Eleshop ELE-T12A
active soldering station
MANUAL
HA N DL EID IN G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELE-T12A and is the answer not in the manual?

Questions and answers

Related Manuals for Eleshop ELE-T12A

Summary of Contents for Eleshop ELE-T12A

  • Page 1 Eleshop ELE-T12A active soldering station MANUAL HA N DL EID IN G...

  • Page 2: Specifications

    SPECIFICATIONS Maximum power Temperature range 200 - 480 °C ESD safe Display OLED Dimensions 88 x 41 x 38 mm Weight 510 gram Iron cable length 110 cm Maximaal vermogen Temperatuurbereik 200 - 480 °C ESD veilig Scherm OLED Afmetingen 88 x 41 x 38 mm Gewicht 510 gram...

  • Page 3: Package Contents

    PACKAGE CONTENTS • ELE-T12A base soldering station • T12 soldering iron • Three different T12 soldering tip • Soldering iron holder • Cleaning sponge • Brass wool • Silicon pad to exchange hot soldering tips • Power adapter • ELE-T12A basis soldeerstation •...

  • Page 4: Warning Before Use

    WARNING BEFORE USE Please read this manual carefully before first use. The manufacturer, nor the supplier, is responsible for other use than outlined in this manual or changes made by the user in the hardware or software of the soldering device and its accessories.
  • Page 5 MAINTANANCE To extend the lifespan of soldering tips, make sure to do the following: 1. Set the temperature not higher than necessary. 2. Do not leave it on high temperatures longer then necessary. 3. Do not apply pressure during soldering. Let the temperature do the work. 4.
  • Page 6 HOW TO CHANGE TIPS First, untighten the bolt and remove the shaft. Pull out the soldering tip. Then push in an other soldering tip. Make sure to push it in deep enough so that it can not go any further. Put back the shaft and tighten the bolt again.
  • Page 7 DEVICE / SCREEN OVERVIEW Current Vibration Power set temperature sensor Soldering iron usage connector Encoder / Button Current Current Inside temperature voltage working temperature of the station CHANGE SET TEMPERATURE To change the set temperature, first make sure that you are in the homescreen as displayed above in the picture.

  • Page 8: Menu Settings

    MENU SETTINGS To enter the MENU of the device, long press the encoder (± 3 sec.). Turn the encode to select the menu item you want. Confirm selection by a short press on the encoder. If you are done with changing settings and want to go back to exit the MENU (go back to the home screen), long press the encoder (±...

  • Page 9: Auto Power Off

    2. AUTO SLEEP (Sleep mode) By turning the encoder you can decide after how many minutes of the soldering iron being idle the soldering station will turn into sleep mode. You can select a value anywhere between 1-99 minutes. Temperature will then drop to 150 °C. If you never want the soldering station to enter sleep mode, you can select [OFF].
  • Page 10 4. BOOST DURATION For challenging solder tasks you sometimes need a temporary boost in temperature to e.g. quickly heat up a larger area. From the home screen of the soldering station you can activate that temporary boost by short pressing the encoder.

  • Page 11: Buzzer Switch

    7. BUZZER SWITCH In this menu item you can turn on or turn off the sound the soldering station makes, e.g. the menu confirmation sound of a sound when an error occurs. In dit menu item kunt u het geluid dat het soldeerstation maakt, bijv. het bevestigingsgeluid van het menu of een geluid bij een foutmelding, in- of uitschakelen.
  • Page 12 For more information or the latest updates, please check eleshop.eu. Questions? Contact Eleshop. Voor meer informatie of de laatste updates, kijk snel op www.eleshop.nl. Vragen? Neem contact op met Eleshop.
