- Page 1 CALLIFREEZE® USER’S GUIDE Document No: CALLIFREEZE-2021-1 September 2021...
-
Page 2: Contact Information
1 Contact information Aquantis S.A. Aquantis Belgium B.V.B.A. EPFL Innovation Park Bâtiment C Generaal De Wittelaan 17C CH-1015 Lausanne B-2800 Mechelen Switzerland Belgium Tel: +41 79 159 97 25 Tel: +32 15 68 24 21 E-mail : info@aquantis.org Website : www.aquantis.org... -
Page 3: Table Of Contents
8.2.2 Connecting to the sensor via the network infrastructure ............17 User Interface ..........................18 8.3.1 Webserver interface ........................18 8.3.2 Modbus TCP/IP interface......................23 Maintenance & Disposal .......................... 25 Daily maintenance.......................... 25 Yearly maintenance ........................25 CALLIFREEZE® User’s Guide... - Page 4 Technical data ............................ 28 11.1 General specifications ........................28 11.2 Electrical specifications ........................28 11.3 Data connectivity / acquisition ....................... 28 11.4 Mechanical specifications ....................... 29 11.4.1 Materials ..........................29 11.4.2 Computer-box ........................29 11.4.3 HF measurement units ......................30 CALLIFREEZE® User’s Guide...
-
Page 5: Quick Start: Calibration And Start Up
3 About the user guide Introduction The CALLIFREEZE® is intended to continuously monitor the Level of Frozenness (LOF) of individual products (e.g., hamburger). CALLIFREEZE® is developed and manufactured by Aquantis. The product number is indicated on the device and has the format: AQFS-TS1-2021-X. Please provide the product number during every communication with Aquantis. -
Page 6: Additional Documents
CALLIFREEZE Bill of Materials (Document No: CALLIFREEZE-2021-BOM-4): Overview of the components used in the CALLIFREEZE®. This document is solely meant CALLIFREEZE manufacturers. ▪ CALLIFREEZE Product Label (Document No: CALLIFREEZE-2021-LABEL-4): The label can be found on the product. CALLIFREEZE® User’s Guide... -
Page 7: Disclaimer
4 Disclaimer In no respect shall Aquantis incur any liability for any damages, including, but limited to, direct, indirect, special, or consequential damages arising out of, resulting from, or any way connected to the use of the sensor, whether or not based upon warranty, contract, tort, or otherwise;... -
Page 8: Safety Information
If you use an extension power cable, ensure that the total ampere rating of the products plugged in to the extension power cable does not exceed the ampere rating of the extension cable. WARNING: The customer is responsible to connect all metal parts of the CALLIFREEZE® to protective earth via a low resistive path (< 1 Ohm). -
Page 9: Transport And Storage
• 1 x Set of thickness sensor mounting plates (3 pieces) If above mentioned parts are missing, please contact Aquantis immediately. Transport For your own safety and to avoid damage to the sensor due to improper transport, respect the following considerations: •... -
Page 10: Sensor Installation And Calibration
WARNING: The customer is responsible to connect all metal parts of the system to protective earth via a low resistive path (< 1 Ohm). Aquantis is not responsible for any damage or dysregulation of the system and other equipment due to no or a bad connection to earth. - Page 11 ✓ Make sure there are no other devices operating in the same frequency range: 61-62 GHz. Respect a distance of 1 m from the CALLIFREEZE® system. ✓ The cable distance between the computer-box and the HF units may not be longer than 2.5 m.
-
Page 12: Power Supply Cables
7.2.1 External power connection The CALLIFREEZE® is powered via its computer unit which further distributes the power to the distance sensor, emitter and receiver units. Please connect the main power to a single 230 VAC – 50 Hz power source with an external switch or remote relay controlled via a PLC. -
Page 13: Data Interconnection
The data streams between the computer unit, distance sensor, emitter and receiver units are shown in Figure 6. From the computing unit, an ethernet cable which can be directly connected to a pc or a network. More information can be found in the next section Connectivity. 6: D IGURE ATA SIGNAL INTERCONNECTIONS CALLIFREEZE® User’s Guide... -
Page 14: Operation
8.1.1 Power on The CALLIFREEZE® is switched on by plugging in the power cord in a socket or by supplying power via an PLC system. The sensor’s operating system boots up automatically upon switching on. This start-up phase takes a few minutes. - Page 15 STEP 4: Under the tab “Networking”, select Internet protocol version 4 (TCP/IPv4), then select properties. STEP 5: Set the settings as indicated in Figure 9 and press OK. CALLIFREEZE® User’s Guide...
