- Page 1 Reverse Osmosis Water Filtration System Owner’s Manual Model # PL400G Scan QR code for installation video or visit www.purlette.com...
- Page 2 Congratulations! You are now the owner of a Purlette System! Purlette is an under-the- sink water filtration system that makes tracking your water quality and keeping it clean and drinkable simpler than ever before. Using the accompanying mobile app, you can monitor the potability of your water and know at all times exactly how much life your filter has left in it.
-
Page 3: Table Of Contents
Introduction System Features Operation Panel Before Installation What’s in the Box Installation Three-Way Valve Drinking Faucet Drain Saddle Water Lines System Diagram Flushing the Filter Network Connection Maintenance Replacing the Filter Safety Warnings and Precautions Troubleshoot Self Troubleshooting Guide Warranty Three Year Limited Warranty... - Page 4 Auto-Cleaning Reserve Osmosis Filter The Purlette system will enter the auto-cleaning mode periodically. This is usage-based and will occur randomly. The Purlette system will make an audible sound when it is in auto- Post Carbon cleaning mode. Filter Safety Mode If user leaves the faucet turned on, the Purlette system will shut off automatically after two hours.
-
Page 5: Operation Panel
(non-flashing) upon successful connection. If a network connection has not been established, the network indicator light will continue to flash and the Purlette system will attempt to establish a connection for 10 minutes and then turn off. -
Page 6: Before Installation
Before Installation Operation Parameters INDOOR USE ONLY we recommend that the Purlette system installed under the kitchen sink. However, you may install the Purlette system in any suitable indoor location away from direct exposure to the environment, with adequate space for the Purlette system to stand upright. -
Page 7: What's In The Box
What’s in the Box Purifier Hybrid Filter Drinking Water Thread Dust Lid RO Filter Faucet Seal Tape and Parts Three-Way Drain 1/4” PE Locking Quick Silicon Feed Water Saddle Tubes Clips Connectors Protective Adaptor Valve Cover... - Page 8 Step 1: Install the three-way feed water adaptor valve Locate the cold water supply valve under the kitchen sink. Turn the incoming cold water off by turning the valve clockwise. Turn on the kitchen faucet to release any pressure and make sure the water has stopped before proceeding to the next step.
- Page 9 Close If your pipe connection is 1/2”, the three-way feed water adaptor valve is 3/8”, but comes with a 1/2”convertor for your convenience. Do not connect the other end to the Purlette system at this time Recommended Optional Installation Installation...
- Page 10 Once secure, slide the locking clip into place to avoid leaking Certain faucet models may not be equipped with a quick-connect fitting. Do not connect the other end to the Purlette system at this time...
- Page 11 (yellow PE tube) through the quick-connect fitting on the saddle and insert the locking clip to secure the yellow PE tube in place. Do not connect the other end to the Purlette system at this time Locking Clip...
- Page 12 Step 5: Connect water lines to Purlette system Attach quick-connectors to all three water lines and make sure to push in all the way until it stops. Slide the locking clip in to secure the water line. Repeat this process for all three water lines (white, yellow, and blue...
- Page 13 Now it’s time to check the system to make sure that there are no leaks! Do not plug in the Purlette system at this time. Turn on cold water supply and check each connection for leaks. If any leaks are detected, turn off cold water supply immediately, remove locking clips and ensure all fittings are properly installed and tightened.
- Page 14 Step 7: Plug in the Purlette system Now it is time to plug in the Purlette system. Plug the power cord into the 110 GFCI outlet. The indicator lights will flash 3 times in synchrony to tell you that it is starting up.
- Page 15 HYBRID After networking, the TDS value of filtered water can be viewed through RESET the Purlette mobile app. As TDS testing equipment is affected by water temperature, flow rate, and water pressure, the test value will have slight deviation. NETWORK...
-
Page 16: Maintenance
80 seconds for the RESET button for 3 the filter prior to the filter ports are gently until you adaptor and check Purlette system to seconds until you use. aligned. hear a pop sound. to make sure there initialize. - Page 17 Maintenance Replacing filter when indicator light is not flashing When replacing the filter without being prompted to by the system, you have to manually reset the timer for the filter life so the system can notify you when it is time to change your filter. Follow steps 2-12 on the last page.
-
Page 18: Safety
• Do not use wet hands to plug or unplug the power cord. • Do not allow flammable-volatile substances near the Purlette system. • Do not allow the Purlette system to be in contact, or close to, the source of heat or open fire. - Page 19 • The Purlette system is only intended for indoor installation and use. • If you do not use the Purlette system for an extended period of time, please disconnect power and close the three- way feed water adaptor valve. After you have started the Purlette system again, run the water for 3–5 minutes before use.
- Page 20 FCC Supplier’s Declaration of Conformity: Purlette / PL400G This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful intererence, and (2) this device must accept any interference recieved, including interference that may cause undesired operation.
-
Page 21: Troubleshoot
1-800-928-7624. Please do not attempt to disassemble and repair the Purlette system, as such action could result in damage to the system and void of warranty. - Page 22 • Reset the leakage detector by locating the tap water during pipe maintenance input line (blue tube) of the Purlette system then disconnecting and reconnecting the water input line to the inlet port. • To remove the air lock, unplug the system power cord and close the three-way feed water adapter.
-
Page 23: Three Year Limited Warranty
To obtain repairs or replacement within the terms of this warranty, please contact us at 1-800-928-7624 (open Monday to Friday, 8 am to 5 pm Pacific Time); PURLETTE/VISINI USA Inc., 136 N. Grand Ave., #330 West Covina, CA 91791. Proof of warranty coverage (i.e. - Page 24 PURLETTE/VISINI USA INC. West Covina, CA 91791 1-800-928-7624 support@purlette.com...
