InFocus LP815 Lamp Replacement Update

Replacing the projection lamp

The lamp hour timer in the About menu counts the number of hours the
lamp has been in use. Fifty hours before the specified end of the lamp's life,
the message "Replace lamp" briefly appears on the screen at each startup
and in the Interactive Display. After 50 additional hours, the lamp will no
longer light. You can order new lamp modules from your dealer.
1 Turn off the projector and unplug the power cable.
2 Wait 60 minutes to allow the projector to cool thoroughly.
3 Turn the projector upside down and remove the lamp door by removing
the two screws and sliding the lamp door tabs out of the two tab bays.
4 Loosen the three captive screws on the lamp module.
About menu
turn off and unplug
audio in
R trigger
the projector
computer 2 monitor out
network mouse computer 1
USB
L
audio in computer 3 serial control
I computer in
O
remove the screws on lamp door
wait 60 minutes
loosen the screws on lamp module
