- Page 1 Model ＭＡＮＵＡＬ ES-4100 ES-4100...
-
Page 3: Table Of Contents
Index Product features..............1 Safety Precautions.............. 3 Package content..............7 Operation interface ............8 Preparation before use............. 9 Product instructions ............12 Cleaning & maintenance method for after use ...14 Optional product & contact info........15 Q & A ..................16 Troubleshooting..............17 Product spec...............19 Product and battery disposal methods ....21 Warranty letter..............23... -
Page 4: Product Features
Product features Product features Thank you very much for purchasing the "POWER IOT FOR ARMS" professional EMS (Electrical Muscle Stimulation) device. Please read this manual carefully before using and keep this product manual for later usage. POWER IOT FOR ARMS is currently the only multi-functional product in the EMS market that is made all-in-one strap style. - Page 5 Please read the instruction manual. Please read the instruction manual. The POWER IOT FOR ARMS manual can provide you with complete product operation methods and safety usage info. Please read it carefully before use to ensure that you can fully enjoy the outstanding training effects from this product.
-
Page 6: Safety Precautions
Safety precautions To ensure that the product is used correctly and safely, please read the instruction manual carefully before use. The precautions described in this manual are intended to ensure the safe and proper use of the product and to prevent injuries to yourself and others, or damage to property. - Page 7 DANGER In the following cases, the use of this product is strictly prohibited • Implanted medical devices, such as a pacemaker • Medical electrical equipment used to sustain life, such as heart-lung machines • Wearable medical devices, such as EKGs WARNING Anyone with the following conditions should not use the product •...
- Page 8 CAUTION Follow the precautions below when using the product. Failure to do so may result in an accident, electric shock, injury, damage, or soiling. • Do not heat the product itself or the gel sheet in a microwave or get it close to open flame. •...
- Page 9 CAUTION please read the instruction below carefully before use. • During the usage process, if you’d like to remove or relocate this product, make sure to turn the power off first. • If you sense something abnormal with your skin or body, stop use immediately and consult your doctor.
-
Page 10: Package Content
Package content Main device(R)Sub device(L) The R word on the main device means right hand. The L word on the sub device means left hand. Product: A. Main device(R) x1 B. Sub device(L) x1 Accessories C. Storage bag x1 D. Black cloth x1 (To clean the silicon surface) White paper towel x5 (Can soak it with water to clean the conductive... -
Page 11: Operation Interface
Operation interface Main device/Sub device【Front】 A. Main device D.EMS level down G. Strap buckle B. Sub device E.LED light H. Charging interface(type-C) C. EMS level up F. Power & mode selection button Main device/Sub device【back】 I. Conductive rubber electrode area... -
Page 12: Preparation Before Use
Preparation before usage 1.Charge the product It is recommended that you fully charge the POWER IOT FOR ARMS before using it for the first time. Insert the charging terminal ● to the USB charging hole on the side When charging, the LED ● ... - Page 13 ES-4200 Procedure 2 Procedure 1 omplete the pairing process for each ● First, perform the pairing procedure for main & sub devices of the ES-4100 & each model’s main device (ES-4100, ES4200(you’ll see the yellow light ES-4200). flashes quickly) ● Press the power & + & - button of the ●...
- Page 14 4.Applying the conductive liquid The function of the conductive liquid is to evenly conduct the energy output from the POWER IOT FOR ARMS electrode to the skin. Please apply it correctly according to the instructions below, take out the conductive liquid bottle, and squeeze an appropriate amount of conductive liquid to the fingertips, and evenly apply to the long black conductive rubber.
- Page 15 5.Wear it correctly After the conductive liquid has been applied to the electrode area, roll the product into a loop, then insert your arm into it. Adjust the tightness & the position according to your need. Make sure the control panel side is heading towards you. ●...
- Page 16 Basic operation of the product 1.Turn on the power Press and hold the power button of the main unit and sub unit for 1.5 seconds, you will hear a long beep, indicating that the main and sub units are powered on. When the sub unit sends out a beep-beep beep-beep-beep beep, it indicates that the synchronization connection status has been completed.
- Page 17 3.Adjust the intensity This machine is designed to adjust the output strength of the two machines individually. The maximum output level is 30. Please adjust slowly to avoid the sudden overload on the muscle for the EMS output. EMS level increase EMS level decrease...
-
Page 18: Cleaning & Maintenance Method For After Use
Cleaning & maintenance method for after use Clean & do the maintenance every time you use the device Apply small amount of water to the white paper towels, wipe away the conductive liquid remaining black conductive rubber. After this, use a black wiping cloth to clean the whole surface of the device. - Page 19 Optional product Purchase POWER IOT conductive liquid • Please contact our company or dealer for the purchase. • Be sure to use the conductive liquid that is specifically for this product • Misuse of non-original conductive liquid may result in poor conductive effect on this product •...
-
Page 20: Q & A
Q & A Q1 Can it be used every day? A1 Yes, it can be used daily; however, do not use more than twice a day for the same area, as it may result in muscle fatigue. Q2 Does higher the intensity of EMS the better on the effect? A2 Insist of using the high voltage that exceeds the individual’s intensity tolerance, it may damage the muscle for this type of pain and discomfort. -
Page 21: Troubleshooting
Trouble shooting Issue Cause Solution Battery exhausted Recharge the battery The power ailed to press the button Hold the + button down until fails to long enough the product beeps(1.5 seconds) turn on Being used in an environment Use in the recommended temperate that is too hot/cold range of 15 to 35 degree celsius Keep... - Page 22 １ ９ Issue Cause Solution The electrode area didn't fit Fit the electrode area close to My skin to the skin the skin turn red and feels Didn't paste enough Remove the product and paste prickly conductive liquid more conductive liquid to the electrode area There are no other accessory parts in this product.
-
Page 23: Product Spec
Product spec Product spec Model: ES-4100 POWER IOT FOR ARMS Adaptor spec: input 5V / 500mA Battery spec: DC 3.7V (Rechargeble lithium battery) Battery capacity: 250mAh Charger spec: Input=AC 100~240V, 50-60Hz / output=DC5V 500mA Frequency: 4 ~ 80Hz ± 10% (Cycle Rotates) Pulse width: 200~400µs ±... -
Page 24: Product And Battery Disposal Methods
Product and batter y disposal methods Please dispose the product properly in accordance with the local regulations. If the product is damaged or cracked, stop using it immediately and discard it. This product is equipped with a lithium battery. Be sure to remove the lithium battery when discarding it. - Page 25 Removing the lithium-ion battery 1. Please use POWER IOT FOR ARMS until it is completely inoperable (discharge the lithium ion battery). 2. Put a slotted screwdriver into the gap of the main body box, pry open the cover, and remove the battery from the base.
- Page 26 The retention period of the performance parts for repairing is 5 years from the manufacturing date. contact us If you have any questions regarding to the after-sales service, please contact your vendor or Unipad customer service center. Customer Service Center 10am~18pm Excepts Saturday &...
- Page 27 * If you have a different address from the warranty card, or your product is a gift from a person, your product can still be covered by this warranty from the dealers listed. If not, please contact UNIPAD Customer Service Center. In general, you may be charged on the following fees during the warranty period.
-
Page 28: Warranty Letter
Month/ Day/ date Name Phone Address Customer info ※Dealer’s name(where you purchase the product), address, telephone Dealer ※ ※Ask your dealer to fill & stamp Repair memo 850-17410-01001 Manufacturer: UNIPAD 株式會社 〒104-0032 東京都中央区八丁堀３-８-７瑞穂ビル4階 ©2020 UNIPAD JAPAN INC. All rights reserved.
