GILBERTS SMOKEGARD Manual

Door, wall and partition mounting smoke and fire dampers
Hide thumbs

Advertisement

Quick Links

Download this manual
SMOKEGARD
Door, Wall and Partition Mounting
Smoke and Fire Dampers
Features
- Slimline construction.
- Smoke or fire operated.
- Stainless steel interlocking blades and side seals for maximum
smoke retardation.
- Galvanised steel frame.
- Easy key reset.
- 1 hour door & 2 hour wall mounting fire ratings.
SFB (57.9) X
UDC 697.9
DAMPERS 2 JAN 2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the SMOKEGARD and is the answer not in the manual?

Questions and answers

Related Manuals for GILBERTS SMOKEGARD

Summary of Contents for GILBERTS SMOKEGARD

  • Page 1 SMOKEGARD Door, Wall and Partition Mounting SFB (57.9) X Smoke and Fire Dampers UDC 697.9 DAMPERS 2 JAN 2013 Features - Slimline construction. - Smoke or fire operated. - Stainless steel interlocking blades and side seals for maximum smoke retardation.
  • Page 2 SMOKEGARD Door, Wall and Partition Mounting Smoke and Fire Dampers Introduction Gilberts Smokegard Dampers provide complete with in built status indicators. All units revolutionary “Engineered’ answer to the problem comprise of a Galvanised Steel Frame with of smoke and fire protection in fire doors, walls Stainless Steel Inter-Locking Blades and Side and partitions.
  • Page 3 INTERLOCKING ACTION OPPOSED BLADE FRAME CONSTRUCTION STAINLESS STEEL CONSTRUCTION Mode A Gilberts Smokegard Mode A has been designed : Reset or initial setting is ESET PROCEDURE to allow the passage of ventilation air in normal accomplished by the insertion of a special key...
  • Page 4 SMOKEGARD Door, Wall and Partition Mounting Smoke and Fire Dampers Mode A TYPE A GRILLE Dimensions FUSIBLE LINK KEY RE-SET POSITION BEHIND GRILLE LIST WIDTH +80mm LIST WIDTH +85mm SECTION THROUGH WALL/DOOR LIST SIZES AVAILABLE WIDTH 200mm in 50mm increments to...
  • Page 5 FRAME CONSTRUCTION to wiring diagram for details. Mode Gilberts Smokegard Modes B & C have been or smoke, it will interrupt the power supply to the designed to allow the passage of ventilation air in damper causing the electro magnet to release the...
  • Page 6 SMOKEGARD Door, Wall and Partition Mounting Smoke and Fire Dampers Mode B and C TYPE A GRILLE Dimensions FUSIBLE LINK LED+KEY TEST HOLES MODE C ONLY KEY RE-SET POSITION BEHIND GRILLE LIST WIDTH +85mm LIST WIDTH +80mm SECTION THROUGH WALL/DOOR...
  • Page 7 Ancillary Gilberts range of ancillary Items have been designed for use in conjunction with Smokegard Damper Modes B & C. Purpose made for straight forward connection to the units they offer a number of useful services. Items Remote Indicators Gilberts remote indicator panels can be...
  • Page 8 IMPORTANT: SMOKEGARD UNITS REQUIRE A SMOOTH AND STABILISED 24V DC SUPPLY +/- 2 VOLTS WITH A MAXIMUM 3 VOLT AC RIPPLE The Smokegard B & C Dampers are supplied pre-wired with a 5-core pvc insulated flex for connection as follows:...

  • Page 9: Installation Procedures

    Installation Door Mounted or Light Structure Partitions MODE B & C Type units will now require electrical 1. Aperture to be cut into door to match the ELECTRICAL Procedures LOOP connection before completing DAMPER size (Aperture dimensions DAMPER installation. After the aperture detailed on page 5).
  • Page 10 SMOKEGARD Door, Wall and Partition Mounting Smoke and Fire Dampers Nomogram 200x100 200x100 250x100 300x100 250x100 350x100 300x100 200x200 400x100 350x100 200x200 400x100 250x200 250x200 300x200 350x200 300x200 400x200 0.15 350x200 300x300 400x200 350x300 300x300 400x300 350x300 0.09 400x300 0.08 400x400 0.07...
  • Page 11 Test Data Introduction TANDARD TIME TEMPERATURE All fire tests where conducted by the WARRINGTON RESEARCH CENTRE BS476 PART 20 1987 CURVE OF Fire Tests to BRITISH STANDARD 476 PART 20 1987. 1200 This test describes the performance of structural elements under fire conditions, 1100 and considering there is no standard test for this type of fire damper it was decided to mount both a fusible link operated, and also an electro-magnet...

  • Page 12: Specification

    Web: www.gilbertsblackpool.com Gilberts (Blackpool) Ltd reserve the right to alter the specification without notice. For our latest product data please visit www.gilbertsblackpool.com. The information contained in this leaflet is correct at time of going to press © 2013.
