Hallis Hudson DUAL RISE Quick Start Manual

Professional Dual Rise
Roman Blind System

adjust your spools...

Step 1. Ensure the cords are fully unwound.
Step 2. Remove the cord from the cord guide.
Step 3. Pull the grey button..
Step 4. Re-position your spool and push each grey button
down to lock them into place.
Step 5. Re-attach the cord to the cord guide, at the opposite
end of the spool.
IMPORTANT: please check all grey buttons have been pushed down and the cord is attached to the cord guide before operating your blind.
change the control side of your
Dual Rise Roman Blind...
Step 1. Using a T10 torx allen key undo both screws on the
underside of the blind being careful not to fully undo.
Step 2. Pull out the Dual Rise gear mechanism from the head-
rail then turn the blind back over.
Step 3. Pull the mechanism completely out of the headrail and
undo the screw which secures the axle rod to the gear housing.
Step 4. Re-fit the axle rod at the opposite end of the blind
making sure its securely held in place, then push the Dual Rise
mechanism back inside the headrail about ¾ of the way in.
Step 5. Turn the headrail over and lift the flap up and push the
gear housing all the way in securely, then tighten both screws
with a T10 torx allen key.
Step 6. Re-adjust the position of your spools accordingly making
sure both the grey buttons are ushed down firmly and the cord
is properly fed through the cord guide.
fit a longer chain or wand to
your Dual Rise Roman Blind...
Step 1. Pull back the white cover and remove the chain from
the clear clip.
Step 2. Slide the cord pull up the chain to reveal the connector.
Step 3. Unclip the cord connector from the chain.
Step 4. Using a small pick or similar pull back the white cap
from one of the Dual Rise cords to reveal the ball chain
connector.
Step 5. Attach your new chain or wand to the ball chain
connector.
Step 6. (Skip this step if you have fitted a wand) Take your
chosen cord pull and pass your chain through the small
opening then fit the 0908R connector to the bottom of the
chain. Repeat steps 4,5 & 6 for the other Dual Rise cord.
