Plug and Track
Quick Installation Guide
Getting started
Before installing the TCSV12 unit, make sure
you record the unit serial number (SN) from
the label.
Many customers choose to take
1
a close-up photo of the unit. Please send this
information along with the vehicle's registration,
brief description (ie: make/model, colour, etc),
and an email address where you wish to receive
weekly reports to
systemssupport@quartix.net
after installation.
•
Park the vehicle in a safe area, outside, with a
clear view of the sky.
•
Ensure the vehicle's engine is switched off.
•
Locate the position of the 16-pin diagnostic
port for the vehicle.
usually under the dash, on either side of the
foot-well or within the centre console. It may
be necessary to remove a small section of
trim or lift an access cover. If you need help
finding the port, refer to our Plug and Track
wiki site or contact our Support team.
quartix.com/en-gb/
2
The connector is
( TCSV12 )
1
2
Issue A
Advertisement
Table of Contents
Related Manuals for Quartix Plug and Track
Summary of Contents for Quartix Plug and Track
- Page 1 It may be necessary to remove a small section of trim or lift an access cover. If you need help finding the port, refer to our Plug and Track wiki site or contact our Support team. quartix.com/en-gb/...
- Page 2 A brief description (make, model) • The email address to be used for the weekly reports Please allow one working day for Quartix to set up your vehicle details on your account. After receiving your confirmation email from Systems Support, log into quartix.com/en-gb/...
- Page 3 Lithium Polymer battery and there are no user-serviceable items inside the product. Any repair or disposal of the product must be carried out by Quartix. If the unit experiences any operational problems, contact our Support team and they will arrange for the product to be replaced.