- Page 16 8.2.1.2 Via the Wi-Fi hotspot The CALLIFREEZE® can also be connected via the mobile Wi-Fi hotspot. The hotspot can be found as a Wi-Fi network named according to its serial number AQFS-TS1-V4-XXXX-Y. The XXXX represents the year and Y the sensor number.
-
Page 17: Connecting To The Sensor Via The Network Infrastructure
8.2.2 Connecting to the sensor via the network infrastructure The Aquantis sensor can be connected to the network infrastructure to access it from a distance, e.g., by means of a PLC. The PC inside the computing unit has two ethernet ports. Port 1 is set for a fixed IP of 192.168.3.100. -
Page 18: User Interface
User Interface The Aquantis CALLIFREEZE® can be interfaced in via: ✓ Webserver interface (read & write) ✓ Modbus TCP/IP (read) 8.3.1 Webserver interface Note: it is advised to make use of Google Chrome version 70.x or later for consulting the sensors webpages. - Page 19 Next, the exact thickness of the reference object needs to be provided in mm with a precision of 1 digit after the comma. The same procedure is repeated for the second reference object (see Figure 13 - Figure 15). 13: T IGURE HICKNESS SENSOR CALIBRATION WIZARD THICKNESS INPUT OF REFERENCE CALLIFREEZE® User’s Guide...
- Page 20 - NO PRODUCT IGURE ALIBRATION BUTTON 8.3.1.4 TCP/IP Settings Protection level: freely accessible. The TCP/IP settings page shows the current IP aaddress. A static IP address will be active unless DHCP is used to attribute the IP address automatically. CALLIFREEZE® User’s Guide...
- Page 21 Protection level: freely accessible. The about-page contains basic information about the sensor as well as a download-link to the user-manual. 18: A IGURE BOUT PAGE 8.3.1.6 Product specifications Protection level: password protected. 19: P IGURE RODUCT SPECIFICATIONS PAGE CALLIFREEZE® User’s Guide...
- Page 22 11. SCATTERING LOSS PARAMETER 2: The product will introduce scattering losses which need to be compensated. Scattering losses are inserted in dB/mm. 12. FULLY FROZEN REFERENCE PRODUCT – CALIBRATE NOW: Static mode calibration of the sensor by taking a fully frozen product as a reference. CALLIFREEZE® User’s Guide...
-
Page 23: Modbus Tcp/Ip Interface
8.3.2.1 Introduction Interoperability between the Aquantis system and external systems is provided through Modbus over TCP/IP. The Modbus server runs on standard port 502. Through Modbus, data can be read, and some functions can be configured. Data reads are performed through the Read Holding Registers (0x03) data function, while data writes are performed either through Write Single Register (0x06), or through Write Multiple Registers (0x10). - Page 24 Product index 0x02 None Unsigned Selected product from the product database (1-12). 16-bit integer Product 0x04 None Unsigned The number of products over which the LOF value is Averaging 16-bit averaged (X=0-8, #products = 2 Intensity integer CALLIFREEZE® User’s Guide...
-
Page 25: Maintenance & Disposal
Daily maintenance On a daily base, the CALLIFREEZE® and laser distance sensor windows should be dry and clean to get the best measurement results. Dust, dirt or drops of liquid can impair the measurement result and in worst case cause wrong measurement results. -
Page 26: Troubleshooting
Once the PC is shut down, the green light will go off. After switching off the industrial PC successfully, the operator can turn it back on by pressing on the power button shortly. 6. Contact Aquantis if the above steps didn’t solve the problem. 10.2 Sensor warnings and errors The web interface indicates warnings or errors in the top-right corner of the web interface (Figure 20). -
Page 27: Returns
Description of the fault which occurred. 10.4 Repairs Repairs of the sensor are only carried out by Aquantis or Aquantis-certified engineers. Contact Aquantis for the repair of the sensor. Any manipulation or modification of the sensor can result in additional costs. -
Page 28: Technical Data
Remote interaction with the sensor via a browser ▪ DHCP client Automatic negotiation of IP address *Depending on the product type and belt. **Higher accuracy can be achieved depending on the product type and the calibration method. CALLIFREEZE® User’s Guide... -
Page 29: Mechanical Specifications
Fixation Stainless steel spacers M10 Sealing White EPDM flat seals for HF box covers & EM output cap 11.4.2 Computer-box Weight: order of magnitude of 20 kg 21: C IGURE OMPUTER UNIT OUTER DIMENSIONS UNITS IN MM CALLIFREEZE® User’s Guide... -
Page 30: Hf Measurement Units
11.4.3 HF measurement units Figure 22 shows the outer dimensions of both the emitter and receiver boxes. Weight per unit: order of magnitude of 5 kg 22: E IGURE MITTER AND RECEIVER UNIT OUTER DIMENSIONS UNITS IN MM CALLIFREEZE® User’s Guide...
