart rate variability: means to monitor the autonomic nervous activity of the heart. Instruction 1.Hold the deivce by left hand, and the thumb touches the metal part on the top of blood oxygen sensor, other fingers touch the metal label at the back of device.
-
Page 20: Maintenance
Ⅴ MAINTENANCE Maintenance under the following principles 1.Do not rinse the cuff with running water, clean the cuff with a dry and soft cloth if it is needed. 2.Do not use moistened cloth to wipe the Vital Signs Monitor because it is not waterproof. -
Page 21: Obsolete Equipment Management
Ⅵ OBSOLETE EQUIPMENT MANAGEMENT On the premise of the correct use of this product, the service life cycle of this product is 3 years. The cuff can be replaced if it is damaged. After correct use of 3 years, the device cannot be repaired and its safety performance cannot meet the requirement, then the device should be scrapped. -
Page 22: Quality Assurance
Ⅶ QUALITY ASSURANCE In terms of the unit, Minttihealth guarantee services as follows: 1. Products can be refunded, replaced or maintained free within 7 days after sale, under the usage of instruction sheet. Products can repaired for free within 1 year after sale in the precondition of non artificial damage. - Page 23 If it is a must to be used beside other devices and or stacked with other device, should be care the unit closely to insure its normal operation. 5.Only use the replaceable electrical components and parts provided by Minttihealth. Electromagnetic Emissions —The monitor is intended for use in the electromagnetic environment specified below. The customer or the user of the monitor should ensure that it is used in such an environment.
- Page 24 Electromagnetic Immunity—The monitor is intended for use in the electromagnetic environment specified below. The customer or the user of the MONITOR should assure that it is used in such an environment. IEC 60601 test Electromagnetic IMMUNITY test Compliance level level environment-guidance Floors should be wood, concrete or...
- Page 25 Electromagnetic Immunity —The monitor is intended for use in the electromagnetic environment specified below. The customer or the user of the MONITOR should ensure that it is used in such an environment. IEC 60601 Compliance Electromagnetic environment - IMMUNITYtest test level level guidance Recommended separation distance...
- Page 26 Recommended separation distances between portable and mobile RF communications equipment and the Monitor. The Monitor is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Wireless Blood Pressure Monitor can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the MONITOR as recommended below, according to...
- Page 27 Package Contents Items Num. Vital Signs Monitor Cuff User manual Warranty Card QC Certificate USB Line...
- Page 28 Suzhou Melodicare Medical Technology Co., Ltd. Address: Room 301, Building F2, No.32 Hongxi road, Suzhou high-tech zone, Jiangsu province,China. Contact: +86(0)791-85230171 E-mail: info@minttihealth.com www.minttihealth.com Share Info Consultant Service LLC Repräsentanzbüro Address: Heerdter Lohweg 83, 40549 Düsseldorf Tel:0049 1767 0057022 Fax:0049 1767 0057022...
