S64 Fixed Skimmer with T75F Filter Tank

S64 Skimmer & T75F Filter Tank| VanishingWater

Vanishing Water Installation

A Drain Intake allows water to drop

below the top of the skimmer when

the pump is shut off.

In a level intake installation, the At-Rest water level in the water

feature will will be at the bottom of the overflow port.

Overflow

Phone: (800) 906-0604 Web: www.filtrific.com

6.00 Water At -Rest Level & Overflow

Downhill Installation

Professional Water Feature Equipment

Trim or lower the skimmer surface

as needed to accomodate the

rate of pumping. The skimmer

can also be adjusted by rotating

the eccentric coupling.

6.00 Water At-Rest Level

8.75

Level Intake

Liner is lowered for a Vanishing Pool

(Typically an additional 3". The water

will vanish just below the rock surface.

In this installation, deeper

Vanishing Pools are possible by

placing the Drain Intake level with

the bottom of the intake pipe.

ILTR I F

I C

Need help?

Do you have a question about the S64 and is the answer not in the manual?

Page 1 S64 Fixed Skimmer with T75F Filter Tank ILTR I F ® S64 Skimmer & T75F Filter Tank| VanishingWater Vanishing Water Installation Professional Water Feature Equipment Trim or lower the skimmer surface as needed to accomodate the rate of pumping. The skimmer can also be adjusted by rotating the eccentric coupling.
Page 2 S64 Fixed Skimmer with T75F Filter Tank ILTR I F ® Pond & Hybri-Pond Installation Professional Water Feature Equipment S64 Skimmer & T75F Filter Tank| Pond | Hybri-Pond Trim or lower the skimming surface The Filter Tank Rim is placed Pond as needed to accommodate the level with the rim of the rate of pumping.
Page 3 S64 Fixed Skimmer with T390F Filter Tank ILTR I F ® S64 Skimmer & T390F Filter Tank| VanishingWater Vanishing Water Installation Professional Water Feature Equipment Trim or lower the skimmer surface as needed to accommodate the rate of pumping. the skimmer can also be adjusted by rotating the eccentric coupling.
Page 4 S64 Fixed Skimmer with T390F Filter Tank ILTR I F ® Pond & Hybri-Pond Installation Professional Water Feature Equipment S64 Skimmer & T390F Filter Tank| Pond | Hybri-Pond The Filter Tank Rim is placed Trim or lower the skimming surface Pond as needed to accommodate the level with the rim of the rate of pumping.
